  • Page 1 32 mm (1 1/4") A11AK� Mirka 150NV ®...
  • Page 2 Parts Page TORQUE SETTING ITEM Nm (in.-lbs.) 6.2 - 7.3 (55 - 65) 1.8 - 2.3 (16 - 20) 6.8 - 8.1 (60 - 72)

  • Page 3: Parts List

    Parts List Item Part No. Description Qty. MPA0040 EXTERNAL RETAINING RING MPA0021 BEARING - 2 SHIELDS MPB0017 REAR ENDPLATE MPA0005 CYLINDER ASSEMBLY MPA0042 O-RING MPB0005 ROTOR MPA0010 VANE MPA0041 WOODRUFF KEY MPB0016 FRONT ENDPLATE MPA0019 BEARING - 2 SHIELDS MPA0045 O-RING MPA0001 LOCK RING MPA1699 THROTTLE LEVER FOR 5.0mm ORBIT MACHINE MPA0031 LEVER SPRING PIN MPA0288 GRIP 65 mm (2 in.) Optional MPA0289 GRIP 70 mm (2 in.) Optional MPA0290 GRIP 75 mm (3 in.)
  • Page 4 REVISED 03/28/05 -PART WA -DWG TITL SET" -ITEM 1 DE -ITEM 2 DE -ITEM 3 DE Sander Spare Parts Kits -ITEM 4 DE -ITEM 5 DE RAG 03/04 -ITEM 8 - X NOT ON MJW 11/26 -ITEMS 9 & WERE NO MCC 04/19 X'POL PROPRIET THE INFORMATION CONTA...
  • Page 5 Mirka 8,000 rpm 32 mm (1 in.) RANDOM ORBITAL SANDER Declaration of conformity Mirka Ltd. FI-66850 Jeppo, Finland declare on our sole responsibility that the products 32 mm (1 in.) 8,000 rpm Random Orbital Sander (see “Product Configuration/Specifications” table for particular model) EN ISO 12100:2010, EN ISO to which this declaration relates is in conformity with the following standard(s) or other normative document(s) 11148-8:2011, EN ISO 15744:2008 & EN ISO 28927-3:2009 in accordance with the regulation 2006/42/EC. Jeppo 23.06.2020 Place and date of issue Company Stefan Sjöberg, CEO Operator Instructions Important Read these instructions care- Includes – Please Read and Comply, Proper Use of Tool, fully before installing, operating, Work Stations, Putting the Tool Into Service, Operating Instruc- servicing or repairing this tool. tions, Product Configuration/Specifications Tables, Parts Page, Keep these instructions in a safe Parts List, Sander Spare Parts Kits, Troubleshooting Guide accessible location.

  • Page 6: Putting The Tool Into Service

    Please Read and Comply with Putting the Tool into Service 1) General Industry Safety & Health Regulations, Part 1910, Use a clean lubricated air supply that will give a measured air OSHA 2206, available from: Superintendent of Documents; pressure at the tool of 6.2 bar (90 psig) bar when the tool is run- Government Printing Office; Washington DC 20402. ning with the lever fully depressed. It is recommended to use an 2) Safety Code for Portable Air Tools, ANSI B186.1 available from: approved 10 mm (3/8 in.) x 8 m (25 ft) maximum length airline. It American National Standards Institute, Inc.; 1430 Broadway; is recommended that the tool be connected to the air supply as New York, New York 10018. shown in Figure 1. 3) State and Local Regulations. Do not connect the tool to the airline system without incorporating an easy to reach and operate air shut off valve. The air supply Proper Use of Tool should be lubricated. It is strongly recommended that an air filter, regulator and lubricator (FRL) be used as shown in Figure 1 as This sander is designed for sanding all types of materials i.e. this will supply clean, lubricated air at the correct pressure to metals, wood, stone, plastics, etc. using abrasive designed for this the tool. Details of such equipment can be obtained from your purpose. Do not use this sander for any other purpose than that supplier.

  • Page 7: Technical Data

    Technical data Mirka® ROS 150NV Recommended Airline Size - Minimum 10 mm 3/8 in Recommend Maximum Hose Length 8 meters 25 feet Air Pressure - Maximum Working Pressure 6.2 bar 90 psig Air Pressure - Recommended Minimum Product Configuration/Specifications: 8,000 rpm Random Orbital Sander *Uncer- Product Height Length Power *Noise *Vibration tainty Vacuum Pad Size Model Consump- Orbit watts Level Level Type mm )inch(...

  • Page 8: Troubleshooting Guide

    Internal air leakage in the Motor Housing Check for proper Motor alignment and Lock Ring indicated by higher than normal air con- engagement. Check for damaged O-Ring in Lock sumption and lower than normal speed. Ring groove. Remove Motor Assembly and reinstall the Motor Assembly. See “Motor Disassembly” and “Motor Assembly”. Motor parts worn. Overhaul Motor. Contact authorized Mirka Service Center. Worn or broken Spindle Bearings Replace the worn or broken Bearings. See “Mini Ran- dom Orbital Head Disassembly” and “Mini Random Orbital Head Assembly”. Dirty, broken or bent Valve Spring, Valve Disassemble, inspect and replace worn or damaged Air leakage through the Speed or Valve Seat. parts. See steps 2 and 3 in “Housing Disassembly”...
