Summary of Contents for CRS 5AHPR0
- Page 1 Electronic Crimping Tool HPS With External Activation Model 5AHPR0 Crimping tools with interchangeable jaws and dedicated power supply Operation Guide...
- Page 2 Do not proceed beyond a WARNING notice until the indicated conditions are fully understood and met. Recycling Sound Pressure For recycling contact CRS or Sound pressure L = 79 dB(A) your local CRS distributor. Chromatography Research Supplies, Inc.
-
Page 3: Table Of Contents
8 mm Crimper Jaw Set 308955 13 mm Crimper Jaw Set 313955 13 mm Flip-Off Crimper Jaw Set 313956 11 mm Decapper Jaw Set 311965 20 mm Decapper Jaw Set 320965 13 mm Decapper Jaw Set 313965 Electronic Crimping Tool 5AHPR0... -
Page 4: Warnings, Intended Use, Limits
Warnings Remember to wear safety glasses when crimping or decapping. The crimper or decapper jaws can pinch severely. Only change jaws after the power supply has been disconnected or the tool has been locked. Never insert fingers into the crimping tool jaws. Use only the 12 volt DC Power Supply supplied with the crimping tool. -
Page 5: Mechanical Connections
Background The CRS 5AHPR0 High Power Crimping Tool can be adapted for use as a crimping head in automatic equipment. This guide serves to outline the mechanical and electrical connections necessary to do so. The designer of the device incorporating this tool will need to issue a new Declaration of Conformity after doing a risk analysis and studying the DoC Supplied. -
Page 6: Electrical Connections
Electrical Connection (Active Crimp or Serial Control) For remote activation (to activate the crimp cycle with a simple contactor) a connection can be made through the case wall of the crimping tool to the power supply adapter circuit board. There is a two-pin connector (P6, the lower white connector in the photo below) on this board that is wired in parallel to the activation button on the crimping tool itself. -
Page 7: Demonstration Interface
The log window shows the communication between the tool and the test program. Note that the program queries the tool setting continuously to keep up with any manual changes to the tool settings, with a lag time of several seconds. Electronic Crimping Tool 5AHPR0... -
Page 8: Power Supply Information
Power Supply Information Support and Repair If the crimping tool is still in the warranty period, contact your dealer for support. If the warranty period has expired, please visit www.ChromRes.com for information about the crimper repair service. Chromatography Research Supplies, Inc. -
Page 9: Appendix A - Accessory Base For Electronic Crimpers
Appendix A Accessory Base for Electronic Crimpers Electronic Crimping Tool 5AHPR0...
