AsReader ASR-P252B User Manual

Ios/android demo
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ASR-P252B iOS/Android Demo
User's Manual
Copyright © Asterisk Inc. All Rights Reserved.
AsReader® is a registered trademark of Asterisk Inc.
Other company and product names are generally trademarks or registered trademarks of
their respective companies.
The contents of this manual are subject to change without notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ASR-P252B and is the answer not in the manual?

Questions and answers

Related Manuals for AsReader ASR-P252B

Summary of Contents for AsReader ASR-P252B

  • Page 1 ASR-P252B iOS/Android Demo User’s Manual Copyright © Asterisk Inc. All Rights Reserved. AsReader® is a registered trademark of Asterisk Inc. Other company and product names are generally trademarks or registered trademarks of their respective companies. The contents of this manual are subject to change without notice.
  • Page 2 ASR-P252B Demo App for iOS/Android User’s Manual Revision History Version Modified Contents Date V1.0 Initial version 2023/9/8 ASTERISK INC.

  • Page 3: Table Of Contents

    ASR-P252B Demo App for iOS/Android User’s Manual Contents Preface ..........................3 About the Demo App for ASR-P252B ..................4 1. Page Description ....................... 5 2. How to Connect ......................... 6 2-1 Connecting via Bluetooth on iOS (See Android version below) ........6 2-2 Android ........................

  • Page 4: Preface

    ASR-P252B Demo App for iOS/Android User’s Manual Preface This document describes the correct operation method of the “ASR-P252B Demo App” for iOS/Android, which can be found on the Apple Store and the Google Play Store. Be sure to read this carefully before using the application.

  • Page 5: About The Demo App For Asr-P252B

    ASR-P252B Demo App for iOS/Android User’s Manual About the Demo App for ASR-P252B The “ASR-P252B Demo App” (hereinafter referred to as "Demo APP", "the app" or “app”) is an application that customers can use together with our company's ASR-P252B device (hereinafter referred to as "AsReader"...

  • Page 6: Page Description

    Go to the Scan 1D and 2D barcodes page. 签信息写入页面 Go to the Update the firmware version of the AsReader page. Go to the Udate the firmware version of the RFID module page. Remaining battery level of the AsReader guage.

  • Page 7: How To Connect

    Bluetooth serial number of the AsReader which is connected on the Bluetooth Settings page of the iOS device Tap "PADDLE-Type" on the list to connect to the AsReader. Once connected, the main page is displayed automatically, and the page becomes active.

  • Page 8: Android

    “one way cable” with one side of the cable marked “PHONE”. Please be sure that side of the cable is connected to your Android or Windows Smartphone or Tablet. Once connected with the cable, the AsReader will beep and the blue Status Indicator LED will be steadily Start the app.

  • Page 9: How To Operate

    3-1 Inventory of RFID Tags Tap "Inventory" and then tap the "Inventory" button to begin inventorying RFID tags. Pressing the trigger button of the AsReader itself can also start and stop inventorying. Items that need to be set up to inventory RFID tags.
  • Page 10 ASR-P252B Demo App for iOS/Android User’s Manual Export RFID tag data The number of times a single RSSI is displayed when the tag has been inventoried. "Report RSSI" function is turned Number of RFID tags read per 1 second of inventory.
  • Page 11 ASR-P252B Demo App for iOS/Android User’s Manual Select the specific RFID tag in the list to do operations such as read/write/lock. Please refer to "3-3 Operations to RFID Tags" for details. See "3-3-1 Read Memory" See "3-3-2 Write Memory" See "3-3-3 Lock Memory"...

  • Page 12: Settings

    ⑥ ① Power Gain You can configure the output power of the AsReader (dBm). In general, the larger the value of power is set, the farther the reading distance will be, but the more electric power is consumed. This setting is saved to the AsReader.
  • Page 13 This setting is saved to the app. ⑤ Operation Time Configure the inventory time. The AsReader stops the inventory as soon as the set time has passed. This setting is saved to the AsReader and the app.
  • Page 14 Buzzer Set the buzzer on/off and volume. When it is turned on, AsReader will beep at the set volume in the following scenarios: When the AsReader is turned on or turned off, When the smartphone (or tablet or PC) and the AsReader connect or disconnect, When the AsReader inventories RFID tags or scans 1D or 2D barcodes, When an RFID tag is read, written to, locked, or killed.
  • Page 15 Long inventory distance. Same as “1”. Fast inventory. Default Link Profile ⑩ Set the default value of Link Profile. When the AsReader is connected to the app, the value of the Link Profile will default to the Default Link Profile. ASTERISK INC.
  • Page 16 “Save” button to save your changes or they will be lost. * The settings of ① ~ ③, ⑤ ~ ⑨, ⑪, ⑫ are saved to the AsReader and the app. The settings of ④ and ⑩ are saved to the app.

  • Page 17: Mask

    ASR-P252B Demo App for iOS/Android User’s Manual 3-2-3 Mask "Mask" is a function to filter RFID tags. It can be set separately in the "Mask" on the "Inventory", "Read Memory", "Write Memory", and "Lock Memory" pages. Setting steps (using the Inventory page, as an example): 1.

  • Page 18: Operations To Rfid Tags

    ASR-P252B Demo App for iOS/Android User’s Manual 3-3 Operations to RFID Tags 3-3-1 Read Memory Tap "Read Memory" to read the memory of a RFID tag. ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ① Result The reading result of the RFID tag is displayed in the "Result"...
  • Page 19 Configure the power gain of AsReader. This setting is saved to the AsReader. ⑧ Operation Time Configure the duration of the “Read” processing. This setting is saved to the AsReader. ⑨ Report RSSI When this “Received Signal Strength Indicator” feature is enabled, the radio wave intensity from the read RFID tag is displayed.

  • Page 20: Write Memory

    ASR-P252B Demo App for iOS/Android User’s Manual 3-3-2 Write Memory Tap "Write Memory" to write to the RFID tag. ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ① Result The writing results of an RFID tag will be displayed in the "Result" area.
  • Page 21 ⑥ Power Gain Configure the radio output value of AsReader. This setting is saved to the AsReader. ⑦ Operation Time Configure the execution time of the "Write" processing. This setting is saved to the AsReader.

  • Page 22: Lock Memory

    ASR-P252B Demo App for iOS/Android User’s Manual 3-3-3 Lock Memory Tap "Lock Memory" to perform the Lock or Kill operation on the RFID tag. ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ Lock RFID tags Set mask. (About how to set...
  • Page 23 To Lock, Unlock, or Permalock an RFID tag, you must enter an access password here. ⑧ Power Gain Configure the radio output value of AsReader. This setting is saved to the AsReader. ⑨ Operation Time Configure the execution time for the processing of the "Lock" series such as “Lock”...

  • Page 24: Inventory Rfid Tags With Temperature/Moisture Sensors

    3-4 Inventory RFID Tags with Temperature/Moisture Sensors Tap "Humiture" and then tap the "Inventory" button to inventory the RFID tags with temperature/moisture sensors. (Or pull AsReader’s trigger while on this screne.) The inventory continues until the "Stop" button is tapped or the trigger button is pressed again.
  • Page 25 Clear the RFID tag list ① Continuous Mode Enable or disable the continuous reading mode. Once enabled, the AsReader continues to inventory multiple RFID tags with temperature/moisture sensors from when the "Inventory" button is tapped until the "Stop" button is tapped.

  • Page 26: 2D Barcode Scan

    Pressing the trigger button of the AsReader can also start and stop scanning. Press the trigger button of the AsReader or tap the “Start Scan” button on the app. When no barcode is scanned within the timeout time period, the AsReader stops trying to scan.
  • Page 27 ASR-P252B Demo App for iOS/Android User’s Manual Export scanned data Barcode data Barcode type ① ② Start scanning /Stop scanning Number of different barcodes Clear the scanned data scanned ① Encoding There are three choices for encoding formats: ASCII, UTF8, and Shift JIS.

  • Page 28: Firmware Update

    ASR-P252B Demo App for iOS/Android User’s Manual 3-6 Firmware Update Tap “Firmware Update” to update the firmware of the AsReader. This function requires a WAN connection to the Internet. Operating steps: The “Update Firmware” page first displays a list of currently downloaded firmwares.
  • Page 29 ASR-P252B Demo App for iOS/Android User’s Manual ASTERISK INC.

  • Page 30: Firmware Update (Rfid)

    ASR-P252B Demo App for iOS/Android User’s Manual 3-7 Firmware Update (RFID) Tap “RFID Update Firmware” to update the firmware of the RFID module of the AsReader. This function requires a WAN connection to the Internet. * Please refer to "3-6 Firmware Update" for details on how to complete this similar process.

  • Page 31: Data Export

    ASR-P252B Demo App for iOS/Android User’s Manual 3-8 Data Export The barcode and RFID tag data can be exported as a CSV file, or, with an iOS device an Excel file is also possible. You can then transfer those files to your PC via iTunes.
  • Page 32 ASR-P252B Demo App for iOS/Android User’s Manual ASR-P252B iOS/Android Demo User’s Manual Sep. 2023 1 Edition AsReader, Inc. Toll Free (US+Canada): +1 (888) 890 8880 / Tel: +1 (503) 770 2777 x102 920 SW 6th Ave., 12th Fl., Suite 1200, Portland, OR 97204-1212 U.S.A.
