- Page 1 Visit www.DeepL.com/pro for more information. Producｔ Ｍａｎｕａｌ Product Name ： １６Ｓ－３０ＡＨ Ｓｍａｒｔ Ｂａｔｔｅｒｙ File Version: V1.0 --------------------------------------------------------------------------------------------------------------------------------...
- Page 2 Reading Tips This product is a high rate special intelligent battery pack for powering drones, which has certain special characteristics and requires a period of familiarity before it can be used safely and requires a certain amount of professional knowledge before it can be operated. Without a strong sense of safety, improper operation may result in product damage and property loss, or even injury to yourself or others.
- Page 3 Overvoltage alarm value TYP.4.30V/ TYP.4.25 /recovery value Charging overcurrent TYP.50 alarm value Over-temperature alarm TYP.75℃/ TYP.65℃ value / recovery value Low voltage alarm value / TYP.3.00V/ TYP.3.05V recovery value Operating voltage range 48.0V～67.2V Working environment Charge: 0～45℃; Discharge: temperature -10～60℃ Batter weight TYP.9.0k Size...
- Page 4 ６．Ｄａｔａ ｃｏｍｍｕｎｉｃａｔｉｏｎ ｆｕｎｃｔｉｏｎ： Ｔｈｉｓ ｂａｔｔｅｒｙ ｈａｓ ｂｏｔｈ ｓｅｒｉａｌ ｃｏｍｍｕｎｉｃａｔｉｏｎ ａｎｄ Ｂｌｕｅｔｏｏｔｈ ｗｉｒｅｌｅｓｓ ｃｏｍｍｕｎｉｃａｔｉｏｎ ｃａｐａｂｉｌｉｔｉｅｓ． Ｂｏｔｈ ｃｏｍｍｕｎｉｃａｔｉｏｎ ｍｅｔｈｏｄｓ ｃａｎ ｐｒｏｖｉｄｅ ｉｎｆｏｒｍａｔｉｏｎ ｏｎ ｉｎｄｉｖｉｄｕａｌ ｃｅｌｌ ｖｏｌｔａｇｅ， ｔｏｔａｌ ｖｏｌｔａｇｅ， ｃｕｒｒｅｎｔ， ｓｔａｔｅ ｏｆ ｃｈａｒｇｅ （ＳＯＣ）， ｔｅｍｐｅｒａｔｕｒｅ， ｃｙｃｌｅ ｃｏｕｎｔ， ａｎｄ ａｂｎｏｒｍａｌ ｓｔａｔｕｓ ｃｏｕｎｔ． Ｉｔ ｃａｎ ａｌｓｏ ｅｓｔａｂｌｉｓｈ ａ ｄａｔａ ｃｏｎｎｅｃｔｉｏｎ ｗｉｔｈ ｔｈｅ ｆｌｉｇｈｔ ｃｏｎｔｒｏｌｌｅｒ ｖｉａ ｓｅｒｉａｌ ｐｏｒｔ． Ｂｌｕｅｔｏｏｔｈ ｃａｎ ｃｏｍｍｕｎｉｃａｔｅ ｗｉｔｈ ａ ｍｏｂｉｌｅ ａｐｐ ｔｏ ｄｉｓｐｌａｙ ｂａｔｔｅｒｙ ｉｎｆｏｒｍａｔｉｏｎ． 7.Ｉｎｔｅｌｌｉｇｅｎｔ ｌｏｇ ｒｅｃｏｒｄｉｎｇ： Ｔｈｅ ｍａｎａｇｅｍｅｎｔ ｓｙｓｔｅｍ ｈａｓ ａ ｕｎｉｑｕｅ ｌｏｇ ｄａｔａ ｒｅｃｏｒｄｉｎｇ ｆｕｎｃｔｉｏｎ， ｃｏｎｔｉｎｕｏｕｓｌｙ ｍｏｎｉｔｏｒｉｎｇ ａｎｄ ｒｅｃｏｒｄｉｎｇ ｂａｔｔｅｒｙ ｉｎｆｏｒｍａｔｉｏｎ， ｉｎｃｌｕｄｉｎｇ ｉｎｄｉｖｉｄｕａｌ ｃｅｌｌ ｖｏｌｔａｇｅ， ｃｕｒｒｅｎｔ， ｂａｔｔｅｒｙ ｔｅｍｐｅｒａｔｕｒｅ， ｂａｌａｎｃｉｎｇ ｒｅｃｏｒｄｓ， ｃｙｃｌｅ ｃｏｕｎｔ， ａｎｄ ａｂｎｏｒｍａｌ ｓｔａｔｕｓ ｃｏｕｎｔ． Ｕｓｅｒｓ ｃａｎ ｑｕｅｒｙ ｔｈｅ ｉｎｆｏｒｍａｔｉｏｎ ｂｙ ｄａｔｅ ａｎｄ ｔｉｍｅ ｕｓｉｎｇ ｔｈｅ ｕｐｐｅｒ ｃｏｍｐｕｔｅｒ ｓｏｆｔｗａｒｅ， ｏｒ ｅｘｐｏｒｔ ｈｉｓｔｏｒｉｃａｌ ｄａｔａ ｒｅｃｏｒｄｓ in Excel format. IV. Instructions for use 1. Battery level inquiry When the battery is in shutdown mode, a short press of the button will cause the green LED to indicate the battery level for 3 seconds before turning off. The battery level indicators are as follows: LED2 LED3...
- Page 5 until all four green LEDs light up, accompanied by a "beep" from the buzzer to indicate that the startup process has begun. Release the button, and the buzzer will make a long "beep" for 1 second, followed by LED indicators showing the current battery level.
- Page 6 2. The charger automatically stops charging when the battery is fully charged. It is recommended to disconnect the battery from the charger when charging is complete. 3. When the abnormal indicator flashes, stop charging immediately and investigate the abnormal situation until the abnormal situation is eliminated before continuing to use the battery.
- Page 7 （３） Ｏｖｅｒ－ｃｕｒｒｅｎｔ ａｌａｒｍ ｄｕｒｉｎｇ ｃｈａｒｇｉｎｇ： Ｗｈｅｎ ｔｈｅ ｃｈａｒｇｉｎｇ ｃｕｒｒｅｎｔ ｉｓ ｇｒｅａｔｅｒ ｔｈａｎ ５０Ａ， ｔｈｅ ｂｕｚｚｅｒ ｗｉｌｌ ｓｏｕｎｄ ａｎｄ ｔｈｅ ｃｏｒｒｅｓｐｏｎｄｉｎｇ ＬＥＤ ｗｉｌｌ ｂｌｉｎｋ． （４） Ｂａｔｔｅｒｙ ｏｖｅｒ－ｔｅｍｐｅｒａｔｕｒｅ ａｌａｒｍ （ｃｈａｒｇｉｎｇ／ｄｉｓｃｈａｒｇｅ）： Ｗｈｅｎ ｔｈｅ ｔｅｍｐｅｒａｔｕｒｅ ｒｅａｃｈｅｓ ７５°C， ｔｈｅ ｂｕｚｚｅｒ ｗｉｌｌ ｓｏｕｎｄ ａｎｄ ｔｈｅ ｃｏｒｒｅｓｐｏｎｄｉｎｇ ＬＥＤ ｗｉｌｌ ｂｌｉｎｋ． （Ｐｒｅｓｓ ｔｈｅ ｂｕｔｔｏｎ ｔｏ ｓｔｏｐ ｔｈｅ ｂｕｚｚｅｒ ａｌａｒｍ） Ｔｈｅ ａｌａｒｍ ｗｉｌｌ ｂｅ ａｕｔｏｍａｔｉｃａｌｌｙ ｃａｎｃｅｌｌｅｄ ｗｈｅｎ ｔｈｅ ｔｅｍｐｅｒａｔｕｒｅ ｄｒｏｐｓ ｂｅｌｏｗ ６５°C． 6. Description of power supply After connecting the power output cable of the battery to the power input interface of the drone, the drone can take off normally. If there is communication between the battery and the flight controller, you must perform a startup operation and wait for the data communication to be normal before taking off.
- Page 8 1. Ｐｌｅａｓｅ ｕｓｅ ｔｈｅ ｏｒｉｇｉｎａｌ ｍａｔｃｈｉｎｇ ｄｒｏｎｅ ｂａｔｔｅｒｙ ｓｐｅｃｉａｌ ｃｈａｒｇｅｒ ｆｏｒ ｃｈａｒｇｉｎｇ ａｎｄ ｋｅｅｐ ａｗａｙ ｆｒｏｍ ｈｉｇｈ ｔｅｍｐｅｒａｔｕｒｅ ｅｎｖｉｒｏｎｍｅｎｔ； 2. Ｄｏ ｎｏｔ ｃｈａｒｇｅ ｗｉｔｈｏｕｔ ｓｕｐｅｒｖｉｓｉｏｎ． Ｉｆ ａｎｙ ａｂｎｏｒｍａｌｉｔｉｅｓ ａｒｅ ｆｏｕｎｄ， ｉｍｍｅｄｉａｔｅ ｌｙ ｓｔｏｐ ｃｈａｒｇｉｎｇ ａｎｄ ｄｉｓｃｏｎｎｅｃｔ ｔｈｅ ｂａｔｔｅｒｙ ｆｒｏｍ ｔｈｅ ｃｈａｒｇｅｒ； 3. Ｄｏ ｎｏｔ ｄｉｓｃｈａｒｇｅ ｔｈｅ ｂａｔｔｅｒｙ ｂｅｙｏｎｄ ｉｔｓ ｍａｘｉｍｕｍ ｄｉｓｃｈａｒｇｅ ｃｕｒｒｅｎｔ， ｏｔｈｅｒｗｉｓｅ ｉｔ ｍａｙ ｃａｕｓｅ ｐｅｒｍａｎｅｎｔ ｄａｍａｇｅ ｔｏ ｔｈｅ ｂａｔｔｅｒｙ ｏｒ ｅｖｅｎ ｆｉｒｅ； 4. Ｉｆ ｔｈｅ ｂａｔｔｅｒｙ ｄｅｆｏｒｍｓ， ｅｍｉｔｓ ａｎ ｏｄｏｒ， ｏｒ ｂｅｃｏｍｅｓ ａｂｎｏｒｍａｌｌｙ ｈｏｔ （ｔｅｍｐｅｒａｔｕｒ ｅ ｅｘｃｅｅｄｉｎｇ ７５℃） ｄｕｒｉｎｇ ｕｓｅ， ｉｍｍｅｄｉａｔｅｌｙ ｓｔｏｐ ｕｓｉｎｇ ｉｔ ａｎｄ ｔｒａｎｓｆｅｒ ｔｈｅ ｂａｔｔｅｒ ｙ ｔｏ ａ ｖｅｎｔｉｌａｔｅｄ ａｎｄ ｓａｆｅ ａｒｅａ； 5. Ｐｌｅａｓｅ ｐｅｒｆｏｒｍ ｔｉｍｅｌｙ ｃｌｅａｎｉｎｇ ａｎｄ ｍａｉｎｔｅｎａｎｃｅ ｏｎ ｔｈｅ ｂａｔｔｅｒｙ ａｆｔｅｒ ｕｓｅ ｔｏ ｐ ｒｅｖｅｎｔ ｄｒｕｇ ｃｏｒｒｏｓｉｏｎ ｏｆ ｔｈｅ ｐｌｕｇ ａｎｄ ｂａｔｔｅｒｙ； 6. Ｉｔ ｉｓ ｆｏｒｂｉｄｄｅｎ ｔｏ ｃｏｎｎｅｃｔ ｔｈｅ ｂａｔｔｅｒｙ ｔｏ ｐｏｗｅｒ－ｃｏｎｓｕｍｉｎｇ ｅｑｕｉｐｍｅｎｔ ｆｏｒ ａ ｌｏ ｎｇ ｔｉｍｅ． Ａｆｔｅｒ ｕｓｉｎｇ ｔｈｅ ｂａｔｔｅｒｙ， ｐｌｅａｓｅ ｓｅｐａｒａｔｅ ｉｔ ｆｒｏｍ ｔｈｅ ｅｌｅｃｔｒｉｃａｌ ｅｑｕｉｐｍ ｅｎｔ ｉｎ ａ ｔｉｍｅｌｙ ｍａｎｎｅｒ； 7. Ａｆｔｅｒ ｕｓｅ， ｐｌｅａｓｅ ｃｈａｒｇｅ ｔｈｅ ｂａｔｔｅｒｙ ｉｎ ａ ｔｉｍｅｌｙ ｍａｎｎｅｒ ｔｏ ａｖｏｉｄ ｏｖｅｒ－ｄｉｓｃｈａ ｒｇｅ ａｎｄ ｄａｍａｇｅ ｔｏ ｔｈｅ ｂａｔｔｅｒｙ ｃａｕｓｅｄ ｂｙ ｌｏｎｇ－ｔｅｒｍ ｓｔｏｒａｇｅ； 8. Ｔｈｅ ｂａｔｔｅｒｙ ｓｈｏｕｌｄ ｂｅ ｓｔｏｒｅｄ ｉｎ ａ ｄｒｙ ａｎｄ ｖｅｎｔｉｌａｔｅｄ ｐｌａｃｅ， ａｎｄ ａｗａｙ ｆｒｏｍ ｏｐ ｅｎ ｆｌａｍｅｓ， ｈｅａｔ ｓｏｕｒｃｅｓ， ｆｌａｍｍａｂｌｅ ａｎｄ ｅｘｐｌｏｓｉｖｅ， ｃｏｒｒｏｓｉｖｅ ｓｕｂｓｔａｎｃｅｓ， ｅｔｃ． Ｗｈ ｅｎ ｎｏｔ ｉｎ ｕｓｅ ｆｏｒ ａ ｌｏｎｇ ｔｉｍｅ， ｉｔ ｓｈｏｕｌｄ ｂｅ ｃｈａｒｇｅｄ ａｎｄ ｍａｉｎｔａｉｎｅｄ ｒｅｇｕｌａｒｌｙ （ｒ ｅｃｏｍｍｅｎｄｅｄ ｎｏｔ ｔｏ ｅｘｃｅｅｄ ３ ｍｏｎｔｈｓ）； 9. Ｐｌｅａｓｅ ｓａｆｅｌｙ ｍａｎａｇｅ ｔｈｅ ｂａｔｔｅｒｙ ａｎｄ ｐｒｏｈｉｂｉｔ ｍｉｎｏｒｓ ｆｒｏｍ ｔｏｕｃｈｉｎｇ， ｐｌａｙｉｎｇ， ｏｒ ｕｓｉｎｇ ｔｈｅ ｂａｔｔｅｒｙ ｔｏ ｐｒｅｖｅｎｔ ａｃｃｉｄｅｎｔｓ； 10. Ｉｔ ｉｓ ｓｔｒｉｃｔｌｙ ｐｒｏｈｉｂｉｔｅｄ ｔｏ ｅｘｐｏｓｅ ｔｈｅ ｂａｔｔｅｒｙ ｔｏ ｄｉｒｅｃｔ ｓｕｎｌｉｇｈｔ． Ｔｈｅ ｂａｔ ｔｅｒｙ ｉｓ ｍｏｉｓｔｕｒｅ－ｐｒｏｏｆ ａｎｄ ｄｕｓｔ－ｐｒｏｏｆ， ｂｕｔ ｎｏｔ ｗａｔｅｒｐｒｏｏｆ ｏｒ ｆｉｒｅｐｒｏｏｆ． Ｕｎｄｅｒ ｎ ｏ ｃｉｒｃｕｍｓｔａｎｃｅｓ ｓｈｏｕｌｄ ｔｈｅ ｂａｔｔｅｒｙ ｂｅ ｔｈｒｏｗｎ ｉｎｔｏ ｗａｔｅｒ ｏｒ ｆｉｒｅ； 11. Ｄｏ ｎｏｔ ｓｑｕｅｅｚｅ， ｃｏｌｌｉｄｅ， ｐｕｎｃｔｕｒｅ， ｄｉｓａｓｓｅｍｂｌｅ， ｏｒ ｓｈｏｒｔ－ｃｉｒｃｕｉｔ ｔｈｅ ｂａｔｔｅｒ ｙ ｔｏ ａｖｏｉｄ ｄａｎｇｅｒ ａｎｄ ｕｎｎｅｃｅｓｓａｒｙ ｌｏｓｓｅｓ． --------------------------------------------------------------------------------------------------------------------------------...
