Foxtech M15 Manual

Uav megaphone system for dji m300

M15 UAV Megaphone System for DJI M300

M15 is a small-size, lightweight, and long-distance wireless megaphone

system designed for DJI M300. The communication range is up to 5km, the sound

transmission distance can reach 150m.

The onboard megaphone adopts high-decibel amplification equipment, a high-

quality digital amplifier, and an audio processing unit, making the output sound loud

and clear without distortion. The handheld end is a high-quality and user-friendly

intercom with a humanized design for easy operation. The entire wireless

communication system adopts encryption technology, ensuring that communication

is free of interference, secure and reliable.

The M15 wireless megaphone system is an ideal choice for a variety of

applications, such as disaster response and emergency management, public safety

and security, search and rescue etc.

Function: Real-time Broadcasting, 3 Kinds of Alarms and Sirens

10s Real-time Recording (recording and playback),

MP3 Function (TF card)

Max Power: 50W

Transmission Distance: 5km

Built-in Battery (Handheld Intercom): 2200mAh/12.6V

Frequency: 400-470MHZ

Sound Transmission Distance: 200m

Megaphone Weight: 700g

Megaphone Size: 190*100*160mm (including antenna)

Table of Contents

Do you have a question about the M15 and is the answer not in the manual?

Page 1 The M15 wireless megaphone system is an ideal choice for a variety of applications, such as disaster response and emergency management, public safety and security, search and rescue etc.
Page 2 Installation： 1 1 1 ： As shown above, with the mounting plate on the left, fix the 1.2.3.4 hole positions to the 5.6.7.8 holes under the M300 large plate on the right. (mounting on the remaining 4 holes is also possible.) Use of the on-board end: After the on-board end has been installed, press the switch button and the voltage is displayed normally.
Page 3 Handheld Intercom Function ： Real-time recording and playback, playback of warning and alarm sounds. TF card is supported. The handheld terminal controls the audio playback in the TF card. Built-in battery, easy to carry. attery capacity: 12.6v, 2200mah Function button description: The three yellow buttons are for siren, fire alarm, and continuous alarm.
Page 4 （二） Handheld Intercom Press the TF/handheld intercom function button to switch to the handheld intercom end. When using the handheld intercom, first make sure that all 5 function buttons are in the pop-up state, and then turn on the power switch. At this time, the power indicator light will be on, the REC light will not be on, press and hold Play button to speaking.The Play button is in the pop...
