Summary of Contents for Wi-Tek WI-IOT411T
- Page 1 Installation Guide Serial Device Server WI-IOT411T | WI-IOT411D www.witek-iiot.com...
-
Page 2: Package Contents
1. Package Contents 1 x WI-IOT411T 1 x WI-IOT411D 1 x AC Power Adapter... -
Page 3: Hardware Introduction
2. Hardware Introduction Structure Dimensions WI-IOT411T 14mm 15mm 30mm 42mm 79mm 3.5mm 3.5mm 52mm 62mm 72mm 21mm WI-IOT411D 14mm 15mm 30mm 42mm 79mm 3.5mm 3.5mm 52mm 62mm 72mm 21mm... - Page 4 Indicator Light Description WI-IOT411T PWR(Red): √ PUN(Green): √ DATA(Green): √ WI-IOT411D PWR(Red): √ PUN(Green): √ DATA(Green): √...
-
Page 5: Hardware Installation
WI-IOT411 series network pin definition: Description RJ45 Definition Transmitting Signal + Transmitting Signal - Receiving Signal+ Receiving Signal- 4,5,7,8 WI-IOT411 series serial port pin definition: Model WI-IOT411T Signal RS-485 RS-422 422 transmitting+ T/R+ 485-A 422 transmitting- T/R- 485-B 422 receiving+... -
Page 6: Network Application
4. Network Application WI-IOT411T Serial Device WI-IOT411D Serial Device... -
Page 7: Login Method
5. Login Method Please connect devices according to the above topology. Follow the steps for quick configuration, using initial setup wizard: Step 1 Connect your PC to device via Ethernet or wireless. Step 2 Launch your web browser then enter http://192.168.1.88 in the address bar and specify the default login key:admin/admin. -
Page 8: Warranty Card
Warranty Card Username Address Telephone No. Purchase Shop Purchase Address Product Model No. Purchase Time Serial No. Dealer Signature If the product defects within three months after purchase, we will provide you a new product of the same model. If the product defects within the three-year warranty period, we will provide the professional maintenance service.
