Ava PT-HT235P User Manual

The HDMI extender provides extension of HDMI signals long distances over a single CAT6
cable, it supports high resolution up to 1080p, EDID copy function. The extender can use for a
wide range of applications requiring long distance transmission of high resolution with high
quality by its good stability and powerful security.
HDMI UTP Extender
Model： PT-HT235P
Transmits HDMI video and audio signals up to 50M over a single CAT6 cable;
Support video resolution up to 1920*1080@60Hz, 3D signal;
Support copy EDID, can match many kinds of display device;
Compliance with HDMI 1.3 and HDCP 1.2 standard;
Support POC unilateral power supply;
High compatibility, can auto-match source and display device;
Built-in automatic adjustment system, make the image smooth, clear and stable;
Simple to install, plug and play.
HDMI transmitter HDMI receiver
Power adapter User manual
Maximum pixel clock
Resolution
Impedance

Interface

Ethernet
Transmission distance
Power supply
Power dissipation
Temperature
Other
Humidity
Dimension
The warranty
型号：STK-S7219H
HDMI 1.3; HDCP 1.2
165MHz
6.75Gbps
1920X1080@60Hz, 3D
HDMI-A
100Ω
RJ45
CAT6---50M
The power adapter: DC 5-12V
MAX 3W
Operating: -5℃ ~ +70℃
Operating: 5% ~ 90%
81*43*23mm
1 year free warranty
