Summary of Contents for JELLYPIG TZ-926
- Page 1 Dog Training Collar User Manual TZ-926 Please Read This Manual Carefully Before Use...
-
Page 2: Table Of Contents
Contents Packaging List Product Specifications Main Features Important Statement Transmitter Introduction Receiver Introduction Charging Instructions Operation Instructions Receiver Fitting Instructions Pairing Instructions How Does the Training Collar Work Frequently Asked Questions Troubleshooting Training Tips Common Weights for Different Size Dogs Common Sizes for Different Breeds of Dogs Warranty Compliance FCC -USA... -
Page 3: Packaging List
② Receiving Collar ③ Type-C Charging Cable ④ Wrist Strap ⑤ Test Light Tool ⑦ Contact Points ⑥ Mini Spanner ⑧ Silicone Caps Remote Dog Training Collar User Manual TZ-926 Please Read This Manual Carefully Before Use ⑨ User Manual... -
Page 4: Product Specifications
Product Specifications Product Name: Remote Dog Training Collar Product Model: TZ-926 Material: ABS+PC Control Range: 800M(2600FT) Charging Method: Type-C Transmitter/ Receiver 2.5 Hours Charging Time: Transmitter/ Receiver 180 Days Standby Time: Transmitter Waterproof Rating: Not Waterproof Receiver Waterproof Rating: IPX7 Waterproof Working temperature: -30°C- +70°C... -
Page 5: Main Features
Main Features Beep, Vibration, Shock training mode 1-9 adjustable beep sound levels 1-16 adjustable Vibration/Shock levels With safe LED light for locating your dog at night Remote control range up to 800M(2600FT) Dual battery power display Receiver is IPX7 waterproof; Transmitter is not waterproof Security lock function One Transmitter can control up to 3 Receivers... -
Page 6: Important Statement
Important Statement WARNING! • DO NOT use this product for aggressive dogs or vicious animals. • When the receiving collar is turned on, the human body should not directly touch the Shock contact points of the collar. Risk of skin damage. It’s important to fit the collar properly. A collar that is fitted too tightly or worn for too long may harm your dog's skin. -
Page 7: Transmitter Introduction
Transmitter Introduction LED Light Channel Button Button Color Screen Key Lock Level+ Button Switch Level- Button Beep Button Shock Button Vibration Button Lock Key Channel 1 LED Light Mode Channel 2 Beep Mode Channel 3 Shock Mode Transmitter Battery Vibration Mode Receiver Battery Digital Display for training intensity... -
Page 8: Receiver Introduction
Receiver Introduction ON/OFF Button(Short press) Pairing Button (Long press) Indicator Light LED Mode Indicator Light (The status of the mode indicator light is as follows in the corresponding mode.) Mode LED Mode Indicator Light Status Beep Mode Mode Indicator will light up Green Vibration Mode Mode Indicator will light up Blue Shock Mode... -
Page 9: Charging Instructions
Charging Instructions Please charge the product before use or when the transmitter and receiver battery icons flash on the screen! It takes 2.5 hours to fully charge the transmitter and receiving collar. 1. When the transmitter is charging, three bars of the battery icon ( ) is running circularly. -
Page 10: Operation Instructions
Operation Instructions 1. Turn on/off the transmitter and receiver • Turn on the transmitter: push down the key lock switch, the screen will light up, indicating that transmitter is in the working state. • Lock the transmitter: push up the key lock switch, the lock key icon flashes, which means entering key lock mode. - Page 11 2. Operate beep function • Short Press the ( ) button to launch beep signal, the ( ) is displayed on the screen, the Mode Indicator will light up Green once and the receiving collar will beep once after receiving the signal. Long press the ( ) button, the Green light will remain on and the receiving collar will continuously beep.
- Page 12 4. Operate Shock Function • Short press the ( ) button to launch shock signal, the ( ) is displayed on the screen, the Mode Indicator will light up Red once and the receiving collar will generate static impulse once after receiving the signal. Long press the ( ) button, the Red light will remain on and the receiving collar will continuously generate static impulse.
- Page 13 5. Operate LED Light Function • Short Press the ( ) button to turn on LED light mode for locating your dog at night, and the ( ) is displayed on the screen. • After the LED light mode is turned on, short press the ( ) button, LED Mode Indicator will cycle through the following light modes: 1st press: Mode 0, light off...
- Page 14 6. Use test light tool The static impulse generated by the Receiving Collar cannot be seen by naked eyes. To test whether the Static Shock Function works, we need to use the test light tool. • Put the test light on contact points on the receiving collar. •...
-
Page 15: Receiver Fitting Instructions
Receiver Fitting Instructions Please ensure that the receiving collar is fitted correctly. 1. Center the Contact Points under your dog’s neck(A). 2. Please adjust the sliders to have the receiving collar positioned snugly around your dog’s neck. Make sure that you can leave one finer between the strap and your dog’s neck(B). -
Page 16: Pairing Instructions
Pairing Instructions In the 1-receiving collar package, the receiver and transmitter are already factory-paired on CH1 by default. If you need to connect CH2/CH3 receiver, pls follow the steps below to pair with the transmitter. If not, you can skip this step. -
Page 17: How Does The Training Collar Work
How Does the Training Collar Work The Remote Training Collar has been proven to be a safe, comfortable, and effective training system for all dogs weighing over 15lbs. This system allows you to control your dog within a range up to 2600 feet. At the press of a button, the Remote Transmitter sends signal to the Receiving Collar and activates a Beep, a Vibration or a Static Shock correction output. -
Page 18: Frequently Asked Questions
Frequently Asked Questions : Why don’t the receiver and transmitter work? A: One reason maybe the transmitter and receiver are not turned on, please refer to the manual for the power-on operation. the other reason maybe that the transmitter and receiver batteries are exhausted, please fully charge them. : Once my dog is trained and has leaned to obey my commands, will he have to continue wearing the Receiving Collar? A: Probably not, although you may need to reinforce the training with the... -
Page 19: Troubleshooting
Troubleshooting I have fitted the Rechargeable and Waterproof Training Collar correctly, but my dog is not responding. • Ensure that the batteries are fully charged. You need to charge both the Remote Transmitter and the Receiving Collar for about 2.5 hours before they can be used for the first time. -
Page 20: Training Tips
Training Tips Here are some general tips for training your dog: • Eliminate one behavioral problem or teach one command at a time. If you move too fast with the training, your dog may become confused. Be consistent. Give your dog a single Beep, Vibration, or Static Shock for each misbehavior. •... -
Page 21: Common Sizes For Different Breeds Of Dogs
Common Sizes for Different Breeds of Dogs Back Length Sizes Neck(in) Chest(in) Type (in) Mini 7.8-8.6 9.8-11.8 Chihuahua,Yorkshire,Terrier Chihuahua,Yorkshire,Terrier Small 7.8-9.5 11.4-14.2 Poodle,Pomeranian Medium 9-11 13.7-16.5 Maltese Dog, Shin Tzu Miniature,Schnauzer, 10.6-12.2 16.2-18.5 12.2 Pekingese Schnauzer, English Cocker, Large 11.8-13.4 18.1-20.8 13.8 Spaniel 13-14.5 20.5-23.2... -
Page 22: Warranty
Warranty • 1-Year Warranty The original purchaser for this unit is provided with a 1-YEAR Warranty. The warranty begins on the date of purchase. For the first year, coverage is provided for both parts and labor on warranty repair services. After the first year, the Limited Lifetime Warranty covers parts only, and does not cover labor fees and Accessories. -
Page 23: Compliance Fcc -Usa
Compliance FCC - USA This device complies with part 15 of the FCC rules. Operation issubject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. CAUTION: Modification or changes to this equipment not expressly approved by the manufacturer may void the user's authority to operate the equipment. - Page 24 Shenzhen Xiaosi Technology Co., LTD service@jellypigpet.com Rm 513-515, BLDG B, Wepark, Rd 1Pinghu Str. , Longgang District.Shenzhen, China...
