THE PERFECT CONCENTRICITY GAGING SYSTEM
The Rollomatic "V-Block" Concentricity Pro is capable of mea-
suring the run-out on cylindrical components below .00004"
(1 micron) and can ideally be used in the cutting tool, punch-
ing, bar-turning, semi-conductor, automotive and aerospace
industries.
The combination of a special rotary drive (patent pending)
together with the traditional "zero-error" carbide V-block sys-
tem offers concentricity gaging for use on comparators or as
a free-standing unit with dial indicators or laser scanners.
ROLLOMATIC SA
Z.I. Prés Bugnons, CH-2525 Le Landeron SWITZERLAND
Phone +41 32-752-1700 / Fax +41 32-752-1717 / E-mail info@rollomatic.ch
VER. JANUARY 2002
Advertisement
Summary of Contents for ROLLOMATIC CONCENTRICITY PRO
- Page 1 THE PERFECT CONCENTRICITY GAGING SYSTEM The Rollomatic “V-Block” Concentricity Pro is capable of mea- suring the run-out on cylindrical components below .00004” (1 micron) and can ideally be used in the cutting tool, punch- ing, bar-turning, semi-conductor, automotive and aerospace industries.
- Page 2 THE PERFECT CONCENTRICITY GAGING SYSTEM The Rollomatic Concentricity Pro represents a totally new approach to concentricity gaging and provides guaranteed improvements in accuracy and efficiency. This quality inspection device is available in 3 versions: Version 1 As a stand-alone unit for comparators and contour projectors...
-
Page 3: Table Of Contents
CONCENTRICITY PRO INSTRUCTION MANUAL Table of Content CHAPTER 0 INTRODUCTION ................4 CHAPTER 1 CALIBRATION ................4 CHAPTER 2 USING THE CONCENTRICITY PRO ..........6 CHAPTER 3 CHANGING THE ”V” GUIDES ............7 CHAPTER 4 DRAWINGS ................. 9 CONCENTRICITY PRO–3... -
Page 4: Introduction
Several features of the ”Concentricity Pro” are being patented. The ”Concentricity Pro” is available as a separate instrument to be mounted on a profile projector, as a stand alone concentricity measuring station or with a steel base and a laser scanner. - Page 5 CONCENTRICITY PRO INSTRUCTION MANUAL PHOTO 1.1–B PRECISION STOPPER ROD TOOL ROTATION Ø 5 MM BLANK ”V” LOCK Space between two “V”–blocks PHOTO 1.1–C Approx. 25mm (1”) SCREW (Back of the silver stopper plate) The stopper rod has a ball shape end. The calibration procedure ensures...
-
Page 6: Using The Concentricity Pro
CONCENTRICITY PRO INSTRUCTION MANUAL CHAPTER 2. USING THE CONCENTRICITY PRO Before using the Concentricity Pro, clean well the tool to be measured. Place the shank of the tool to be measured under the silver colored stopper plate as shown on the photo 2.1–A. Slightly press the stopper plate and tighten the stopper lock. -
Page 7: Changing The "V" Guides
CONCENTRICITY PRO INSTRUCTION MANUAL CHAPTER 3. CHANGING THE “V“ GUIDES Move the “main” block to the very right, so that the pins of the block reach beyond the guide rail. PHOTO 3.1–A MAIN BLOCK “V” LOCK Fix the main block in position by tightening the “V” lock. Attach the front “V”... - Page 8 CONCENTRICITY PRO INSTRUCTION MANUAL Position the main block at the desired distance, attach the back “V” block and tighten the “V” lock. The “V” block is attached to the main block via the pins. PHOTO 3.1–C Fix the back “V” block in position by means of an allan screw.
-
Page 9: Drawings
CONCENTRICITY PRO INSTRUCTION MANUAL CONCENTRICITY PRO–9... - Page 10 CONCENTRICITY PRO INSTRUCTION MANUAL CONCENTRICITY PRO–10...
- Page 11 CONCENTRICITY PRO INSTRUCTION MANUAL CONCENTRICITY PRO–11...
- Page 12 CONCENTRICITY PRO INSTRUCTION MANUAL CONCENTRICITY PRO–12...
