AWNING POST SUPPORT: AWM60, AWM60A, AWM80, AWM80A, AWM100, AWM100A.
CAUTION. Read all instructions carefully before installing and using this product.
1. REQUIRED FOR INSTALLATION.
Threadlocker
Wrenches
Installation instruction
Awning post side mount kit.
Hole saw
Polyurethane marine sealant
Drill
(only for external installation)
rev. 07-2021
Non acidic degreaser
Anti-corrosion lubricant
Screwdriver and countersunk
screws Ø 5,5 mm
(only for external installation)
| P. 01 |
Advertisement
Table of Contents
Summary of Contents for seasmart AWM60
- Page 1 | P. 01 | rev. 07-2021 Installation instruction Awning post side mount kit. AWNING POST SUPPORT: AWM60, AWM60A, AWM80, AWM80A, AWM100, AWM100A. CAUTION. Read all instructions carefully before installing and using this product. 1. REQUIRED FOR INSTALLATION. Non acidic degreaser...
- Page 2 1. TEMPLATE. Mark the holes, and use a hole saw to cut hole for the socket of the mounting bracket. Type T min T max A min AWM60 Ø 32 mm 10 mm 44 mm 250 mm AWM60A Ø 32 mm...
- Page 3 Insert the socket inside the hole, and tighten the nut with the wrench. Remove the excess of marine sealant on the top. Type AWM60 / AWM80 / AWM100 40 mm 30 mm...
- Page 4 | P. 04 | rev. 07-2021 Installation instruction Awning post side mount kit. 2.2 EXTERNAL INSTALLATION (ONLY FOR AWM60A, AWM80A, AWM100A) Carefully clean the base of the socket with a non-acid degreasing agent. Then apply a small bead of marine sealant. Apply some anti-corrosion lubricant into the drilled hole.
- Page 5 | P. 05 | rev. 01-2021 52 mm BP20AX 64,5 mm...
