StellaHome
Antena
StellaHome
Exterior
1 Install the outdoor antenna in a location where you have good signal, outside and
high up on the building.
2 Using the supplied cable, connect the external antenna to the connector on the
right side of the repeater.
3 The repeater and antenna (s) should be located inside your building in the areas
where you want coverage.
4 Plug the 12V power supply into the wall socket. You should see the green signal bars
on the repeater light up. (See Indicator section below)
5 Finally, slowly rotate the external antenna towards your operators mast. Check the
signal bars on your phone inside the house. When you see maximum signal bars on
your phone, fix the antenna in this position.
• Use the sealing tape to seal the connector on the outdoor antenna to ensure it is waterproof.
• It is not necessary to install an external surge protector as this is built into the repeater.
• One internal antenna is connected directly to the repeater and therefore does not need a long cable.
• Make sure you get at least 2 bars of signal on your phone outside your house for this repeater to work
effectively.
• Permission from all cellular operators must be granted before the device is switched on. The repeater
must be installed by a mobile operator. This equipment requires a licence in all EU countries.
Antena
Power
12M External
Interior
Supply
Cable
1 Instruction manual EN
StellaOffice
StellaOffice
External
4X Internal
Antennas
Antenna
Power
Internal
15M External
Supply
cables
Cable
