Summary of Contents for Bondtech LGX Lite PRO
- Page 1 HOW TO Do regular maintenance on the LGX® Lite PRO Difficulty Medium Steps Time Required 10 to 15 min PRODUCT PAGE Sections...
- Page 2 Rotate the extruder 90 degrees counterclockwise remove the interface plug. and remove the middle section. Remove the drivegears, plastic washers and pins. Remove the extruder assembly from the motor. Remove the lever, double gear and spring from the back SLS piece. Page 2/7 www.bondtech.se...
- Page 3 Wipe off excess grease and solvent from the Apply a generous amount of grease to the motor Next, place the needle bearings on the drivegear needle bearings. Be careful to not loose needles. gear. pins and apply grease. Page 3/7 www.bondtech.se...
- Page 4 Insert the spring from the front of the SLS part. Add the double gear behind the spring. Shown here is the placement in the back. Push the double gear pin into the double gear. Add the right drivegear pin. Add the lever to the drivegear pin. Page 4/7 www.bondtech.se...
- Page 5 Add some more grease to the double gear as you Push the lever all the way to the left. Add the middle SLS part. see fit. Place the assembly on the motor. Page 5/7 www.bondtech.se...
- Page 6 We are available to help you with any questions or issues you may have. Simply go to our website where you can access our customer support and send us your questions or follow the provided link: https://www.bondtech.se/contact/#tab_technical-support-requests Page 6/7 www.bondtech.se...
