- 1 Step 1: Attach Lower Column to Base Plate with (2) Short Knobs
- 2 Step 2: Connect the Upper Column to the Lower Column Using (2) Short Knobs
- 3 Step 3: Attach Counter Legs to the Counter Top Using (2) Long Knobs Per Leg
- 4 Step 4: Attach the Canopy Support Bar
- 5 Step 5: Assemble the Canopy
- 6 Step 6: Attach the Canopy to the Support Arm
- 7 Step 7: Attach the Wings Using Gripper Knobs; Attach Canopy Header Using Standoffs
- Download this manual
Advertisement
Table of Contents
Related Manuals for exline KB.1
Summary of Contents for exline KB.1
- Page 1 KB.1 Assembly Instructions Step 1: Attach lower column to base plate with (2) Short Knobs; Cover with Gusset Caps Gusset Cap Short Knob Connect the upper column to the lower column Step 2: using (2) Short Knobs Short Knob...
- Page 2 KB.1 Assembly Instructions Attach counter legs to the counter top using (2) Step 3: Long Knobs per leg; Then, attach the counter to the columns using a Long Knob Long Knob Step 4: Attach the canopy support bar...
- Page 3 KB.1 Assembly Instructions Assemble the canopy Step 5: Long Knob Step 6: Attach the canopy to the support arm...
- Page 4 KB.1 Assembly Instructions Step 7: Attach the wings using Gripper Knobs; Attach canopy header using Standoffs Gripper Knob Finished...
