BICYCLE ELECTRIC CONVERSION PMDC SIDE MOTOR KIT (USER MANUAL) TABLE OF CONTENT PAGE NO. Disclaimer What's In the Box 04-05 Maintenance Troubleshooting 07-11 Warranty Warranty terms and conditions Enhance Your Technical Knowledge Safety of Use Contact Us (02)
Page 3: Disclaimer
DISCLAIMER The GEEKAY PMDC side Motor Kit is supplied as a set of do-it-yourself parts for the user to install on their bicycle. Because this kit is installed, maintained and operated by the purchaser, Rajesh Enterprises disclaims any responsibility for injury, damage or other consequences arising from the use of this product.
Page 4: What's In The Box
THE MARKET. YOUR BOX INCLUDES THE FOLLOWING ITEMS: 24V 250W PMDC SIDE MOTOR (PIC) GEEKAY has Geared PMDC Motor Systems which are the most Trusted & Powerful E Bike Systems Currently in the Market with all top of the Line Features & Excellent Fits.
Page 5 HIGH QUALITY PARTS GEEKAY electric conversion kits come with 78 link chain, 18T left thread free wheel & also 36 or 40 hole double thread hub. BATTERY & CHARGER (OPTIONAL) Geekay Battery chargers are smart CC-CV chargers and will automatically disconnect after the battery is fully charged.
Page 6: Maintenance
Experienced Bike or E-Bike Mechanic. Geekay Dealerships will ensure that before you buy, your bike is in tip-top shape from the moment you take it out of the store. This is especially important for E bikes as they need to be set up correctly to function properly.
Page 7: Troubleshooting
TROUBLESHOOTING THE TABLE BELOW IS BY NO MEANS A COMPREHENSIVE TROUBLESHOOTING GUIDE, BUT RATHER A GENERAL GUIDE FOR THE MOST COMMON ISSUES. EACH PROBLEM MUST BE LOOKED AT ON A CASE BY CASE BASIS PROBLEMS POSSIBLE REASONS CORRECTIVE ACTION Speed is too slow Low battery capacity Fully charge battery (less than 6Km/Hr)
Page 8 PROBLEMS POSSIBLE REASONS CORRECTIVE ACTION Driving range is very low. Tyre pressure too low Pump air in the tires. I.e. less than 10km Undercharged battery Recondition the battery by charging it for 12 hours and using it until completely drained. Repeat 3 times. Hill climbing, frequent stops, Try to avoid running on head wind, overloading...
Page 9 Driving range is very low. Check out battery voltage at I.e. less than 10km controller power input plugs. Contact your local dealer or Geekay customer service with the report of the above tests for battery repair or replacement. Front Light or keypad issues Check out related cables and connectors at handlebar.
Page 10 PROBLEMS POSSIBLE REASONS CORRECTIVE ACTION The system is on, but The brake cut-off might have The brake levers are not motor is not running problem properly installed or adjusted. using both throttle or To let the system rub, unplug pedal assist the brake sensors from the main controller.
Page 11 PROBLEMS POSSIBLE REASONS CORRECTIVE ACTION Motor making extra noise Normal when motor is loaded No action. on hills. Motor normal vibration is Try adjusting and ﬁxing loose causing resonance on other parts which cause vibration bicycle components such as disk brake rotor, fenders, etc Controller getting too hot Normal up to 70 Degree If more, try making some...
Page 12: Warranty
Please read our warranty terms and conditions. Geekay Dealerships will ensure that before you buy, your bike is in tip-top shape from the moment you take it out of the store. This is especially important for E bikes as they need to be set up correctly to function properly.
Page 13 In the case of use of the battery in systems that are not approved for such use with this particular product. In the case of the operation of the Geekay electric systems with batteries other than the batteries designed for the Geekay system (refer to user manual).
Page 14 REPAIRS Contact us and explain the problem with our experts. It might be resolved through a telephone discussion or email instructions provided to you. Sometimes something as simple as a loose connection or bad adjustment can cause failure. If there is a broken part that you have recognized yourself or with the help of our technician, we will simply send you the right part and you can replace it yourself.
Page 15: Enhance Your Technical Knowledge
100km will be about Rs 8. GEEKAY ELECTRIC CONVERSION PMDC SIDE MOTOR KIT MAINTENANCE No maintenance is required for Geekay electric Conversion PMDC side Motor Kits other than simple physical protections and keeping batteries fully charged after each use.
Page 16: Safety Of Use
SAFETY OF USE Once again we thank-you for choosing Geekay quality products. Our number one focus is to make you aware of the dangers of riding a bicycle and especially an electric bicycle so you can ensure you have safe and enjoyable riding experiences for years to come.
Page 17 There are risks associated with the use of any bicycle which cannot be predicted or avoided, and which may be caused and/or prevented through the actions of the rider, and which are the sole responsibility of the rider. You should save this Manual along with any other documents that were included with your bicycle purchase for future reference.
Page 18: Contact Us
CONTACT US Customer Care :- +91 82648 19999 Email:- Sales@geekaybikes.com Rajesh Enterprises B XXIX 92/1C/4, BMS Nagar, St no 2.5, Daba Road Ludhiana 141003, PB, India www.geekaybikes.com (18)
