DC PV Inverter Series Filters
FT130FD Series
Introduction
•
Rated current: 1A~2000A
•
Stud or terminal block optional ( ≥ 250A it is copper bar)
•
Could be customized according to the real interference
situation of customer's working eld
Features and Bene ts
•
Prevent the electromagnetic interference of solar panel and inverter towards each other.
•
Prevention of radiation o the panel.
•
Signi cantly increase the service life of solar panel.
•
E ectively reduce the interference of inverter towards solar panel.
•
Help PV system to comply with related EMC standards.
•
600VDC, 1200VDC or above high voltage versions available upon request.
•
Strict temperature rise control and much better performance than actually required assure product
reliability even under special working conditions.
Typical Applications
PV inverters
Completed EMC Solution Provider
Large DC motors
High current fast charging device and other DC applications
Advertisement
Table of Contents
Summary of Contents for filtemc FT130FD Series
- Page 1 DC PV Inverter Series Filters FT130FD Series Introduction • Rated current: 1A~2000A • Stud or terminal block optional ( ≥ 250A it is copper bar) • Could be customized according to the real interference situation of customer's working eld Features and Bene ts •...
- Page 2 DC PV Inverter Series Filters Technical Data Rated Voltage: VR 0~1600VDC Operating Frequency: FR Rated Current: I R 1~2000A@40℃ Test Voltage: Vtest 2000VDC, 3S(line-line); 2000VDC, 3S(line-ground) Climatic Category (IEC 60068-1) 25/085/21(-25℃/+85℃Damp heat test for 21 days) Tabulates Terminals Rated Part No. Weight [g] Current [A] FT130FD-65...
- Page 3 DC PV Inverter Series Filters 9±0.5 6±0.5 10.1±0.5 4-M10 116±0.5 30±0.5 50±0.5 200±2 276 MAX. 82 MAX. FT130FD-150 2-M8 2- 10±0.5 418±2 452 MAX. 6- 12±0.5 42±2 8±0.5 70±0.5 290±0.5 134±0.5 350±2 164 MAX. FT130FD-630 2-M8 4- 12±0.5 50±0.5 394±2 456±2 487 MAX.
- Page 4 DC PV Inverter Series Filters Important Notes on EMI Filter Application 1. Storage of EMI Filters: EMI lters mustn't be left out in the heat of the sun or exposed to the rain, it should be stored in warehouse with good ventilation, surrounding temperature between -30℃...
- Page 5 DC PV Inverter Series Filters 3. Reminding and Warning： Please read all the safety warnings and instructions before installing lters and putting them into use: • Don't take terminals as supporting point when moving filters to avoid the terminals distortion, loosening or broken.
