Questo manuale d'istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per
BRR29703EWW
Refrigerator
(Larder)
User manual (without Freezer box)
BRR29*
SEUK
Built-in Appliance
Untitled-3 1
o cerca il tuo prodotto tra le
migliori offerte di Frigoriferi e Congelatori
Samsung
2022-11-25
11:42:55
Advertisement
Table of Contents
Related Manuals for Samsung BRR29703EWW
Summary of Contents for Samsung BRR29703EWW
- Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Samsung BRR29703EWW o cerca il tuo prodotto tra le migliori offerte di Frigoriferi e Congelatori Refrigerator (Larder) User manual (without Freezer box) BRR29* SEUK Built-in Appliance Untitled-3 1...
-
Page 2: Table Of Contents
Contents Safety information What you need to know about the safety instructions Important safety symbols and precautions: Important safety precautions Severe warning signs for transportation and site Critical installation warnings Installation cautions Critical usage warnings Usage cautions Cleaning cautions Critical disposal warnings Additional tips for proper usage Instructions about the WEEE Installation... -
Page 3: Safety Information
Safety information Before using your new Samsung Refrigerator, please read this manual thoroughly to ensure that you know how to operate the features and functions that your new appliance offers safely and efficiently. What you need to know about the safety instructions •... - Page 4 Safety information • Never start up an appliance showing any signs of damage. If in doubt, consult your dealer. The room must be 1 m in size for every 8 g of R-600a refrigerant inside the appliance. The amount of refrigerant in your particular appliance is shown on the identification plate inside the appliance.
-
Page 5: Important Safety Symbols And Precautions
- If the refrigerating appliance is left empty for long periods, power off, defrost, clean, dry, and leave the door open to prevent mould developing within the appliance. Important safety symbols and precautions: Please follow all safety instructions in this manual. This manual uses the following safety symbols. -
Page 6: Important Safety Precautions
Safety information Important safety precautions WARNING; Risk of fire / Flammable materials WARNING • When positioning the appliance, ensure the supply cord is not trapped or damaged. • Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance. •... - Page 7 • If the product is equipped with LED lamps, do not disassemble the Lamp Covers and LED lamps yourself. - Contact a Samsung service center. - Use only the LED Lamps provided by the manufacturer or its service agents.
- Page 8 Safety information • To get the best energy efficiency of this product, please leave all shelves, drawers and baskets on their original position. How to minimize the energy consumption • Install the appliance in a cool, dry room with adequate ventilation.
-
Page 9: Severe Warning Signs For Transportation And Site
• Select 560 mm cavity depth. A smaller cavity depth will result in a higher energy consumption. This appliance is intended to be used in household and similar applications such as - staff kitchen areas in shops, offices and other working environments;... -
Page 10: Critical Installation Warnings
Safety information - This appliance contains a small amount of isobutane refrigerant (R-600a), a natural gas with high environmental compatibility that is, however, also combustible. When transporting and installing the appliance, care should be taken to ensure that no parts of the refrigerating circuit are damaged. - Page 11 • Do not bend the power cord excessively or place heavy objects on it. • Do not pull or excessively bend the power cord. • Do not twist or tie the power cord. • Do not hook the power cord over a metal object, place a heavy object on the power cord, insert the power cord between objects, or push the power cord into the space behind the appliance.
- Page 12 Safety information • Connect the power plug in the proper position with the cord hanging down. - If you connect the power plug upside down, the wire can get cut off and cause a fire or electric shock. • Make sure that the power plug is not crushed or damaged by the back of the refrigerator.
- Page 13 • The refrigerator must be safely grounded. - Always make sure that you have grounded the refrigerator before attempting to investigate or repair any part of the appliance. Power leakages can cause severe electric shock. • Never use gas pipes, telephone lines, or other potential lightning attractors as an electrical ground.
-
Page 14: Installation Cautions
Safety information Installation cautions CAUTION • Allow sufficient space around the refrigerator and install it on a flat surface. - If your refrigerator is not level, cooling efficiency and durability can be declined. • Allow the appliance to stand for 2-3 hours before loading foods after installation and turning on. - Page 15 • Do not touch the inside walls of the freezer or products stored in the freezer with wet hands. (applicable models only) - This may cause frostbite. • Do not put a container filled with water on the refrigerator. - If spilled, there is a risk of fire or electric shock. •...
- Page 16 - Products that require strict temperature controls must not be stored in the refrigerator. • If you smell pharmaceutical or smoke, pull out power plug immediately and contact your Samsung Electronics service center. • If any dust or water is in Refrigerator, pull out power plug and contact your Samsung Electronics service center.
- Page 17 • Do not use a hair dryer to dry the inside of the refrigerator. Do not place a lighted candle in the refrigerator for removing bad odours. - This may result in an electric shock or fire. • Do not stand on top of the appliance or place objects (such as laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance.
- Page 18 • If the refrigerator emits a burning smell or smoke, unplug the refrigerator immediately and contact your Samsung Electronics service center. - Failing to do so may result in an electric or fire hazards.
-
Page 19: Usage Cautions
Usage cautions CAUTION • Do not refreeze thawed food. - Frozen and thawed food will develop harmful bacteria faster than fresh. - The second thaw will break down even more cells, leaching out moisture and changing the integrity of the product. - Page 20 • When the refrigerator got wet by water, pull out the power plug and contact your Samsung Electronics service center. • Do not strike or apply excessive force to any glass surface. - Broken glass may result in a personal injury or property damage.
-
Page 21: Cleaning Cautions
• If the refrigerator is flooded, make sure to contact your nearest service center. - There is a risk of electric shock or fire. • Do not keep vegetable oil in your refrigerator’s door bins. The oil can solidify, making it foul-tasting and difficult to use. - Page 22 Safety information • Use a clean, dry cloth to remove any foreign matter or dust from the power plug blades. Do not use a wet or damp cloth when cleaning the plug. - Otherwise, there is a risk of fire or electric shock. •...
-
Page 23: Critical Disposal Warnings
Critical disposal warnings WARNING • Please dispose of the packaging material from this product in an environmentally friendly manner. • Ensure that none of the pipes on the back of the refrigerator are damaged prior to disposal. • When disposing of this refrigerator, remove the door/ door seals and door latch so that small children or animals cannot become trapped inside. -
Page 24: Additional Tips For Proper Usage
Safety information Additional tips for proper usage • In the event of a power failure, call the local office of your electric company and ask how long the failure is going to last. - Most power failures that are corrected in an hour or two will not affect your refrigerator temperatures. - Page 25 • The temperature of two star section (sections) or compartment (compartments) which have two star symbol ) is slightly higher than other freezer compartment (compartments). The two star section (sections) or compartment (compartments) is (are) based on the instruction and/or the condition as delivered.
-
Page 26: Instructions About The Weee
This product and its electronic accessories should not be mixed with other commercial wastes for disposal. For information on Samsung’s environmental commitments and product regulatory obligations, e.g. REACH, WEEE or Batteries, visit our sustainability page available via www.samsung.com... -
Page 27: Installation
Installation Follow these instructions carefully to ensure a proper installation of this refrigerator and to prevent accidents before using it. WARNING • Use the refrigerator only for its intended purpose as described in this manual. • Any servicing must be performed by a qualified technician. •... -
Page 28: Step-By-Step Installation
Installation Step-by-step installation STEP 1 Select a site Site requirements: • Solid, level surface without carpeting or flooring that may obstruct ventilation • Away from direct sunlight • Adequate room for opening and closing the door • Away from a heat source •... - Page 29 Product Overall Dimension BRR29*1* BRR29*0* BRR29*2* Model Sliding hinge type Fixed or Soft closing hinge type 01 * 10 (Min.) / 30 (Recommended) 115° 95° (Recommended) (Recommended) 1055 1055 * 01: From cabinet to rear of product. (unit : mm) NOTE •...
- Page 30 Installation Ventilation system of the cabinet As shown in the figure, the air entering the refrigerator circulates along the ventilation path (see the arrow direction) of the cabinet. The cabinet must have at least 200 cm (WxH: 500 mm x 40 mm) of space both for the air inlet and air outlet. Also, the cabinet must have a rear vent of at least 200 cm (WxH: 500 mm x 40 mm) of space at the rear bottom.
- Page 31 Cabinet dimension CAUTION If the cabinet has a door, make sure the door is not heavy to prevent it from tipping or falling off. Thickness (mm) Weight (kg) Min. 16 Max. 28 Max. 19 Any product failure because of the following is not covered by the Warranty.
- Page 32 Installation Consideration for socket outlet location and required space Min. 590 Min. 560 Min. 580 (unit : mm) NOTE If you install the refrigerator in a cabinet with a 560 mm depth, make sure the power cord is arranged on a side of the refrigerator before plugging into a power socket.
- Page 33 Cabinet type The recommended cabinet type is one of the following: NOTE If using any of these cabinet types, you don't need to remove the main unit from the cabinet for servicing a defective main PBA. If using another cabinet type, you must remove the main unit from that cabinet for servicing.
- Page 34 Installation BRR29*1* BRR29*0* BRR29*2* Model Sliding hinge type Fixed or Soft closing hinge type 1775+A+B A. Lower edge of the front panel above the air ventilation B. Front panel overhang STEP 2 Flooring • The surface to install the refrigerator must support a fully loaded refrigerator.
- Page 35 STEP 3 Spacing (applicable models only) Attach the provided spacers (A) and the sponge (B) as shown in the figure to for optimal energy efficiency. CAUTION If the refrigerator is not flush with the cabinet, you may cut the spacers to make the refrigerator flush with the cabinet, but the optimal energy efficiency cannot be guaranteed.
- Page 36 Installation STEP 4 Adjust the levelling legs CAUTION • The refrigerator must be levelled on a flat, solid floor. Failing to do so can cause damage to the refrigerator or physical injury. • Levelling must be performed with an empty refrigerator. Make sure no food items remain inside the refrigerator.
- Page 37 STEP 5 Initial settings By completing the following steps, the refrigerator should be fully functioning. 1. Remove the PE foam sheet on each shelf corner, which is attached to protect the refrigerator during transportation. 2. Open the door, and check if the interior light lights up. 3.
-
Page 38: Operations
Operations Main panel 01 Fridge / Vacation 02 Door Alarm 03 Network connection * (Power) * applicable models only NOTE • If the door is left open for 5 minutes, the interior light will blink for 5 minutes and turn off. It is to alert deaf and hard of hearing users that a door is open. Note that this function is normal. - Page 39 01 Fridge / Vacation (3 sec) To adjust the fridge temperature, press Fridge to select the corresponding temperature. You can change the temperature between 1 °C and 7 °C (default: 3 °C). Power Cool Power Cool speeds up the cooling process at maximum fan speed. The fridge keeps running at full speed for two and a half hours and then returns to the previous temperature.
- Page 40 Operations 02 Door Alarm You can set the alarm for a reminder. If the door is left open for more than 2 minutes, the alarm will sound with the Alarm indicator blinking. You can switch to enable and disable the alarm by pressing Door Alarm. 03 Network connection * This icon indicates that the refrigerator is connected to a network.
-
Page 41: Smartthings (Applicable Models Only)
• Unauthorized Wi-Fi wireless routers may fail to connect to applicable Samsung Smart Refrigerators. Samsung account You are required to register your Samsung account to use the app. If you don’t have a Samsung account, follow the app’s on-screen instructions to create a free Samsung account. English... - Page 42 Operations Getting started Turn on the device you want to connect, open the SmartThings app on your phone, and then follow the instructions below. If a pop-up appears saying that a new device has been found, tap ADD NOW. If a pop-up doesn't appear, tap the + button, and then select the device you want to connect from the list of available devices.
-
Page 43: Maintenance
Maintenance Handle and care Shelves / Shelf Wine (applicable models only) • Pull out the shelf (or shelf wine) a little. Then, while lifting the rear side, pull out. • Twist the shelf (or shelf wine) diagonally to remove. CAUTION •... - Page 44 Maintenance Door bins Hold the door bin with both hands, and then lift up to remove. CAUTION To prevent accidents, empty the door bins before removing Drawers Gently lift up the front of the drawer and slide out. English Untitled-3 44 2022-11-25 11:42:59...
-
Page 45: Cleaning
4. Plug in the power cord. Replacement LED Lamps To replace the lamps of the refrigerator, contact a local Samsung service centre. WARNING • The lamps are not user-serviceable. Do not attempt to replace a lamp yourself. This can cause electric shock. -
Page 46: Troubleshooting
Troubleshooting Before calling for service, review the checkpoints below. Any service calls regarding normal situations (No Defect Cases) will be charged to users. General Temperature Symptom Possible causes Solution • Power cord is not plugged in • Properly plug in the power properly. - Page 47 Odors Symptom Possible causes Solution • Clean the refrigerator and • Spoiled food. remove any spoiled food. Refrigerator has odors. • Make sure strong smelling • Food with strong odors. food is wrapped airtight. Frost Symptom Possible causes Solution Frost around the •...
-
Page 48: Do You Hear Abnormal Sounds From The Refrigerator
Troubleshooting Do you hear abnormal sounds from the refrigerator? Before calling for service, review the checkpoints below. Any service calls related to normal sounds will be charged to the user. These sounds are normal. • When starting or ending an operation, the refrigerator may make sounds similar to a car engine igniting. - Page 49 • As the refrigerator cools or freezes, refrigerant gas moves through sealed pipes, causing bubbling sounds. Bubbling! • As the refrigerator temperature increases or decreases, plastic parts contract and expand, creating knocking noises. These noises occur during the defrosting cycle or when electronic parts are working.
-
Page 50: Smartthings (Applicable Models Only)
• The old Samsung Smart Refrigerator app cannot connect with Samsung Smart Home models. • You must log into your Samsung account to use the app. • Make sure that your router is operating normally. The SmartThings •... -
Page 51: Appendix
Appendix Safety Instruction • For the most efficient use of energy, please keep the all inner fittings such as baskets, drawers, shelves and ice cube tray on the position supplied by manufacturer. Install Instruction For refrigerating appliances with climate class Depending on the climate class, This refrigerating appliance is intended to be used at ambient temperatures range as specified following table. -
Page 52: Temperature Instruction
Appendix Temperature Instruction Recommended Temperature The optimal temperature setting for food storage: • Fridge: 3 °C NOTE The optimal temperature setting of each compartment depends on the ambient temperature. Above optimal temperature is based on the ambient temperature of 25 °C. Power Cool (applicable models only) Power Cool speeds up the cooling process at maximum fan speed. - Page 53 Don’t store perishable foods in the door. Eggs should be stored in the carton on a shelf. The temperature of Stored on the door the storage bins in the door fluctuate more than the temperature in the cabinet. Keep the door closed as much as possible.
- Page 54 Appendix Poultry / Eggs Product Refrigerator Freezer Fresh poultry 2 days 6-8 months Poultry salad 1 day Eggs, Fresh in shell 2-4 weeks Not recommended Fish / Seafood Product Refrigerator Freezer Fresh fish 1-2 days 3-6 months Cooked fish 3-4 days 1 month Fish salad 1 day...
-
Page 55: Information For Model And Ordering Spare Parts
24 Months. • Relevant information for ordering spare parts, directly or through other channels provided by the manufacturer, importer or authorized representative • You can find professional repair information on http://samsung.com/support. You can find user servicing manual on http://samsung.com/support. English... -
Page 56: Open Source Announcement
Open Source Announcement The software included in this product contains open source software. The following URL http://opensource.samsung.com/opensource/SMART_TP1_0/seq/0 leads to open source license information as related to this product. English Untitled-3 56 2022-11-25 11:43:00... - Page 57 Memo Untitled-3 57 2022-11-25 11:43:00...
- Page 58 Memo Untitled-3 58 2022-11-25 11:43:00...
- Page 59 Memo Untitled-3 59 2022-11-25 11:43:00...
- Page 60 2412 - 2472 MHz 20 dBm Bluetooth 2402 - 2480 MHz 20 dBm Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. Country Contact Center Web Site 0333 000 0333 www.samsung.com/uk/support...
