- Page 2 FOLLOW THIS STEPS FOR BUILDING THIS KIT 1. Prepare the parts to begin the assembly 2. Solder the power connector and the proccess. 4 multiturn trimmers. 3. Solder the 2 pin male connector. 4. Attach both PCB´s with female/male connectors and metal spacers, then solder them.
- Page 3 FOLLOW THIS STEPS FOR BUILDING THIS KIT 8. Before proceeding to solder the mechanics make sure pots are lifted, faders 7. Place the panel, screw 3 jacks nuts, 4 pot and buttons are completly down. nuts, the small screw, all circled in yellow. Solder 1 pin of each btn and slider to easily adjust them if needed.
