PLUMBING & GAS
Product Number: 1811162
BROMIC PRO OXYSET
2.2L BRAZING SYSTEM
OPERATOR'S MANUAL
BROMIC Plumbing & Gas
10 Phiney Place, Ingleburn NSW 2565 Sydney Australia
Telephone: 1300 276 642 (AU) 0508 276 642 (NZ)
Email: plumbing@bromic.com Web: bromicplumbing.com
A member of the Bromic Group
09/2021 - V1
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for Bromic Heating PRO OXYSET
- Page 1 PLUMBING & GAS Product Number: 1811162 BROMIC PRO OXYSET 2.2L BRAZING SYSTEM OPERATOR’S MANUAL BROMIC Plumbing & Gas 10 Phiney Place, Ingleburn NSW 2565 Sydney Australia Telephone: 1300 276 642 (AU) 0508 276 642 (NZ) Email: plumbing@bromic.com Web: bromicplumbing.com A member of the Bromic Group...
- Page 2 Part No. 1811162 Pro Oxyset 2.2L Operator’s Manual ATTENTION - THIS PRODUCT IS FOR INDUSTRIAL USE The following instructions must be read carefully and adhere to before using the OXYSET 1811162 (which will henceforth be referred to as ‘kit’) and keep the manual for future reference.
- Page 3 Part No. 1811162 Pro Oxyset 2.2L Operator’s Manual CONTENTS 1. General Warnings 2. Safety Information 3. List of Components 4. Technical Specifications 5. How to gas weld 6. Operating instructions 10-11 7. Maintenance Sydney Office: 10 Phiney Place, Ingleburn NSW 2565 Australia Telephone: 1300 276 642 (AU) 0508 276 642 (NZ) Email: plumbing@bromic.com...
- Page 4 Part No. 1811162 Pro Oxyset 2.2L Operator’s Manual Hazard Prevention • Always guard against flammable substances, burns, fluxes, filler metals, gases, and fumes. • Never use oxygen or fuel gas to blow off work, equipment, or clothing. Pure oxygen encourages combustion, and gas is flammable.
- Page 5 Part No. 1811162 Pro Oxyset 2.2L Operator’s Manual Ventilation • Adequate ventilation must be provided for all welding, cutting, brazing, and related operations. • Adequate ventilation must be enough such that any hazardous concentrations of airborne contaminants exposed to personnel are maintained below the allowable limits specified by the authority having jurisdiction.
- Page 6 Part No. 1811162 Pro Oxyset 2.2L Operator’s Manual Supervision This section pertains the commercial use of the product. Management refers to people responsible for welding operations, while supervisors refer to people responsible for the supervision of welding. Responsibilities Operators and management are both responsible for safety in welding and cutting.
- Page 7 1 x Goggles Introduction The PRO OXYSET 1811162 is fuelled by disposable oxygen cylinder (T-PED approval number 0036) and a disposable MAP//Pro cylinder (complying with DOT39). We recommend using Bromic oxygen cylinders (P/N 1811322) and Bernzomatic MAP//Pro cylinders (P/N 1811120).
- Page 8 Part No. 1811162 Pro Oxyset 2.2L Operator’s Manual Putting into service 1. Ensure that the seals/connections, hoses and general appliance are damage free 2. Ensure that the adjustment knobs on the pressure regulators (5&6) are closed by turning the regulator knobs ANTI CLOCKWISE.
- Page 9 Part No. 1811162 Pro Oxyset 2.2L Operator’s Manual How to gas weld WARNINGS: a) We recommend to preset regulators’ output pressure to minimum 0.5 bar for gas pressure regulator; and 4 bar for oxygen pressure regulator. b) The maximum working pressure should NEVER exceed 0.9 bar for gas pressure regulator;...
- Page 10 Part No. 1811162 Pro Oxyset 2.2L Operator’s Manual Gas Flow Valve Oxygen Flow Valve Light the torch Ignite using a spark lighter (11), paying attention to keep the flame stuck to the soldering nozzle until you achieve a flame as shown. If the flame comes away from the nozzle and blows out, close the gas knob slightly to slow supply.
- Page 11 Part No. 1811162 Pro Oxyset 2.2L Operator’s Manual Switching off Complete the following steps in order. Close the torch’s oxygen flow valve by turning the knob CLOCKWISE Close the torch’s gas flow valve by turning the knob CLOCKWISE Close the oxygen regulator valve by turning the knob ANTI CLOCKWISE Close the gas regulator valve by turning the knob ANTI CLOCKWISE Purge the system of all remaining gas and let the torch cool down.
- Page 12 Part No. 1811162 Pro Oxyset 2.2L Operator’s Manual Storage If the OXYSET is not in use, disconnect all components from each other and allow all the system to drain. This will avoid cylinder discharge as a result of imperceptible leaks.
- Page 13 Australia 10 Phiney Place Ingleburn NSW 2565 Sydney AUSTRALIA Telephone: +61 2 9426 5222 BROMICPLUMBING.COM 09/2021 - V1...
