Preliminary Specification Number :SP-ZZ1WL-857
LoRa + Wi-Fi + Bluetooth + GNSS Module Data Sheet
Semtech LR1110 Chipset for 802.11 b/g/n (sniff),LoRa, GNSS
ST Micro STM32WB55VGY6 Chipset for MCU and BT
Design Name: Type1WL
Sample Part Number: LBEU5ZZ1WL-857SMP
MP Part Number: LBEU5ZZ1WL-857
This Datasheet is preliminary version, and subject
to change without notice
Preliminary & Confidential
< Specification may be changed by Murata without notice >
Murata(China) Investment Co., Ltd.
Advertisement
Table of Contents
Summary of Contents for Murata LBEU5ZZ1WL-857SMP
- Page 1 ST Micro STM32WB55VGY6 Chipset for MCU and BT Design Name: Type1WL Sample Part Number: LBEU5ZZ1WL-857SMP MP Part Number: LBEU5ZZ1WL-857 This Datasheet is preliminary version, and subject to change without notice Preliminary & Confidential < Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
- Page 2 First release 2022-09-21 Added the weight information. Update Updated the laser mark information on top side Changed sample par number and EVK part number Preliminary & Confidential < Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
-
Page 3: Table Of Contents
PRECONDITION TO USE OUR PRODUCTS ........21 Please be aware that an important notice concerning availability, standard warranty and use in critical applications of Murata products and disclaimers thereto appears at the end of this specification sheet. Preliminary & Confidential <... -
Page 4: Scope
LBEU5ZZ1WL-857 Mass Produced Product “Type1WL” is design name of this module. Design name may be used in certification test report. 3. Block Diagram Preliminary & Confidential < Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd. -
Page 5: Certification Information
4 / 23 4. Certification Information 4.1. Radio Certification USA/Canada FCC ID *Please follow installation manual in Appendix Europe Japan 4.2. Bluetooth® Qualification QDID: T.B.D. Preliminary & Confidential < Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd. -
Page 6: Dimensions, Marking And Terminal Configurations
0.50±0.10 0.80±0.10 0.20±0.15 1.875±0.150 4.10±0.15 4.50±0.15 0.20±0.15 1.70±0.15 4.35±0.15 0.80±0.10 0.80±0.10 0.80±0.10 0.35±0.10 0.35±0.10 0.80±0.10 0.80±0.10 2.15max Note: The laser mark is temporary. Preliminary & Confidential < Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd. -
Page 7: Pin Layout And Descriptions
STM32 BOOT0 pin. At start up, BOOT0 pin and BOOT1 option bit are used to select three boot option: Boot from user flash:(BOOT1:x, BOOT0:0) Boot from system memory: (BOOT1:0, Preliminary & Confidential < Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd. - Page 8 LPUART of STM32 USR_ADC AI/O STM32: PA0 Analog IO GPIO10 STM32: PC11 General purpose I/O I2C_INT2 STM32: PC3 Interrupt for I2C sensor Ground Preliminary & Confidential < Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
-
Page 9: Absolute Maximum Ratings
-0.3 Supply Voltage VDD_GNSS -0.3 VDD_GNSS_BU -0.3 7. OPERATING CONDITION Parameter min. typ. max. unit Operating Temperature deg.C VDD_3V3 Supply Voltage VDD_GNSS VDD_GNSS_BU Preliminary & Confidential < Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd. -
Page 10: Rf Characteristics
RxBoost ON Supply current in receiver BW = 125 kHz LoRa mode, RxBoost off IDDR_L BW = 250 kHz BW = 500 kHz Preliminary & Confidential < Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd. -
Page 11: Rf Characteristics For Wi-Fi Passive Scanner
Wi-Fi sensitivity for Wi-Fi RXSWFN1 802.11 n, OFDM, 20MHz BPSK, CR = 1/2, DR = 7.2 Mb/s channel spacing, short guard interval Preliminary & Confidential < Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd. -
Page 12: Rf Characteristics For Ble
RF BLE current consumption Symbol Parameter Typ. Unit TX maximum output Itxmax power consumption TX 0 dBm output power Itx0dbm consumption Irxlo Rx consumption Preliminary & Confidential < Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd. -
Page 13: Rf Characteristics For Gnss
GPS, indoor classification, and strong signal SV RXSGPS1E capture RXSGPS2E GNSS sensitivity GPS, weak signal SV capture RXSBEI1E BeiDou, strong signal SV capture RXSBEI2E BeiDou, weak signal SV capture Preliminary & Confidential < Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd. -
Page 14: Land Pattern (Top View)
Preliminary Specification Number : SP-ZZ1WL-857 13 / 23 9. LAND PATTERN (TOP VIEW) Preliminary & Confidential < Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd. -
Page 15: Reference Circuit
CON1 epad epad epad epad nReset_ST epad epad SWDIO epad epad SWCLK CON4 VDD33 4.7uF 0.1uF Preliminary & Confidential < Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd. -
Page 16: Tape And Reel Packing
Preliminary Specification Number : SP-ZZ1WL-857 15 / 23 11. TAPE AND REEL PACKING 11.1. Dimension of Tape 11.2. Dimensions of Reel (unit: mm) Preliminary & Confidential < Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd. -
Page 17: Taping Diagrams
[3] Cover tape : 62μMin thickness [4] Base tape : As specified in (1) Feeding Hole Feeding Direction Chip 11.4. Leader and Tail Tape Preliminary & Confidential < Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd. - Page 18 Packaging (Humidity proof Packing) Tape and reel must be sealed with the anti-humidity plastic bag. The bag contains the desiccant and the humidity indicator. Preliminary & Confidential < Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
-
Page 19: Notice
All the ground terminals should be connected to the ground patterns. Furthermore, the ground pattern should be provided between IN and OUT terminals. Please refer to the specifications for the standard land dimensions. Preliminary & Confidential < Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd. -
Page 20: Notice For Chip Placer
Preliminary Specification Number : SP-ZZ1WL-857 19 / 23 The recommended land pattern and dimensions is as Murata's standard. The characteristics of products may vary depending on the pattern drawing method, grounding method, land dimensions, land forming method of the NC terminals and the PCB material and thickness. Therefore, be sure to verify the characteristics in the actual set. -
Page 21: Cleaning
- Humid place where water condenses. - Freezing place. If there are possibilities for products to be used under the preceding clause, consult with Murata before actual use. As it might be a cause of degradation or destruction to apply static electricity to products, do not apply static electricity or excessive voltage while assembling and measuring. -
Page 22: Precondition To Use Our Products
Please do not use our products, our technical information and other data provided by us for the purpose of developing of Preliminary & Confidential < Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd. - Page 23 -improper use of engineering samples. We disclaim any liability for consequential and incidental damages. If you can’t agree the above contents, you should inquire our sales. Preliminary & Confidential < Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
- Page 24 Preliminary Specification Number : SP-ZZ1WL-857 23 / 23 Appendix Preliminary & Confidential < Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
