welcoming
WALL CABINET
MODEL # 1116WC-26-201; 1116WC-26-202;
1116WC-26-242; 1116WC-26-320
ATTACH YOUR RECEIPT HERE
Serial Number__________________ Purchase Date__________________
Questions, problems, missing parts? Before returning to your retailer, call our customer service
department at 1-866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Sunday.
•
MODEL NUMBER DESCRIPTION
1116WC-26-201
1116WC-26-202
1116WC-26-242
1116WC-26-320
sophisticated
26" White Finish Wall Cabinet
26" Mahogany Finish Wall Cabinet
26" Light Gray Finish Wall Cabinet
26" Flaxen Finish Wall Cabinet
•
inspiring
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Allen + Roth 1116WC-26-320
Summary of Contents for Allen + Roth 1116WC-26-320
- Page 1 1116WC-26-320 26" Flaxen Finish Wall Cabinet WALL CABINET MODEL # 1116WC-26-201; 1116WC-26-202; 1116WC-26-242; 1116WC-26-320 ATTACH YOUR RECEIPT HERE Serial Number__________________ Purchase Date__________________ Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Sunday.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Package Contents...........................3 Hardware Contents..........................3 Safety Information..........................4 Preparation ............................4 Assembly or Installation Instructions .....................4 Care and Maintenance ........................7 Warranty ............................7 Replacement Parts List ........................ . 8... -
Page 3: Package Contents
PACKAGE CONTENTS PART DESCRIPTION QUANTITY Cabinet Wall Bracket Shelf Left Door (preassembled to Cabinet (A)) Right Door (preassembled to Cabinet (A)) HARDWARE CONTENTS HARDWARE CONTENTS (NOT SHOWN ACTUAL SIZE) Shelf pin Qty. 8 Touch-up pen Qty. 1... -
Page 4: Safety Information
SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install this product. WARNING • Some steps are more easily handled with two adults. CAUTION • Before installation, carefully use scissors or utility knife to cut and unwrap all parts. Make sure you DO NOT discard the hardware. - Page 5 INSTALLATION INSTRUCTIONS 2. Using hardware appropriate for your wall type (not included), secure the Wall Bracket (B) to the wall into preferably 2 wall studs. Use hardware such as a cabinet screw or toggle bolt depending on your wall type. Make sure the Wall Bracket (B) is level and centered well to the desired location of the Cabinet (A).
- Page 6 INSTALLATION INSTRUCTIONS 4. Insert shelf pins (BB) at desired height, ensuring they are level. Place shelves (C) on top of shelf pins (BB). Hardware Used Shelf Pin 5. If you need to adjust the doors, do so in the following manner. To adjust door up or down, loosen screws (a) on both hinges, adjust door, and retighten screws.
-
Page 7: Care And Maintenance
CARE AND MAINTENANCE • Dust the Wall cabinet regularly with a soft, non-lint producing cloth or household dusting product. • You can clean the Wall cabinet with a gentle, non-abrasive household cleaner. • Make sure to dry the wood immediately with a soft cloth or towel. •... -
Page 8: Replacement Parts List
REPLACEMENT PARTS LIST FOR 1116WC-26-201 For replacement parts, call our customer service department at 1-866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Sunday. PART DESCRIPTION PART# 1116WC-26-201-001 Wall Bracket Shelf 1116WC-26-201-002 Left Door 1116WC-26-201- 003/004 Right Door Touch-up pen OF-0010 Shelf pin B1044... - Page 9 REPLACEMENT PARTS LIST FOR 1116WC-26-202 For replacement parts, call our customer service department at 1-866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Sunday. PART DESCRIPTION PART# 1116WC-26-202-001 Wall Bracket Shelf 1116WC-26-202-002 Left Door 1116WC-26-202- 003/004 Right Door Touch-up pen W3350A Shelf pin B1044...
- Page 10 REPLACEMENT PARTS LIST FOR 1116WC-26-242 For replacement parts, call our customer service department at 1-866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Sunday. PART DESCRIPTION PART# 1116WC-26-242-001 Wall Bracket Shelf 1116WC-26-242-002 Left Door 1116WC-26-242- 003/004 Right Door Touch-up pen OF-0120R Shelf pin B1044...
- Page 11 REPLACEMENT PARTS LIST FOR 1116WC-26-320 For replacement parts, call our customer service department at 1-866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Sunday. PART DESCRIPTION PART# 1116WC-26-320-001 Wall Bracket Shelf 1116WC-26-320-002 Left Door 1116WC-26-320- 003/004 Right Door Touch-up pen...
