eKids 555 Series Quick Start Manual

Bluetooth mp3 karaoke with light show
Table of Contents
  • Utilisation du Mode Bluetooth
  • Dépannage
  • Entretien
  • Erste Schritte
  • Verwendung des USB-Modus
  • Problembehandlung
  • Problemas y Soluciones
  • Mantenimiento
  • Problemen Oplossen
  • Rozwiązywanie Problemów

Advertisement

Available languages
  • EN

Available languages

  • ENGLISH, page 1

Quick Links

This product bears the selective sorting symbol for waste electrical and electronic equipment (WEEE).
This means that this product must be handled pursuant to European Directive 2012/19/EU in order to be recycled or dismantled to minimize
its impact on the environment.
For further information, please contact your local or regional authorities.
Electronic products not included in the selective sorting process are potentially dangerous for the environment and human health due to the
presence of hazardous substances.
CHARGE BEFORE USE
Getting Started
There are two ways to listen to music with this unit:
• In USB Mode you can connect a flash drive (not included) to the unit and listen to your stored songs.
• In Bluetooth Mode you can stream music from your smartphone or other Bluetooth device.
Note: When using USB Mode, this unit is compatible with .mp3 and .wav files ONLY.
This unit ships in Demo Mode for in-store demonstration purposes.Slide the ON/OFF Switch to OFF and then back to On again
to exit Demo Mode.
Charging The Unit
1. Connect the included micro USB cord to the micro USB charging port
on the back of the unit.
2. Connect the standard USB plug end of the cord to a power USB port
on a computer or other USB charging device.
For first time use, charge unit for about 5 hours.
3. A low battery tone will sound to indicate it is time to charge the unit.
FRONT OF UNIT
Mode (USB/BT)
Light Show
Previous Track/
Volume Down
USING THE LIGHT SHOW
• Slide the Power Switch to ON when you start to use the unit.
Press and hold the Mode/Light Show Button for 3 seconds to
cycle through 6 different Light Show Patterns, and OFF.
Light Show Patterns: Quick, Slow In, Pinball, Breath,
Reactive, and Rainbow.
• Two quick short presses of the Mode/Light Show Button will
toggle the lights ON and OFF.
USING A USB DRIVE
For best performance, use a high speed 3.1 USB drive (not
included) when recording audio from this unit.
Note: Using a lower speed USB drive may cause skipping or
poor performance of the Bluetooth audio stream.
Sometimes skipping in recorded music may occur, depending
on the online streaming speed of your phone.
Using USB Mode
Slide the Power Switch to ON when you start to use the unit.
Make sure the Mode is set to USB (use the Mode Button). A voice
prompt will confirm when USB Mode is active.
• Connect a USB flash drive to the USB port on the top of the unit.
• Press Play, then use the "Next Track" and "Previous Track" buttons
to navigate files on the USB drive.
• After pressing "Play", the automatic play-all function will activate,
and songs will play in the order they were stored.
Using Bluetooth Mode
• Select Bluetooth mode using the Mode Button. A voice prompt will
confirm the unit is in Bluetooth mode.
• Turn on your Bluetooth device and enable Bluetooth mode (check
in Options or Settings). The unit will automatically enter pairing
mode.
• Using your Bluetooth device, select the Bluetooth pairing name for
your product: 'Karaoke 555'
• A tone will sound to confirm once your device is paired. Put your
Bluetooth device in play mode to play audio.
• Use the "Next Track", "Previous Track"and "Play/Pause" buttons on
the unit to navigate tracks.
• To manually pair your device, press and hold the Play/Pause Button
on the front of the unit for 2-3 seconds.
• To reset Bluetooth settings, press and hold the Play/Pause Button
for 10 seconds. A tone will sound to confirm Bluetooth is reset.
Recording Audio
• Record audio from Bluetooth mode and the microphone input,
and the file will save to your USB flash drive.
• Make sure the Mode is set to "Bluetooth" , and that a flash drive is
connected to the USB port.
• When you are ready to perform, press the Record Button to begin
recording from Bluetooth and the microphone.
• Short press the Record Button to stop recording.
• Press the Play/Pause Button to pause recording, and press again
to continue recording the same file.
• Switch to USB Mode to listen to your recording!
Note: The unit will automatically stop recording when USB flash
drive is full.
555-ONLINEIB-ENG-041823-A
Model: 555 Series
Bluetooth MP3 Karaoke with Light Show
Play/Pause/
Bluetooth Pairing
Next Track/
Volume Up
(In BT Mode Only)
For further information and to see the latest instructions, visit www.ekids.com
Charge via USB AC adaptor, computer USB port, or other powered USB port
Computer connected
to working outlet
TOP OF UNIT
USB
Record
USB Port
(for USB Mode)
USING THE MICROPHONE
• Connect the microphone to Mic Jack 1 or 2 on the
top of the unit.
• Slide the Microphone Switch ON to amplify your
voice when you sing.
• To toggle Echo effect off and on, press and hold
BOTH "Next Track" and "Previous Track" buttons for
3 seconds. A voice prompt will confirm "Echo Off" or
"Echo On."
NAVIGATING TRACKS/ADJUSTING VOLUME
• Short press Next Track/Previous Track Buttons to navigate tracks.
• Press and hold Next Track or Previous Track to increase or
decrease volume. Release to set current volume.
If the unit does not respond:
• Make sure unit is completely charged.
• To re-pair your device, press and hold the Play/Pause Button for
2-3 seconds, then select 'Karaoke 555' on your Bluetooth device.
Be sure to remove any previous instance of "Karaoke 555" from
"My Devices" setting screen on your Bluetooth device if present.
Note: The rechargeable battery can be replaced only by eKids
Consumer Repair Department.
WARNING/DISPOSAL OF UNIT
Please do NOT attempt to change the battery yourself. Doing so may
damage the unit and will void your warranty.
• Never dispose of used batteries/electronics with ordinary solid wastes,
since they contain toxic substances.
• Always dispose of used batteries/electronics in accordance with the
prevailing community regulations. Many electronics retailers now
recycle batteries and other electronic components at no charge.
To find a drop-off location near you, visit www.call2recycle.com
Internal Rechargeable Lithium-ion Battery
This device uses an internal rechargeable lithium-ion battery that should
last the lifetime of the device. If you suspect your battery may be dead,
try charging it several times. If problems persist, please do not attempt
to repair unit; see warranty for factory service.
CAUTION
The battery used in this device may present a risk of fire, explosion or
chemical burn if mistreated. Never use or charge the battery if it appears
to be leaking, discolored, deformed, or in any way abnormal. Never
disassemble the unit or attempt to remove battery as that could cause
leakage of alkaline solution or other electrolytic substance. Always
confirm that the temperature is 5°C – 35° C (41° - 95° Fahrenheit)
before you charge the battery. Leakage or deterioration of the battery
may occur if this warning is not heeded.
• Never expose the battery to any liquid.
• Never expose the battery to excessive heat such as direct sunlight
or fire. Never use the battery pack in an unventilated vehicle where
excessive internal temperatures may be encountered.
• Always keep the battery out of the reach of infants and small children.
• It is important to keep the unit as dry and clean as possible. You may
clean the cabinet with a cloth or sponge moistened with mild soap
and water. Do not attempt to use strong cleansers or solvents, as
they may cause damage.
• Battery chargers used with the device are to be regularly examined
for damage to the cord, plug, enclosure and other parts, and in the
event of such damage, they must not be used until the damage has
been repaired.
USB Adaptor
(not included)
OR
Computer USB port
ON OFF
USB 5V
MIC 1
ON/OFF
Charging
Switch
Indicator
USB
Charging Port
Troubleshooting
Maintenance
ENG
MIC 2
