ROBOSEN AI BASE LITE
QUICK START GUIDE
APP DOWNLOAD QR CODE
Please download the "Robosen AI "app
before you start using the product. You can
download it from APP Store or Google Play.
PRODUCT SPECIFICATION
Product Name
Model
Main Unit Input
Main Board
Dimensions 201.5*201.5*54.5mm (7.93*7.93*2.15in)
Weight
Material
Wireless Connection
Control Method Voice control, Mobile App, Button control
External Ports DC power port, Micro USB port
Microphone
Power supply
robosen AI base lite
K1JD
12Vdc 1.5A
MT8516
456g(16.09oz)
ABS
2.4G Wi-Fi, Bluetooth 4.2
6-Mic Circular Arra
powered by adapter
MEET ROBOSEN AI BASE LITE
robosen AI base lite is an open platform based on artificial intelli-
gence, with advanced automatic speech recognition and emotion-
al interaction. It can give Robosen robot products more functions,
such as intelligent voice user interface, emotional companionship
and AI entertainment. It can identify your intentions in a more
accurate way, let your hands free, and experience the fun things of
AI entertainment.
( robosen AI base lite applies to most Robosen robot products )
ROBOSEN AI BASE LITE BUTTON'S FUNCTION DESCRIPTION
Button Action
Short press
Volume Up
Long press
Short press
Mode/Next Button
Quick double click
Short press
Mic Button
Short press
Wake Button
Hold for 3s
Short press
Volume Down
Long press
Volume Up
1
2 Mode/Next Button
3 Mic Button
4 Wake Button
5 Volume Down
Function
Volume increases by scale
Volume increases continuously
Next action/song
Ground mode/Base mode
Turn off microphone/Turn on microphone
Voice command
Wi-Fi configuration
Volume decreases by scale
Volume decreases continuously
