    INTRODUCTION Dear Customer, thank you for choosing one of our products. We hope that you will be completely satisfied with this machine and that it fully meets your expectations. This manual has been compiled in order to provide you with all the information you need to get acquainted with the machine and use it safely and ef ciently.
  • Page 14: Identification Of The Main Components

    9. Bar cover • C 41 9a. Spiked bumper guard (to be removed while working) 10. Identification plate • C 38 T • C 41 T CONTROLS AND FILLING POINTS • C 38 • C 41 11. Engine stop switch •...
  • Page 15: Symbols

    IDENTIFICATION OF MAIN COMPONENTS / SYMBOLS IDENTIFICATION PLATE 10.1) CE Conformity marking 10.9 10.5 10.2 10.1 10.3 10.2) Name and address of the manufacturer 10.3) Sound power level 10.5) Type of machine Type: 10.6) Serial number 10.7) Year of manufacture 10.8) Article Code 10.9) Emission number Art.N.
  • Page 16: Safety Requirements

    SYMBOLS / SAFETY REQUIREMENTS EXPLANATORY SYMBOLS ON THE MACHINE (if present) 11) Fuel tank 12) Chain oil tank and oil flow adjuster 13) Carburettor adjustments = low speed mixture adjuster H = high speed mixture adjuster = idle speed adjuster 14) Choke 15) Primer 16) Chain brake (the...
  • Page 17 SAFETY REQUIREMENTS running or when the engine is hot; 7) Check that when the machine is running idle, there is – if you have spilt some fuel, do not attempt to start the no movement of the chain and, after pres s ing the throttle engine but move the machine away from the area of trigger, the engine quickly returns to minimum speed.
  • Page 18 SAFETY REQUIREMENTS F) RESIDUAL RISKS keep your cutting jobs free from accident or injury. Kickback is the result of tool misuse and/or incorrect oper- • Keep all parts of the body away from the saw chain ating procedures or conditions and can be avoided by taking proper precautions as given below: when the chain saw is operating.
  • Page 19: Machine Assembly

    Disposal of the packaging should be done in • Machines with quick chain tension ac cordance with the local regulations in force. adjuster (C 38 T, C 41 T) WARNING! – Unscrew the handle (11) and remove the guard Always wear heavy-duty to get to the drive sprocket and the point where gloves when handling the bar and chain.
  • Page 20: Preparing To Work

    PREPARING TO WORK 5. PREPARING TO WORK 1. PREPARING THE FUEL Petrol Synthetic oil 2-stroke liters liters This machine is fitted with a two-stroke engine which requires a mixture of petrol and lubricating oil. 0,025 0,050 IMPORTANT Using petrol alone will dam- 0,075 age the motor and will cause for invalidation of the 0,125...
  • Page 21 • Machines with quick chain tension and to prevent irreparable damage to the oil pump. adjuster (C 38 T, C 41 T) IMPORTANT The special oil for lubricating the chain is biodegradable. Use of a mineral oil or –...
  • Page 22: How To Start - Use - Stop The Engine

    HOW TO START - USE – STOP THE ENGINE 6. HOW TO START - USE – STOP THE ENGINE STARTING THE ENGINE DANGER! Never start the chain saw by holding on to the starter cable and allowing WARNING! The engine must be it to fall.
  • Page 23 HOW TO START - USE – STOP THE ENGINE the accelerator. This product has accordingly been designed with a The chain speed is regulated by the throttle trigger ventilation hatch on the right side of the surface of the cylinder cover to allow warm air to be supplied (1) on the rear handgrip (2).
  • Page 24: Using The Machine

    USING THE MACHINE 7. USING THE MACHINE IMPORTANT IMPORTANT Always remember that an During the first period of use incorrectly used chain-saw may disturb others and (or after replacing the chain), it must be checked have a serious impact on the environment. more frequently due to settling of the chain.
  • Page 25 USING THE MACHINE • Bucking (Fig. 15) WARNING! Stop the engine immedi- ately if the chain stops during sawing. Beware of kickback, which can occur if the bar con- WARNING! Be careful of where the tacts an obstacle. bran ches are lying on the ground, the risk of them being under tension, the direction the branch may go during cutting and the risk of the tree being unstable after the branch has...
  • Page 26: Maintenance And Storage

    USING THE MACHINE / MAINTENANCE AND STORAGE – If there is excessive dirt or resin build-up, dis- WARNING! Allow the engine to cool assemble the chain and place it in a container be f ore storing in any enclosure. with a specific cleanser. Then rinse it with clean To reduce fire hazards, clean the machine water and treat it with a suitable anticorrosive thoroughly to get rid of any sawdust, bran-...
  • Page 27 MAINTENANCE AND STORAGE CHAIN CATCHER the same characteristics whenever the electrodes have burnt or the insulation has worn, and in any This is an important safety device that restrains the case every 100 working hours. chain if it breaks or degrooves. Regularly check the condition of the pin and re- place it if damaged.
  • Page 28 MAINTENANCE AND STORAGE Chain maintenance table WARNING! Do not use other types of chains or bars for safety reasons. The table gives the sharpening data for different types of chains, but this does not mean you can use different chains from the homologated one. Chain pitch Limiter tooth level (a) File diameter (d)
  • Page 29: Identification Of Faults

    MAINTENANCE AND STORAGE / TROUBLESHOOTING LONG PERIODS OF DISUSE the fuel that is left in the tank and the carburettor. – Remove the spark plug after the engine cools. IMPORTANT If you are not going to use – Pour a teaspoon of (new) 2-stroke engine oil into the machine for a period of more than 2-3 months, the spark plug slot.
  • Page 30: Accessories

    CHAIN Model Length Groove width C 38 C 41 Code Code C 46 C 50 C 38 T C 41 T Inches Inches / cm Inches / mm OREGON OREGON 91VG053X 3/8” 14” / 35 cm 0.050” / 1.3 mm...
  • Page 31 DICHIARAZIONE CE DI CONFORMITÁ (Direttiva Macchine 2006/42/CE, Allegato II, parte A) La Società: ST. S.p.A. – Via del Lavoro, 6 – 31033 Castelfranco Veneto (TV) – Italy Dichiara sotto la propria responsabilità, che la macchina: Motosega a catena per lavori forestali...
