Model： LU-RMT02, LU-RM03 （Only different silk-screen)
Specification：
1. IC model：HS1527
2. Working voltage：9V
3.
Wordking current：5~5.5mA(± 0.5mA)
4. Emission frequency：315MHz(± 100K)
5.
Emission power：≥10MW
6. Modulation system：ASK
7. Transmission distance：20-50meter
8. Quiescent current：≤3uA
9. Oscillation resistance：270K
This remote control is used in the lamp control above, the customer can
choose the mode at will.
Instruction
1 key: Power on/off
2 key: Mode key
3 key: Color key
4 key: Speed key
Advertisement
Table of Contents
Related Manuals for LedGlow LU-RMT02
Summary of Contents for LedGlow LU-RMT02
- Page 1 Instruction Model： LU-RMT02, LU-RM03 （Only different silk-screen) Specification： 1. IC model：HS1527 2. Working voltage：9V Wordking current：5~5.5mA(± 0.5mA) 4. Emission frequency：315MHz(± 100K) Emission power：≥10MW 6. Modulation system：ASK 7. Transmission distance：20-50meter 8. Quiescent current：≤3uA 1 key: Power on/off 9. Oscillation resistance：270K 2 key: Mode key...
- Page 2 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
