Corona Lighting CX-BTE Quick Start Manual

Bluetooth range extender
Hide thumbs
1
2
Table of Contents

Advertisement

Quick Links

Download this manual
FIAT LUX
By
Download the free 'Corona BT' App
CX-BTE

Description:

The extender is intended to boost the bluetooth mesh network range where communication
gaps are present. To function it must be added to the Corona BT app. Multiple Range
Extenders can be installed and added to the same account.

Fixture Features:

Body: Aluminum, PVC
Antenna: External, 5dB, 2.4 GHZ
Wire: 5' wire lead (UL Listed), SP1-1W
Mounting: 8½" Plastic ground spike, attached to the fixture, with ½ NPT threads.
Warranty: Ten (10) year warranty

Specifications:

Wattage: 1 Watt
Operating Voltage Range: 9V-17V
Works With: Corona Lighting BT products and phone app
Compatible Wireless Applications: Bluetooth Mesh®

Available Accessories:

CX-703: Aluminum Flat Canopy
CX-705: Brass Flat Canopy
CX-709: Brass Raised Canopy
CX-719: Brass Tree Mounting Bracket

Installation:

Use waterproof connectors and wire into the existing system.
Install in areas where a distance gap between fixtures is present.
Range Extender must be added to the same User Account as the Bluetooth fixtures, in order to
work properly.
Signal range increases in higher areas above ground.
Extend communication range between your BT fixtures.
Wire the Bluetooth Range Extender to any existing BT system.
Antenna and 5' wire lead included.
For use with Fiat Lux by Corona Lighting Products Only.
Smart Accessories
Bluetooth Range Extender

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CX-BTE and is the answer not in the manual?

Questions and answers

Summary of Contents for Corona Lighting CX-BTE

  • Page 1 FIAT LUX Extend communication range between your BT fixtures. Wire the Bluetooth Range Extender to any existing BT system. Antenna and 5’ wire lead included. Download the free ‘Corona BT’ App For use with Fiat Lux by Corona Lighting Products Only.
  • Page 2 The ideal location would be an open area without obstructions like walls, buildings or large rocks. To mount the CX-BTE you can either place it in the ground by attaching it to the included ground spike, or for better reception you can mount it to a wall or tree with a canopy or bracket mount (see the available accessories on page 1).
