PCB Piezotronics Inc. claims proprietary rights in
the information disclosed hereon. Neither it nor any
reproduction thereof will be disclosed to others
without the written consent of PCB Piezotronics Inc.
B

1.37 [34.8]
1.00 [25.4]
A
1 FOR METRIC RING TRIAXIAL ACCELEROMETER (MODEL M604B91) USE MOUNTING BOLT MODEL
M081A68, M6 X 1.00-6g X .92[23.4] LONG.
UNLESS OTHERWISE SPECIFIED TOLERANCES ARE:
DIMENSIONS IN INCHES
DECIMALS XX ±.03
XXX ±.010

ANGLES 2 DEGREES
FILLETS AND RADII
.003 - .005
2
2.04 [51.9]
MOUNTING BOLT
MODEL 081A68
1/4-28 UNF-2A
.92 [23.4] LONG
(SUPPLIED)
DIMENSIONS IN MILLIMETERS
ECB
[ IN BRACKETS ]
TITLE
DECIMALS X ± 0.8
XX ± 0.25

ANGLES 2 DEGREES
RING TRIAXIAL ACCELEROMETER
FILLETS AND RADII
0.07 - 0.13
2
REV
NR
ELECTRICAL CONNECTOR
4-PIN, M12
1
DRAWN CHECKED
8/16/17 ECB 8/16/17
OUTLINE DRAWING
1
REVISIONS
DESCRIPTION
RELEASED TO DRAFTING
"Y" AXIS
SIGNAL
"Z" AXIS
SIGNAL
ENGINEER
GCD 8/16/17
3425 WALDEN AVE. DEPEW, NY 14043
(716) 684-0001 E-MAIL: sales@pcb.com
DWG. NO.
CODE
IDENT. NO.
52681
SCALE: 2X
1
DIN
47010
B
"X" AXIS
SIGNAL
GROUND
A
67524
SHEET 1 OF 1
