User Manual
PCI-E Riser Cable with Bracket Set
This product is only designed for XILENT X Case (X912.ARGB)!
Components List
1
5
2
6
3
7
4
1) L Shape Bracket x 1
2) PCI-E Riser Cable x 1
3) Screwdriver x 1
4) Mounting Screw A x 2
5) Mounting Screw B x 5
6) Mounting Screw C x 3
7) Pad x 1 (pre-installed)
1) L Form Halterung x 1
2) PCI-E Riser Kabel x 1
3) Schraubendreher x 1
4) Schrauben A x 2
5) Schrauben B x 5
6) Schrauben C x 3
7) Polster x1 (vormontiert)
Advertisement
Table of Contents
Summary of Contents for Xilence XZ107
- Page 1 Components List 1) L Shape Bracket x 1 User Manual 2) PCI-E Riser Cable x 1 3) Screwdriver x 1 4) Mounting Screw A x 2 5) Mounting Screw B x 5 6) Mounting Screw C x 3 PCI-E Riser Cable with Bracket Set 7) Pad x 1 (pre-installed) 1) L Form Halterung x 1 2) PCI-E Riser Kabel x 1...
- Page 2 Installation Steps À DÉPOSER À DÉPOSER EN MAGASIN EN DÉCHÈTERIE Cet appareil et ses accessoires 1) Asemble the bracket. se recyclent 2) Install the riser cable to bracket. 3) Remove all PCI slots. 4) Install the bracket to the case. Points de collecte sur www.quefairedemesdechets.fr 5) Connect GPU to the riser cable.
