Ikelite 47011 Manual

Vacuum Pump with Gauge
Item number 47011
Included in the Box
•
Vacuum pump with gauge
•
Rubber tubing
•
Tubing insert # 47005 (installed)
Important Notices
The vacuum pump is not airtight. Do not leave the
»
vacuum pump attached to your system overnight.
The vacuum valve is only waterproof with the plug in
»
place. Never submerge the housing in water without the
plug properly installed in the valve.
Vacuum systems are only capable of simulating depths
»
up to 33 feet (10 meters). Some very small leaks, like
those caused by a fine hair across the o-ring, may only
occur at deeper depths. In most cases, these leaks are
not significant enough to cause damage to a camera.
A vaccum system cannot correct for improper assembly.
»
Product Use & Video
Tutorials
http://ikelite.com/watch-47011
Vacuum
release button
Vacuum plug
Installation and Use
Getting Ready for a Dive
The housing is only waterproof with the vacuum valve
»
plug in place. Always replace the valve plug before
putting the housing in water.
1. Install your camera in the housing.
2. Press the vacuum valve lock release and remove the
plug from the valve.
Gauge
Vacuum pump
Vacuum valve
Valve
release lock
