- Page 1 Crestron Adagio ATC-AMFMXM ® AM/FM and XM Satellite Radio Tuner Card Operations & Installation Guide...
- Page 2 This document was prepared and written by the Technical Documentation department at: Introducing XM Satellite Radio There’s a world of audio listening pleasure beyond AM and FM: XM Satellite Radio. Select from over 160 channels of music, news, sports, comedy, talk, and entertainment.
-
Page 3: Table Of Contents
Crestron Adagio ATC-AMFMXM Contents AM/FM/XM Tuner Card: Adagio Introduction ... 1 Features and Functions ... 1 Specifications ... 2 Physical Description... 3 Industry Compliance ... 5 Setup ... 6 Installation ... 6 Regional Configuration ... 7 Hardware Hookup ... 7 Antenna Orientation ... -
Page 5: Am/Fm/Xm Tuner Card: Adagio ® Atc-Amfmxm
(RDS), a European standard, permit broadcasters to use a sub-carrier frequency to transmit inaudible digital data along with their regular FM programming to receivers equipped to process the data. Refer to “Appendix: RBDS/RDS Function Support” on page 13 for more information. AM/FM/XM Tuner Card AM/FM/XM Tuner Card: ATC-AMFMXM • 1 ®... -
Page 6: Specifications
AM/FM/XM Tuner Card Specifications Specifications for the ATC-AMFMXM are listed in the following table. ATC-AMFMXM Specifications 2 • AM/FM/XM Tuner Card: ATC-AMFMXM Crestron Adagio SPECIFICATION Audio Maximum Output FM Tuner Frequency Response Intermediate Frequency Usable Sensitivity S/N Ratio IF Rejection... -
Page 7: Physical Description
ATC-AMFMXM. ATC-AMFMXM Physical View (Head On) ATC-AMFMXM Physical View (Angled) Conversion Connector Coax (RG6)/F Type (Antenna) to IEC Type Connector (Tuner) Operations & Installation Guide – DOC. 6462A AM/FM/XM Tuner Card AM/FM/XM Tuner Card: ATC-AMFMXM • 3... - Page 8 AM/FM/XM Tuner Card ATC-AMFMXM Overall Dimensions 4.91in (12.46cm) Connectors, Controls and Indicators (Continued on following page) 4 • AM/FM/XM Tuner Card: ATC-AMFMXM Crestron Adagio 1. 38 in (3. 51 cm) CONNECTORS, CONTROLS, & INDICATORS EXT. ANT IN (1) 8-wire RJ-45 female;...
-
Page 9: Industry Compliance
ATC-AMFMXM Connectors, Controls and Indicators (Continued) Industry Compliance As of the date of manufacture, the ATC-AMFMXM has been tested and found to comply with specifications for CE marking and standards per EMC and Radiocommunications Compliance Labeling. NOTE: This device complies with part 15 of the FCC rules. Operation is subject to... -
Page 10: Setup
3. Unpack the ATC-AMFMXM card. 4. As shown in the photo on the next page, position the ATC-AMFMXM card so the print on the faceplate is right side up and the side rails of the card slide into the plastic slots mounted on left and right inside walls of the Adagio system. -
Page 11: Regional Configuration
Hardware Connections for the ATC-AMFMXM Operations & Installation Guide – DOC. 6462A Tuner Card Installation 5. Push the ATC-AMFMXM card into the slot until it stops at the rear connector, and then push again until the ATC-AMFMXM card snaps into place. -
Page 12: Antenna Orientation
Extension cables are available from your dealer or from Crestron. The following antennas are supplied with your AM/FM/XM Tuner Card: AM Loop Antenna 8 • AM/FM/XM Tuner Card: ATC-AMFMXM Crestron Adagio CONNECTOR END OF AM ANTENNA FM T-Type Antenna Operations &... -
Page 13: Uploading And Upgrading
• Display the network device tree (Tools | Network Device Tree) to show all network devices connected to the control system. Right-click on the ATC-AMFMXM to display actions that can be performed on the ATC-AMFMXM. • Select Functions | Firmware to upgrade the ATC-AMFMXM firmware. -
Page 14: Operation
These are buttons and controls you should know how to use: Please refer to the latest version of the operations guide for your Adagio system for detailed information on Source mode control of the AM/FM/XM Tuner. 10 • AM/FM/XM Tuner Card: ATC-AMFMXM Crestron Adagio •... -
Page 15: Problem Solving
Follow instructions on inside cover of this manual. Clean contacts with cotton swab or clean cloth. Apply Isopropyl alcohol as needed for cleaning. Verify proper antenna connection. Check antenna placement and orientation for good signal strength. AM/FM/XM Tuner Card: ATC-AMFMXM • 11... -
Page 16: Further Inquiries
Future Updates As Crestron improves functions, adds new features and extends the capabilities of the ATC-AMFMXM, additional information may be made available as manual updates. These updates are solely electronic and serve as intermediary supplements prior to the release of a complete technical documentation revision. -
Page 17: Appendix: Rbds/Rds Function Support
TA&TP = This station is currently broadcasting the traffic announcements. Station search by The FM Tuner is able to search for station with specified program type. AM/FM/XM Tuner Card: ATC-AMFMXM • 13 AM/FM/XM Tuner Card DESCRIPTION... - Page 18 AM/FM/XM Tuner Card RBDS/RDS Program Types 14 • AM/FM/XM Tuner Card: ATC-AMFMXM Crestron Adagio RBDS PROGRAM TYPE CODE (US) No program type or undefined News Information Sports Talk Rock Classic Rock Adult Hits Soft Rock Top 40 Country Oldies Soft...
-
Page 19: Return And Warranty Policies
All brand names, product names and trademarks are the sole property of their respective owners. Windows is a registered trademark of Microsoft Corporation. Windows95/98/Me/XP/Vista and WindowsNT/2000 are trademarks of Microsoft Corporation. Operations & Installation Guide – DOC. 6462A AM/FM/XM Tuner Card AM/FM/XM Tuner Card: ATC-AMFMXM • 15... - Page 20 Crestron Electronics, Inc. Operations & Installation Guide – DOC. 6462A 15 Volvo Drive Rockleigh, NJ 07647 (2014566) Tel: 888.CRESTRON 08.07 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
