- Page 1 Mounting plates TECHNICAL REFERENCE MANUAL MOUNTING PLATES V23-1...
-
Page 2: Table Of Contents
About this document Legend Online versions Device Technical Reference Manual DEWESoft® User Manual DS-MOUNT (Mounting plates) 1. DS-MOUNT-1 1.1. DS-MOUNT-1 Technical drawing 2. DS-MOUNT-2 2.1. DS-MOUNT-2 Technical drawing 3. DS-MOUNT-2K 3.1. DS-MOUNT-2K Technical drawing 4. DS-MOUNT-3 4.1. DS-MOUNT-3 Technical drawing 5. - Page 3 MOUNTING PLATES TECHNICAL REFERENCE MANUAL Safety instructions Safety symbols in the manual General Safety Instructions Environmental Considerations Product End-of-Life Handling System and Components Recycling General safety and hazard warnings for all Dewesoft systems Documentation version history V23-1 3/29...
-
Page 4: About This Document
The DEWESoft® User Manual document provides basics and additional information and examples for working with DEWESoft® and certain parts of the program. The latest version of the DEWESoft® tutorials can be found here: https://download.dewesoft.com/list/manuals-brochures/software-manuals In the Software Manuals section click the download link of the DEWESoft X User Manual entry. V23-1 4/29... -
Page 5: Ds-Mount (Mounting Plates)
MOUNTING PLATES TECHNICAL REFERENCE MANUAL DS-MOUNT (Mounting plates) Mounting plates are equipped with a smart click mechanism that allows several Dewesoft DAQ ● systems to be firmly fixed to the mounting plate. All mounting plates are milled from a single block of aluminum in our state-of-the-art CNC tool ●... -
Page 6: Ds-Mount-1 Technical Drawing
MOUNTING PLATES TECHNICAL REFERENCE MANUAL 1.1. DS-MOUNT-1 Technical drawing 2. DS-MOUNT-2 DS-MOUNT-2 can be used to fit small instruments, such as DS-CAN2, GPS/IMU devices, or any other accessory that needs to be firmly fixed on top of the SIRIUS DAQ systems or SBOX processing computers. -
Page 7: Ds-Mount-2 Technical Drawing
MOUNTING PLATES TECHNICAL REFERENCE MANUAL 2.1. DS-MOUNT-2 Technical drawing V23-1 7/29... -
Page 8: Ds-Mount-2K
MOUNTING PLATES TECHNICAL REFERENCE MANUAL 3. DS-MOUNT-2K Top mounting plate for binding up to two KRYPTON data acquisition systems to the SIRIUS or MINITAURs data acquisition systems, SBOX computer, or battery packs. DS-MOUNT-2K 3.1. DS-MOUNT-2K Technical drawing V23-1 8/29... -
Page 9: Ds-Mount-3
MOUNTING PLATES TECHNICAL REFERENCE MANUAL 4. DS-MOUNT-3 Top plate with display handle and holder for our portable LCD displays. Clever click mechanism will allow the mount to fit our SIRIUS, IOLITE, SBOX, MINITAURs, or DS-BP battery packs and allow easy mounting of the LCD display. -
Page 10: Ds-Mount-3 Technical Drawing
MOUNTING PLATES TECHNICAL REFERENCE MANUAL 4.1. DS-MOUNT-3 Technical drawing V23-1 10/29... -
Page 11: Ds-Mount-4
MOUNTING PLATES TECHNICAL REFERENCE MANUAL 5. DS-MOUNT-4 Bottom aluminium mounting plate with easy click mechanism, same as on SIRIUS single slice. Fits to SIRIUS slice, R2, R4, SBOX, BP2i, BP4i DS-MOUNT-4 5.1. DS-MOUNT-4 Technical drawing V23-1 11/29... -
Page 12: Ds-Mount7
MOUNTING PLATES TECHNICAL REFERENCE MANUAL 6. DS-MOUNT7 Aluminum top mounting plate with handle and click mechanism, to mount instruments on top. Fits to SBOXwe. Units that can be mounted on top: SIRIUS slices, R2, R4, SBOX, DS-BP2i and DS-BP4i. DS-MOUNT7 6.1. -
Page 13: Ds-Mount-19
MOUNTING PLATES TECHNICAL REFERENCE MANUAL 7. DS-MOUNT-19 Mounting plate for fitting SIRIUS, MINITAURs data acquisition systems, and SBOX data loggers into a 19˝ rack cabinet. DS-MOUNT-19 7.1. DS-MOUNT-19 Technical drawing V23-1 13/29... -
Page 14: Ds-Mount-19-R8X
MOUNTING PLATES TECHNICAL REFERENCE MANUAL 8. DS-MOUNT-19-R8x 19" rack-compatible mounting kit for SIRIUS R8x data acquisition systems. The easy-to-screw-on handles can enable R8 systems to be easily mounted in standard 19'' rack cabinets. It fits all R8 models - R8, R8B, R8D, R8DB, R8R, R8Rrt, R8rt DS-MOUNT-19-R8x V23-1 14/29... -
Page 15: Ds-Mount-19-R8X Technical Drawing
MOUNTING PLATES TECHNICAL REFERENCE MANUAL 8.1. DS-MOUNT-19-R8x Technical drawing V23-1 15/29... -
Page 16: Ds-Mount-Disp-12
MOUNTING PLATES TECHNICAL REFERENCE MANUAL 9. DS-MOUNT-DISP-12 Mount that fits DS-DISP-12, our 12'' multi-touch LED screen DS-DISP-12, on a SIRIUS slice compatible plate. Smart click-mechanism enables plane and display to be firmly fixed above SIRIUS DAQ system, SBOX data logger or MINITAURs DAQ system. DS-MOUNT-DISP-12 V23-1 16/29... -
Page 17: Ds-Mount-Disp-12 Technical Drawing
MOUNTING PLATES TECHNICAL REFERENCE MANUAL 9.1. DS-MOUNT-DISP-12 Technical drawing V23-1 17/29... -
Page 18: Ds-Mount-K1
MOUNTING PLATES TECHNICAL REFERENCE MANUAL 10. DS-MOUNT-K1 Aluminum mounting for fitting KRYPTON ONE products. Fits to: SIRIUS slices, R2, R4, SBOX, DS-BP2i and DS-BP4i. Note: The mechanism is not meant to sustain large vibrations and a huge stack of devices. Mounting adapter for attaching KRYPTON ONE modules to the SIRIUS module V23-1 18/29... -
Page 19: Ds-Mount-K2
MOUNTING PLATES TECHNICAL REFERENCE MANUAL 11. DS-MOUNT-K2 Mounting plate for a KRYPTON and KRYPTON CPU data acquisition systems. The mount features an aluminum ground plate with an easy click mechanism, which is the same as the one found on the top side of all Krypton instruments. -
Page 20: Ds-Mount-K3
MOUNTING PLATES TECHNICAL REFERENCE MANUAL 12. DS-MOUNT-K3 Top aluminium mounting plate with click mechanism, same as on the KRYPTON multi units. Fits to: KRYPTON multi, will NOT fit KRYPTON CPU. Important Please note that the mechanism is not meant to sustain large vibrations and a huge stack of devices. -
Page 21: Ds-Mount-K3 Technical Drawing
MOUNTING PLATES TECHNICAL REFERENCE MANUAL 12.1. DS-MOUNT-K3 Technical drawing V23-1 21/29... -
Page 22: Ds-Mount2-M
MOUNTING PLATES TECHNICAL REFERENCE MANUAL 13. DS-MOUNT2-M DS-MOUNT2-M is designed for the SIRIUS mini line of data acquisition systems. This aluminum mounting plate is designed to fit the SIRIUS MINI instrument on top of SIRIUS modular slices, R2, R4, IOLITE R8, SBOX, DS-BP2i, and DS-BP4i. DS-MOUNT2-M features a handle and already known click mechanism for easy instrument clipping into place. -
Page 23: Ds-Mount2-M Technical Drawing
MOUNTING PLATES TECHNICAL REFERENCE MANUAL 13.1. DS-MOUNT2-M Technical drawing V23-1 23/29... -
Page 24: Ds-Mount-R1X-R2X
MOUNTING PLATES TECHNICAL REFERENCE MANUAL 14. DS-MOUNT-R1x-R2x Bottom aluminium mounting plate. Fits to: R1DB, R1B, R2DB, R2B, R2D. DS-MOUNT-R1x-R2x 14.1. DS-MOUNT-R1x-R2x Technical drawing V23-1 24/29... -
Page 25: Warranty Information
Support Dewesoft has a team of people ready to assist you if you have any questions or any technical difficulties regarding the system. For any support please contact your local distributor first or Dewesoft directly. Dewesoft d.o.o. -
Page 26: Printing History
When used in text representing the company, product or technology name, the ® sign is not used. The Dewesoft triangle logo is a registered trademark but the ® sign is not used in the visual representation of the triangle logo. -
Page 27: Environmental Considerations
This symbol indicates that this system complies with the European Union’s requirements according to Directive 2002/96/EC on waste electrical and electronic equipment (WEEE). Please find further information about recycling on the Dewesoft web site www.dewesoft.com Restriction of Hazardous Substances This product has been classified as Monitoring and Control equipment and is outside the... - Page 28 REMOVE POWER and do not use the product until the safe operation can be verified by service-trained personnel. If necessary, return the product to Dewesoft sales and service office for service and repair to ensure that safety features are maintained.
-
Page 29: Documentation Version History
MOUNTING PLATES TECHNICAL REFERENCE MANUAL Lithium ion batteries are classified as not hazardous when used according to the ● recommendations of the manufacturer described in Battery Safety Data Sheet, which is available for download from this link. Do not switch on the system after transporting it from a cold into a warm room and vice versa. ●...
