BELL SYSTEM PRACTICES
SECTION 081-330-100
AT&TCo Standard
Issue 4, May 1972
KS-14582 11 AND 12 SOLDERING COPPERS
AND KS-14768 HEAT UNITS
DESCRIPTION AND USE
CONTENTS
PAGE 1.o4
Two sizes of tips are provided for the
I. GENERAL . . . . . . . . . .
2. PRECAUTIONS . . . . . 0 . .
3. TOOLS AND MATERIALS . . . . .
4. DESCRIPTION OF SOLDERING COPPERS
5. DESCRIPTION OF HEATING UNIT . .
6. LOADING OF SOLDERING COPPER .
7. FIRING OF SOLDERING COPPER . .
8. MAINTENANCE OF SOLDERING COPPER
9. REPLACEMENT PROCEDURES . . .
1.
GENERAL
1.01
This section describes
L2 Soldering Coppers
.
.
.
.
.
.
.
.
the KS-14582 L1 and
and covers their use,
KS-14582 L1 and L2 Soldering Coppers. The
1
larger tip, designated L4, is used for heavier
soldering operations such as splicing and maintaining
2
cables. The smaller tip, L5, is used for lighter
work, such as soldering conductors on terminal lugs
2
(Fig. 1).
2
3
4
4
5
6
KS-14582
L5 TIP
,,.
",.
KS-14582
L4 TIP
—
safety measures, and maintenance. It also covers
the KS-14768 Heat Unit used to provide heat for
soldering operations in the field and the safety
precautions that must be observed in the handling
of thermite heat units.
1.o2
This section is reissued to add further
precaution with regard to the firing procedure
for the KS-14582 Soldering Copper.
1.o3
The soldering copper is intended for use
where power for heating an electrical
soldering copper is not available or where the use
of an open flame-heated copper is not practical,
as in the case of certain carrier repeater maintenance
operations.
Fig. l—lips For KS-1 4582 Soldering Copper
1.o5
Before attempting to use the KS-14582 L1
or L2 Soldering Copper, prepare all connections
in advance of the soldering operation. The KS-14582
L1 and L2 Soldering Coppers reach operating
temperature in approximately 20 seconds after the
heat unit is fired. The soldering coppers may then
be used for soldering for a period of 4 to 6 minutes
with the L4 tip, and 6 to 8 minutes with the L5
tip. To continue soldering for a longer period of
time, the expended heat unit must be extracted
and fresh one substituted.
1.06
The KS-14582 L1 Soldering Copper has been
rated Manufacture Discontinued and may no
longer be ordered as a complete unit; however,
replacement parts may be obtained to maintain
existing L1 soldering coppers in the field. Refer
to Part 9 for replacement part procedures.
@ American Telephone and Telegraph Company, 1972
Printed in U.S.A.
. . ,. Page 1
