- Page 1 USER MANUAL Product Version 1.0 | Document Revision B | Released 2023-02-13...
-
Page 2: I-6 Series Dimensions
All dimensions in millimeters and inches. Drawing not to scale This manual covers installation, use, and maintenance of the SGM i-6 Series. A digital version is available at www.sgmlight.com or upon request via support@sgmlight.com. The information in this document is subject to change without notice. -
Page 3: I-6 Rgbw / I-6 White Poi
i-6 RGBW / i-6 WHITE POI 502mm 19,76in 440mm 17,32in 406mm 166mm 15,99in 6,53in 200mm 150mm 5,91in 7,87in 320mm 12,60in 220mm 8,66in 81mm 3,19in 401mm 111mm 15,77in 4,37in 468mm 150mm 18,41in 5,91in 326mm 12,82in 172mm 6,78in All dimensions in millimetres and inches. Drawing not to scale Product Version 1.0 | Revision B | Released 2023-02-13... -
Page 4: Table Of Contents
CONTENT 2 i-6 SERIES DIMENSIONS 2 i-6 RGBW / i-6 White standard 3 i-6 RGBW / i-6 White POI 6 SAFETY INFORMATION 7 BEFORE INSTALLING THIS PRODUCT 8 INSTALLATION STANDARD FIXTURE 8 Identification and terminology 9 Unpacking 9 Application considerations 9 Transport handling 9 Rigging 10 ... - Page 5 CONTENT 26 CONFIGURING THE DEVICE FOR DMX CONTROL 26 About DMX 26 DMX Start address 26 Set/edit DMX address 26 Setting the DMX mode 26 DMX charts 27 SETTING A STATIC COLOR MANUALLY 27 USING STANDALONE OPERATION 28 FIXTURE PROPERTIES 28 Factory default 28 LED Engine 28 Individual fixture settings 30 CONTROL MENU 32 RDM 32 ...
-
Page 6: Safety Information
SAFETY INFORMATION WARNING! READ THE FOLLOWING SAFETY PRECAUTIONS CAREFULLY BE- FORE UNPACKING, INSTALLING, POWERING OR OPERATING THE DEVICE. SGM fixtures are intended for professional use only. They are not suitable for household use. Les fixtures SGM sont impropre à l’usage domestique. Uniquement à usage professionnel. This product must be installed in accordance with the applicable installation code by a person familiar with the construction and operation of the product and the hazards involved. -
Page 7: Before Installing This Product
BEFORE INSTALLING THIS PRODUCT Please visit the SGM official website at www.sgmlight.com for the latest version of this user manual/ safety information leaflet. Due to continuous improvements, the instructions may change without notice. SGM always recommends the latest available firmware version from www.sgmlight.com. -
Page 8: Installation Standard Fixture
INSTALLATION STANDARD FIXTURE IDENTIFICATION AND TERMINOLOGY A: 24 LEDs 5 Red, 5 Green, 5 Blue, 9 White B: Tilt lock C: Cooling fans D: Control panel (POI n/a) OLED Display (POI n/a) F: Rubber feet (POI n/a) G: GORE-TEX membrane H: Power in and out I: DMX in and out J: Handle... -
Page 9: Unpacking
UNPACKING Unpack the device and inspect it to ensure that it has not been damaged during transport. The i-6 Series are shipped with: • 2 x Omega bracket with 1/4-turn fasteners (standard version) • Safety information leaflet • 2 m IP66 power cable pigtail APPLICATION CONSIDERATIONS The standard version is IP66-rated and is designed for both indoor and outdoor operation. -
Page 10: Rigging Process Using Sgm Omega Brackets
3. Align the omega bracket with the i-6 Series base. For standard Omega Bracket, insert the fasteners into the i-6 Series base bracket, and turn both levers a full 1/4 turn clockwise to lock. When using the POI Omega Bracket, insert the included M-10 screws through the bracket holes and tighten them with a M-10 key until they are Product Version 1.0 | Revision B | Released 2023-02-13... -
Page 11: Tilt Lock
fully attached to the base. 4. Hang the fixture on a truss or other structure. Tighten the clamp/bracket. 5. Verify that there are no combustible materials, cables, or surfaces to be illuminated within 0.3 m (12 in.) of the fixture. 6. -
Page 12: Connecting Power
CONNECTING POWER The power cable color coding is given in figure 6: Wire Color Symbol Conductor ated • Connect the black wire to live Black live White neutral • Connect the white wire to neutral green/yellow ground (earth) ion. • Connect the green/yellow wire to ground (earth) Figure 6: Connecting AC Power For a temporary outdoor installation the mains cable must be fitted with a grounded connector intended for exterior use. -
Page 13: Installation Poi Fixture
INSTALLATION POI FIXTURE IDENTIFICATION AND TERMINOLOGY A: 24 LEDs 5 Red, 5 Green, 5 Blue, 9 White B: Tilt lock C: Cooling fans D: Rubber feet (POI n/a) E: GORE-TEX membrane F: Power in and out G: DMX in and out H: LED Indicator (POI only) I: Barndoors attachment points (x2) J: Handle... -
Page 14: Unpacking
TO DO CONFIGURATION AND ANY TROUBLESHOOTING BEFORE MOUNTING IS COMPLETE. UNPACKING Unpack the device and inspect it to ensure that it has not been damaged during transport. The i-6 Series are shipped with: • 1 x Spanner with magnet (POI version). • 6 x M-10 screws (POI version). -
Page 15: Settings And Fixture Defaults
PLEASE NOTE! AT A MINIMUM, ALL FIXTURES WILL NEED TO BE GIVEN A DMX ADDRESS AND DMX PERSONALITY IN ORDER TO PATCH AND PROGRAM ON A CONTROL- LER. REFER TO MANUALS FOR MORE DETAILS. Figure 9: Connecting data to USB up-loader cable for POI fix- tures SETTINGS AND FIXTURE DEFAULTS All configuration of POI fixtures is done through the SGM Addressing Tool. -
Page 16: Wireless Data Connection
Factory Defaults are as follows: • DMX address = 1 • Fan mode = Standard • Dimming curve = Gamma Corrected • Led frequency = Dimming optimized • DMX mode/personality = Default mode (6 channel • Master slave = Disabled CTC) •... -
Page 17: Mounting
MOUNTING All SGM POI fixtures have M10 size attachment points to mount the supplied brackets or directly to a structure. The POI wash fixture may be installed in any orientation and it might take up to two brackets per fixture. Depending on the structure, please use appropriate and secure methods for mounting the Omega brackets. -
Page 18: Flat Bracket Attachment
FLAT BRACKET ATTACHMENT M10 Countersunk Bolts Flat Bracket 8mm or smaller screw or bolt to structure 8mm or smaller screw or bolt to structure Fixture OMEGA BRACKET ATTACHMENT M10 Stainless Steel Bolts 13mm / 0.5in hole diameter for attachment point POI Omega Bracket Fixture Product Version 1.0 | Revision B | Released 2023-02-13... -
Page 19: Universal Bracket Attachment
UNIVERSAL BRACKET ATTACHMENT Using a bolt through this slot, M10 Countersunk Bolts the fixture will rotate around its center point, always use 2 bolts with washers. POI Universal Bracket Using a bolt through this slot, the fixture will rotate around its center point, always use 2 bolts with washers. -
Page 20: Wall Bracket Attachment
WALL BRACKET ATTACHMENT Medium 6/8 Series Attach and align the bracket to a surface. The shorter side of the bracket is the side that attaches to a wall surface. There are two slots provided to align the bracket. Using appropriate fas- teners, align and level the bracket. -
Page 21: Poi Tilt Lock
POI TILT LOCK The fixture can be tilted in any orientation. To adjust the tilt angle in POI fixtures: • Loosen the two tilt lock kobs (one on each side) by turning them counter-clockwise using the small pig-nose key. Tilt the fixture to the angle de- sired and hold it. -
Page 22: Permanently Connecting Power & Data
PERMANENTLY CONNECTING POWER & DATA PLEASE NOTE! POI FIXTURES MUST BE TERMINATED IN SUITABLY IP RATED ENCLOSURES, AND WITH CABLE CONNECTIONS MEANT FOR DIGITAL DATA SIGNAL. Figure 15: Connecting DMX and AC Power in POI The last fixture in line must have a resistor installed between the yellow and black data out wires. This is to terminate the DMX signal, according to the RS-485 signal protocol. -
Page 23: Wireless
WIRELESS In POI versions with wireless, it is necessary to pair the fixture with a new transmitter (by default, the fixture is linked to the SGM factory transmitter during the testing and QA process). In order to do so, make sure the fixture is powered on before taking the following steps: •... -
Page 24: User Interface
USER INTERFACE The i-6 Series can be set up by using the control panel and OLED multi-line display on fixture’s head or through RDM. PLEASE NOTE! IN POI VERSIONS THE DISPLAY IS REPLACED BY AN INDICATOR LIGHT. THE ADJUSTMENTS ARE MADE THROUGH RDM. -
Page 25: Display
DISPLAY OPERATIONAL MODE (A) Displays the current mode (quick color, stand-alone, or DMX mode). The fixture is set by default to be controlled in DMX mode. 6CH CTC MODE (107) DMX ADDRESS (B) A - Operational mode Displays the current DMX address. The DMX address is al- B - DMX address tered directly from this view. -
Page 26: Configuring The Device For Dmx Control
Confirm the chosen mode by pressing ‘Enter’. DMX CHARTS The i-6 Series operates in different DMX modes. Each DMX mode has its own DMX chart. All DMX charts are available for download at www.sgmlight.com under the respective product, or upon request via support@sgmlight.com... -
Page 27: Setting A Static Color Manually
SETTING A STATIC COLOR MANUALLY The i-6 standard can be configured to display a predefined and static color. To set up a static color select ENTER → MANUAL → QUICK COLOR. Note that, once the MANUAL → QUICK COLOR settings are changed, the fixture will be set, by default, to automatical- ly start in quick color mode whenever it is powered on. -
Page 28: Fixture Properties
FIXTURE PROPERTIES FACTORY DEFAULT When restoring the i-6 to the factory defaults, the follow- • Display saver = Off ing settings will be set: • Flip screen = Off • DMX address = 1 • RDM device label set to = Fixture type name •... - Page 29 Setting LED refresh rate (Frequency) When using LED lighting with cameras, flickering can occur due to incompatible frequency settings which means the LEDs and cameras are not synchronized. In order to avoid flickering and horizontal banding (rolling shutter) the i-6 offers the ability to adjust the refresh rate (frequency) in order to achieve flicker-free performance. In the i-6 menu, go to SETTINGS →...
-
Page 30: Control Menu
CONTROL MENU LEVEL 1 LEVEL 2 LEVEL 3 FUNCTION Mode Select Mode Select DMX mode. Info Product Type Displays product type. Firmware Version Displays installed firmware version. Hardware Revi- sion Serial Number Displays SGM serial#. RDM ID Displays RDM ID (Unique RDM ID for identification). DMX View Up to 504 DMX addresses Displays received DMX levels. - Page 31 LEVEL 1 LEVEL 2 LEVEL 3 FUNCTION Manual* Macro Color Macro color Editor High Speed High speed mode Editor Program Program Editor Quick Color Run Macro Run High Speed Run Program Run 1, 2 or 3 Run internal sequence 1, 2 or 3. Stop Stop current running internal sequence or Quick Color.
-
Page 32: Rdm
SUPPORTED RDM FUNCTIONS The i-6 Series features support for various RDM functions. RDM (Remote Device Management) is a protocol enhancement to USITT DMX512 that allows bi-directional commu- nication between the fixtures and the controller over a standard DMX line. This protocol will allow configuration, sta- tus monitoring, and management. -
Page 33: Accessories
The Vacuum Test Kit is an accessory suitable for all SGM IP-rated fixtures, made for testing the IP integrity upon reassembly. In order to ensure the IP-rating of the i-6 Series, it’s highly recom- mended that the fixture is always vacuum tested after installing or swapping any part that might compromise the IP-rating, e.g.,... -
Page 34: Firmware Updates
USB - POI UPLOADER CABLE The SGM USB to DMX cable is an accessory used mainly to update the fixture with the latest SGM firmware. See below how to update the fixture with the latest firmware. The SGM Uploader cable is also used for controlling the DMX val- ues channel by channel through the Firmware Uploader Tool soft- ware (available for download at www.sgmlight.com). -
Page 35: Cleaning
CLEANING SGM fixtures with IP65 or IP66-rating do not need any cleaning procedures inside the fixture. However, cleaning the front lens may be needed to achieve the maximum light output after exposure to dust, sand, or dirt. The exterior housing can also be cleaned to get a better look. To maintain adequate cooling, fans must be cleaned periodically. Whenever necessary, clean the fixture using a soft cloth dampened with a solution of water and a mild detergent. -
Page 36: Troubleshooting
TROUBLESHOOTING PROBLEM POTENTIAL CAUSE(S) REMEDIES Fixture does not respond or appears No power to the fixture. Confirm that the power is switched on, confirm that to be off. the cables are plugged in. Main fuse is blown. Contact your local SGM dealer or support@sgmlight. Fixture suddenly turned off. -
Page 37: Fixtures And Accessories
I-6 W, 2.3deg, POI, BL ................P/N: 80251780 i-6 SERIES ACCESSORIES Omega bracket w/Q-bolt,, BL / WH . -
Page 38: Support Hotline
SUPPORT HOTLINE SGM offers 24/7 technical support. Worldwide: +45 3840 3840 US: +1 407-242-6217 support@sgmlight.com APPROVALS AND CERTIFICATIONS Conforms to ............... 2014/35/EU: Low Voltage Directive Conforms to . -
Page 39: User Notes
USER NOTES Product Version 1.0 | Revision B | Released 2023-02-13... - Page 40 SGM LIGHT A/S Sommervej 23 8210 Aarhus V Denmark Tel: +45 70 20 74 00 info@sgmlight.com www.sgmlight.com Product Version 1.0 | Revision B | Released 2023-02-13...
