- Page 1 DC/DC converter --- Product: SLA-DCDC-30W Document: User Instructions Manual Rev: 06 Date: 26. April 2023 Company: AED Vantage DC/DC converter SLA-DCDC-30W User Instructions Manual Public – Page 1 of 23...
- Page 2 DC/DC converter --- Product: SLA-DCDC-30W Document: User Instructions Manual Rev: 06 Date: 26. April 2023 Company: AED Vantage Classification: Public Revision: 06 Date: 26. April 2023 REVISION HISTORY REV DATE AUTHOR DESCRIPTION 26.04.2023 Alexandra Voß Rebranding Update the CE certificates referencing the RoHS EU Directive Updated Storage and Transport Temperature 14.09.2020...
-
Page 3: Table Of Contents
DC/DC converter --- Product: SLA-DCDC-30W Document: User Instructions Manual Rev: 06 Date: 26. April 2023 Company: AED Vantage Table of contents Introduction .............................6 General Information ........................6 Further products..........................6 Available manuals ..........................6 Pictograms ............................6 Safety Notes ............................7 General safety instructions ......................7 Product liability..........................8... - Page 4 Company: AED Vantage Table of figures Figure 4.1-1 Nameplate of the SLA-DCDC-30W ....................11 Figure 4.2-1 Front side ports of the SLA-DCDC-30W ..................12 Figure 4.2-2 Front view of Power INPUT connector ..................13 Figure 4.2-3 Summary of LED status ......................13 Figure 6.2-1 Web interface shows configuation editor .................16 Figure 6.2-1 SLA-DCDC-30W connected to SLA .....................17...
- Page 5 DC/DC converter --- Product: SLA-DCDC-30W Document: User Instructions Manual Rev: 06 Date: 26. April 2023 Company: AED Vantage Terms and Acronyms Term/Acronym Definition Adapter-Board Camera Serial Interface Direct Current Electronic Control Unit European Economic Area Electrostatic Discharge FPD-Link Texas Instruments Flat Panel Display Link...
-
Page 6: Introduction
Company: AED Vantage 1 Introduction 1.1 General Information The SLA-DCDC-30W is a galvanic isolated power source and is designed for use in a MTA-System in an automotive environment. This manual contains important advice, notes, and information about the SLA-DCDC-30W. Read this manual carefully. -
Page 7: Safety Notes
Contact the manufacturer if repair is required Caution Safety and functional defects due to incorrect accessories and spare parts Accessories or spare parts that are not recommended by AED Vantage GmbH may have adverse effects on the safety and functionality of the device. ▪... -
Page 8: Product Liability
• The device is not used according to the user manual or according to the described scope. • Modifications are done to the device without permission of AED Vantage GmbH. • Installation instructions of the device are not fulfilled. Public... -
Page 9: Terms Of Use
The device is designed to be used for engineering purpose only. Special care has to be taken during operation of the device. Installation in series production cars is not scope of this product. The usage of the SLA-DCDC-30W must apply to all of the described installation instructions (User Instructions Manual). -
Page 10: Intended Use And Integration Into System
Users must be qualified in electronic or electrical engineering. • Users must be qualified for using measurement instrumentation. • The SLA-DCDC-30W is for industrial environments only. No use in personal or domestic areas. • The SLA-DCDC-30W is for test vehicles only (no use in series vehicles) •... -
Page 11: Installation And Operation
Rev: 06 Date: 26. April 2023 Company: AED Vantage 4 Installation and Operation 4.1 Identification A laser engraved nameplate on the top of the SLA-DCDC-30W contains the following information: Figure 4.1-1 Nameplate of the SLA-DCDC-30W • P/N: Device type and version •... -
Page 12: Connections And Controls
Connector type TE 2-929425-1, 10 pin, male connector Status LED LED indicates the status of the SLA-DCDC-30W Power OUTPUT Output voltage +12 VDC Connector type MOLEX 172310-1104, 4 pin, male connector Figure 4.2-1 Front side ports of the SLA-DCDC-30W Public – Page 12 of 23... -
Page 13: Figure 4.2-2 Front View Of Power Input Connector
Company: AED Vantage Power INPUT By default, the SLA-DCDC-30W must be supplied with 12 VDC voltage. According to the technical datasheet it can also operate with power supplies between +4,5 VDC and +30 VDC. You can download this document at the AED wiki see section 10.4. - Page 14 DC/DC converter --- Product: SLA-DCDC-30W Document: User Instructions Manual Rev: 06 Date: 26. April 2023 Company: AED Vantage Power OUTPUT The output voltage of 12 VDC +/- 5% is fixed and can be variable between the variants of the product. The output power range goes up to 30 Watts and the inputs and outputs are galvanically isolated.
-
Page 15: Installation Location
It is the responsibility of the user to provide sufficient cooling by keeping the SLA-DCDC-30W within its specified temperature limits in all cases. Further details are provided in the technical data sheet. You can download this document from the AED wiki see section 10.4. -
Page 16: Quick Start Guide
4.2. The SLA-DCDC-30W will start up automatically. 6.2 Functional description The SLA-DCDC-30W is an isolated DC/DC converter with a wide input voltage range and up to 30 Watts output power. The output voltage is fixed and can be variable between the variants of the product. The inputs and outputs are galvanically isolated. -
Page 17: Example Use Case
Company: AED Vantage 7 Example use case The following figure shows the SLA-DCDC-30W connected to the SLA with an output power cable. In this case, the SLA-DCDC-30W converter supplies the SLA and the adapter-board with power. This application takes place in an automotive environment. -
Page 18: Technical Specification
Document: User Instructions Manual Rev: 06 Date: 26. April 2023 Company: AED Vantage 8 Technical specification The following table provides an overview of electrical and technical data of SLA-DCDC-30W. Property Value/ Characteristic Max. output power 30 W @ 25 °C Max. -
Page 19: Storage, Transport And Disposal
Protect the SLA-DCDC-30W from strong sunlight, heat and shocks • Do not place any object on the SLA-DCDC-30W • Store the SLA-DCDC-30W in a dry, dust-free and ESD safe area 9.2 Transport Transport conditions of the SLA-DCDC-30W: • Transport temperature: -40 °C …... -
Page 20: Maintenance And Service
Observe section 4 Caution Safety and functional defects due to incorrect accessories and spare parts Accessories or spare parts that are not recommended by AED Vantage GmbH may have adverse effects on the safety and functionality of the device. ▪... -
Page 21: Repair
In case of any malfunction or defect to the device please contact SLA support (see section 10.4) before sending the device to AED Vantage GmbH. AED will decide if a hardware defect occurs and if the RMA procedure comes to use. Customers will receive an RMA number and will be informed about the next steps. - Page 22 DC/DC converter --- Product: SLA-DCDC-30W Document: User Instructions Manual Rev: 06 Date: 26. April 2023 Company: AED Vantage Public – Page 22 of 23...
- Page 23 DC/DC converter --- Product: SLA-DCDC-30W Document: User Instructions Manual Rev: 06 Date: 26. April 2023 Company: AED Vantage AED Vantage GmbH Taunusstraße. 51 80807 München www.aed-vantage.com sla-support@aed-vantage.com Public – Page 23 of 23...
