- Page 1 XIM638961-R1 - 11/23 years Adventure Rover ™ ASSEMBLY INSTRUCTIONS #638961M8 Adult assembly required. Approx. assembly time: 50 min.
- Page 2 • Clear a flat surface to lay out all the materials so everything is close at hand. • You will need a Phillips head screwdriver (power driver, recommended, not included) hammer and safety glasses (not included) to assemble the Adventure Rover™. - When installing screws, be sure screws are tightened snugly, but do NOT OVERTIGHTEN.
- Page 3 The Little Tikes Company makes fun, high quality toys. We warrant to the original purchaser that this product is free of defects in materials or workmanship for one year * from the date of purchase (dated sales receipt is required...
-
Page 4: Hardware Guide
BEFORE you begin assembly, make sure you have all the parts listed below. Some packages of hardware may have extra pieces. Questions? We’re here to help. Little Tikes customer service team at 1-800- 321-0183. Tools required (not included) Included in hardware pack (1). Discard after use. - Page 5 Door latch (2) Right (1) Steering wheel (1) Left (1) Roof (1) Body (1) Door (2) Steering O ring (1) Roof Pillars - FRONT Roof Pillars - REAR Steering clip (1) Roof pillars - Roof pillars - Roof pillars - Roof pillars - front left (1) front right (1)
- Page 6 Start with the dashboard decals! Before installing steering wheel, apply decals 4 - 7 to dashboard. Let’s get the horn working WARNING: Remove battery cover before pulling tab. Snap horn (part J) into center of Remove battery cover on horn (part J) steering wheel (part E) Pull clear tab from horn unit to activate.
-
Page 7: Steering Wheel
Steering wheel...in a Click! Steering clip should snap into MIDDLE Squeeze steering clip (part I) hole on each side of the steering column. into steering wheel (part E). Insert steering wheel through hole in dashboard Make sure the steering clip AND through the steering O ring (part F). - Page 8 REAR wheels...get in the groove. bushing washer wheel hubcap Slide onto rear axle (1) hubcap (O), (1) wheel (P), (1) bushing (CC) and (1) washer (BB). bushing washer Slide assembled axle through rear axle guides. Slide (1) washer (BB) then (1) bushing (CC). hubcap Slide wheel (P), then wheel...
- Page 9 REAR wheels...last step. Flip the coupe on its side. Place a (1) top hat (AA) and the top hat tool over the OPEN end of the axle. Hammer the top hat onto axle. Top hat tool Top hat Do not hammer on surfaces or items you don’t want to break, mark or dent.
- Page 10 FRONT wheels...cont. Place the top hat, top hat then the top hat tool onto open end of axle. Hammer top hat onto the axle. REPEAT these steps for Top hat tool RIGHT front axle FRONT wheels...rolling along! First, slide washer (BB), then bushing (CC) onto assembled right axle.
- Page 11 FRONT wheels...cont. bushing bushing Insert bushing (CC) onto each axle and push in place IMPORTANT! Check axle positions - roll the Adventure Rover forward - HUBCAPS STOP SHOULD BE FACING OUTWARD. WRONG CORRECT WRONG...
- Page 12 Caps and snaps! Insert top hat (AA) onto the top of each axle and hammer into place. Top hat tool top hat Top hat Top hat tool Align slots and snap on (4) center caps (part N). Choose your lock! First, install door latch (part C) into door (part B) Attach using (1) "...
- Page 13 Choose your lock! - cont. Next, insert Right and Left doors (part B) into body. Front pillars pop right in For Ease of Assembly: apply 1 tbsp. of liquid soap to surface. Roof Pillars - FRONT Insert FRONT right (part G2) and left (part G1) pillars into roof.
- Page 14 REAR pillars... insert, pull back, turn! BEFORE YOU START: match roof pillars marked “L & R” to the correct side of roof also marked “L & R”. Roof Pillars - REAR PUSH DOWN PULL Hook the ROUNDED END of Pull the REAR roof pillar the REAR roof pillar (part toward you to fully insert the H1) into the roof (part D) and...
- Page 15 REAR pillars... insert, pull back, turn! TURN Repeat steps for the roof pillar - rear LEFT (part H2). For Ease of Assembly: Turn the roof pillar around. The Little apply 1 tbsp. of liquid Tikes logo should be facing outward. soap to surface.
- Page 16 Let's put it all together! (4) large fastener Line up holes in body with holes in rear roof supports to install fasteners Person 1: hold down roof assembly. Person 2: install (2) fasteners (2 each side) Repeat on the other side Need a windshield...
- Page 17 2b 11 View of the stars! (5) short plastic fasteners Install using (5) short plastic fasteners. Insert roof panel (part Q) 0nto the roof. 2b 12 Radar detection... " (1.27 cm) Insert radar dish support (U2) into the radar dish (U1). Assemble the radar dish nut (U3) onto the other end of the support.
- Page 18 LAST STEP...let’s finish with the decals! Decals must be applied to a clean, dry surface. Wipe clean with a dry rag before application. Remove air from under decals by applying pressure to the decals starting from the center, and work towards edges. NOTE: If decals bubble, prick with a pin to remove the air. Decals are located in the bottom of the cardboard box.
- Page 19 Floorboard needs buttons! Insert (2) floorboard buttons (part S). For parent controlled push rides, install the floorboard. STOP Line up openings in floorboard (part T) to floorboard buttons. Once buttons are inserted into floorboard, push down to secure in place.
