SCP 998-DO-EXT Instruction Manual

www.scpcat5e.com
Toll Free USA
sales@scpcat5e.com 1-866-470-5742

PLUG AND PLAY INSTALLATION

|
Before installing the cable, make sure that you have an
HDMI graphic card or devices with an HDMI port (for
example, a PC, laptop, DVD/Blu-ray player or any other
video/audio signal source device).
998-DO-EXT can be damaged if it is excessively
pinched or twisted when being installed and after
being installed. Make sure not to bend or twist the
cable tightly.

INSTALLATION

| |
The 998-DO-EXT HDMI dongle extender kit is designed
to work with the specially designed SCP pre-terminated
SCP-EasyFiber™ patch cords with MPO connectors (Part
number series EFP-998-P-XX and EFP-998-LSZH-XX). SCP
EasyFiber is an ultra-bendable optical fiber that is
designed for in-wall or outdoor installations. The
SCP-EasyFiber MPO patch cables are Indoor/Outdoor
rated and is available in micro-armored UL OFNP and/or
LSZH with B2ca EuroClass rating.
1. Unpack the dongle extenders from the box.
Notice that one dongle is for the Display side and
the other is for the Source side.
2. Remove the MPO/MPO SCP-EasyFiber™ patch cable.
(sold separately)
3. For in-wall installations, use the Pulling Capsule
by inserting the MPO connector into the plastic
capsule and close. The EasyFiber patch cable can
then be pulled through conduit or installed
without conduit behind walls. When installing be
sure to always use the pulling capsule as it
protects the MPO connector ends.
4. After the EasyFiber patch cable has been installed
to the Display and Source device, attach the
Display Dongle end to the MPO connector by the
Display. Install the Source Dongle end to the
MPO connector at the Source device.
1.
2.
3. \\\\
4.
|
5. Remove the (2) USB External Power cords from
the box. The 998-DO-EXT dongles require USB
external power at the Display device. Plug the
power jack into the Display dongle and attach the
USB end to the USB port on the Display. [If
necessary, USB power may be needed at the
Source end as well.]
6. Insert the HDMI connector ends into the HDMI or
FRL port on both the Display and Source.
7. DO NOT plug the Display dongle into the Source
device and DO NOT plug the Source dongle into
the Display device.
8. Power up both the Source and Display devices
after Dongles have been connected. If required,
connect the USB external power on the Source
dongle and Source device USB socket.
Note: The SCP EasyFiber MPO patch cables are available in
various lengths. These cables can be daisy chained up to
1000ft/300m. To daisy chain, use the MPO coupler (part
EFP-MPO-COU) that can be ordered separately.

TROUBLESHOOTING

| |
If you have encountered a problem, check that:
• The source and display devices are both
switched on.
• Both HDMI connector heads are fully plugged into
the devices.
• The cable jacket is not physically damaged.
• The cable is not bent or twisted.
Note that it is important to connect the cable
correctly as marked on the end of each connector:
SOURCE to the source device and DISPLAY to the
display device.
5
INSTRUCTION
MANUAL
PART NUMBER
998-DO-EXT
48Gbps HDMI Dongle Adapter Extender Kit -
TX & RX 8K Dongles, Supports v2.1. HDMI
Type A (m) / MPO (f), (2) USB Power cables
and (1) Pulling Capsule.
*SCP-EasyFiber patch cable sold separately
