WiSilica lumos controls SENOR E Installation And Quick Start Instructions

SENOR E
Beacon & Range Extender
INSTALLATION AND QUICK START SHEET

WARNING AND GUIDELINES!!!

Read and follow all safety instructions!!
DO NOT INSTALL DAMAGED PRODUCT! This product has been properly packed so that
no parts should have been damaged during transit. Inspect to confirm. Any part
damaged or broken during or after assembly should be replaced.
WARNING : TURN THE POWER OFF AT THE CIRCUIT
BREAKER BEFORE WIRING
WARNING: Risk of Product Damage
Do not modify the product
Do not mount near gas or electric heater
Do not use product for anything other than its intended use
WARNING - Risk of Electric Shock
Verify that supply voltage is correct by comparing it with the product information

PRODUCT OVERVIEW

Senor E is a USB powered Beacon & range extender with
external antenna. It is a part of Lumos Controls ecosystem,
which includes controllers, sensors, switches, modules, drivers,
gateways, and analytical dashboards.
Do's
Installation should be performed by a
qualified electrician
Installation shall be in accordance with
all applicable local and NEC codes
Observe the correct polarity of output
terminal
Place devices as far away as possible
from metallic materials
Devices work best in when there is a
clear LOS between them
When placing devices inside metallic
boxes, please ensure the antenna
comes out of the boxes

Specifications

Value
Input voltage 5VDC
Input current 15mA
Frequency range 2402-2480MHz
8dBm
Tx Output power
Rx sensitivity -92dBm
Antenna Stick or 600mm wire antenna
Operating temperature
-40 to 50°C(-40 to 122°F)
Storage temperature -40 to 85°C(-40 to 185°F)
Relative humidity 85%
Dimensions 2.56 x 1.15 x 0.9in(66.7 X 29.2 X 22.4mm)
Mounting
Wall/Surface mounting
REQUIRED TOOLS &
Don'ts
Don't use outdoors
Avoid input voltage exceeding
maximum rating
Don't dissemble the products
Remarks
USB Type-A
Typical current
_
Conductive
_
_
_
_
_
L x W x H
SUPPLIES
Screwdriver
Screws Wall plug
