WIFI DONGLE FOR SOLAR INVERTER
Thank you for selecting and buying V-TAC Product. V-TAC will serve you
the best. Please read these instructions carefully & keep this user manual
handy for future reference. If you have any another query, please contact
our dealer or local vendor from whom you have purchased the product.
They are trained and ready to serve you at the best.
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST
DEALERS. V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
INSTRUCTION MANUAL
INTRODUCTION
Multi-Language Manual QR CODE
Please scan the QR code to access the manual
in multiple languages.
MODEL
SKU
VT-660000
11378, 11528
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for V-TAC VT-660000
Summary of Contents for V-TAC VT-660000
- Page 1 Please scan the QR code to access the manual in multiple languages. IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS. V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B...
-
Page 2: Download App
ENGLISH WARNING 1. Please make sure to turn off the power before starting the installation. 2. Installation must be performed by a qualified electrician. This marking indicates that this Caution, risk of product should not be disposed electric shock. of with other household wastes. NOTICE: Please read this manual carefully before using products and keep it in the place where O&M providers can easily find. - Page 3 ENGLISH 1. Stick Logger Installation Type 1 Type 2 Step1: Assemble logger to the inverter Step1: Assemble logger to the inverter communication interface as shown in the communication interface as shown in the diagram. diagram. Warning: Please do not hold the logger body to rotate while install or remove the logger.
- Page 4 ENGLISH ABNORMAL STATE PROCESSING If the data on platform is abnormal when the stick logger is running, please check the table below and according to the status of indicator lights to complete a simple troubleshooting. If it still can not be resolved or indicator lights status do not show in the table below, please contact Customer Support.
- Page 5 ENGLISH USAGE METHODS AND NOTICES FOR RESET BUTTON Usage methods and key-press descriptions for Reset button Usage: Press Key-press Status Descrip�on Light Status Short press 1s SMARTLINK rapid networking status. NET light flashes fast for 100ms. Long press 5s Reboo�ng the s�ck logger. All lights are ex�nguished immediately.
- Page 6 ENGLISH 3.Add a Logger Method 1: Enter logger SN manually. Method 2: Click the icon in the right and scan to enter logger SN You can find logger SN in the external packaging or on the logger body. 4.Network Configuration After the logger is added, please configure the network to ensure normal operation.
- Page 7 ENGLISH Step 2 ： Connect to AP network Click "Go to connect" and find the right "AP_XXXXX" network (XXXXX Refers to logger SN). If the password is required, you can find the password on the logger body. Go back to SOLARMAN Smart APP, after connecting to AP network.
