Summary of Contents for Karel ST30

  • Page 1 GRAPHIC DISPLAY FEATURE TELEPHONE SET TECHNICAL REFERENCE AND USER GUIDE...
  • Page 2 GRAPHIC DISPLAY FEATURE TELEPHONE SET TECHNICAL REFERENCE USER GUIDE MAY-2010...
  • Page 4 10.05.2010 / AAB ST30 TTKK - Ver. AAB - 10.05.2010 KAREL reserves the right to make modifications in product features mentioned in this document for development and improvement purposes, without prior notice. Individual products may possess characteristics different from those that have been mentioned in...
  • Page 5 · Do not make any connection other than the extension connection of the KAREL telephone system. · There is no part that you can repair or maintain in your device; therefore call the authorized technical service in case of any malfunction.
  • Page 6 By this way, one could understand abilities of the ST30 Graphic Display Feature Phones, how it will be operated in accordance with customer demands and things that should be done in order to operate them with full performance.

  • Page 7: Table Of Contents

    CONTENTS TECHNICAL INTRODUCTION..................1 INTRODUCTION ....................... 1 COMPATIBILITY......................1 PARTS LIST ON DELIVERY ..................1 GENERAL APPEARANCE ..................2 TECHNICAL SPECIFICATIONS................2 USER INTERFACE....................3 LCD DISPLAY......................3 ICONS........................4 DISPLAY KEYS ..................... 4 SPECIAL FUNCTION KEYS.................. 6 Park........................6 Phone Book .......................
  • Page 8 Auto Settings....................26 Do Not Disturb ..................... 27 Lazy Mode ......................27 Reminder ......................27 Sounds & Alerts ....................28 Signal Beep Option: ..................28 Keypad Sound: ....................28 Ringer Volume: ....................28 Microphone Volume Level:................28 Ring Tone: ....................... 28 Ring Cadance: ....................

  • Page 9: Technical Introduction

    TECHNICAL INTRODUCTION INTRODUCTION ST30 is a digital telephone set which is special for the KAREL exchanges of DS series. It can be installed only on the new digital extension card (UPN) of the KAREL DS- series exchanges. With the ST30 telephone sets: •...

  • Page 10: General Appearance

    GENERAL APPEARANCE TECHNICAL SPECIFICATIONS Weight: 900 gr Dimensions: · When the display is vertical: 225 mm x 230 mm x 130 mm · When the display is horizontal: 225 mm x 270 mm x 75 mm Operational Temperature: 0 C - 40 Storing Temperature: -20 C - +60 Humidity: 10 - %80 (non-condensing)

  • Page 11: User Interface

    USER INTERFACE LCD DISPLAY ST30 telephone has graphical display for information presentation and it can be positioned in 5 different levels. The following information that facilitates usage is present on the LCD display, which indicates the active features of the telephone and the functions of the flexible keys at that moment: •...

  • Page 12: Icons

    DISPLAY KEYS These keys are located below the display and they play an important role in usage of ST30. Actions that can be carried out and/or information that can be received by a user while: a call / conversation is being made...
  • Page 13 These keys are used for accepting or declining the alternatives presented to the user on the display at that moment, or they are used for accessing new alternatives. Functions that will be activated by those keys or title of the information to be accessed are indicated on the display.

  • Page 14: Special Function Keys

    For ST30 users, if there are parked line and also parked internal call and if another service is activated, the internal line call will be retrieved in turn with this key.

  • Page 15: Phone Book

    Phone Book This key provides access to the telephone book, which has been created through the main menus that have been accessed by using the “Menu” key or its option on the display, which contains names and phone numbers and over which operations on those entries could be carried out.

  • Page 16: Transfer

    GSM by “Transfer” key. If there is an incoming call on the active GSM, pressing this key puts the call on hold and in the meantime ST30 can be used for other operations. GSM call can be continued by pressing again the Transfer key.

  • Page 17: Voice Control Keys

    VOICE CONTROL KEYS Control of voice features of ST30 are fulfilled by making use of four keys: “ ” Key: (Handsfree: It is a feature of telephone that it emits voices into the room or transmits voices inside the room to the other parties while the handset is still on hook.) This is the key with red icon that puts the telephone into the “handsfree”...

  • Page 18: Speed Dial Keys

    “+”Key: It is used to increase the level of (H/F) voice received during conversation while in the Handsfree mode. When the handset is off hook and H/F is not active, it is used to increase the level of voice received during conversation. When the headset is on hook and H/F is not active, it used to increase the level of the contrast.

  • Page 19: Function Programming For The Speed Dial Keys

    This feature provides for taking advantage of some functions that have been defined for ST30 in the exchange properties, by pressing a single key. A user may program for those keys the features presented by the KAREL telephone branch exchange, which s/he would use most frequently.
  • Page 20 Phone Lock Key: · If this key is pressed while the telephone is on hook it will gets into H/F mode. If a password is entered afterwards, the telephone will be closed for external calls. The telephone will be open for external calls again, if the procedure is repeated in that mode.

  • Page 21: By Code Programming

    By “Auto Setting” Menu: In ST30 telephone sets, possibility of assigning different functions to the entire keys simultaneously is provided via the Auto Setting option under the Key Settings menu.

  • Page 22: Installation

    Under ST30, there are five connection points. Connections and their characteristics have been illustrated below. DSS CONNECTION: ST30 digital telephone set can be used with DSS25-28 module. AUXILIARY CONNECTION: The connection point that is required for programming ST30 over computer.

  • Page 23: Line Connection

    3 and 4 of the RJ11. Only a single ST30 can be connected to each of the groups of two. Number of ST30s that will be connected to the exchange and accessories using the external data line of the exchange should not exceed 25 in total.

  • Page 24: Program Features

    PROGRAM FEATURES PROGRAMMING MENUS The user performs entrance to programming by making use of the flexibly functional key that is under the option “menu” that appears on the display or specially functional MENU key, while the telephone is off hook and dial tone is being received. In order for the user to activate the services s/he makes use of or deactivate the active ones within the program menus, a single menu comes to view.

  • Page 25: Call Options

    CALL OPTIONS Submenu titles: · Call Diversion Status § § All Calls / Extension No= § No Answer / Extension No= § On Busy / Extension No= § Busy/No Answer / Extension No= · Auto Dial Disable Last Number Private Pool / Register No= Common Pool / Register No= ·...

  • Page 26: Call Diversion

    · Extended Call Diversion facility explained above, can be used with AASC or later software version of ST30. This facility can be only supported in DS Series Systems with z_adz software version (the version of IDEA and Net-Console should be BAY and Release AAZ).

  • Page 27: Paging

    By selecting the Last Number option, the most recent number that has been dialed is automatically called. When the Private Pool option is activated, the private pool numbers, which have previously been entered into the memory by the menu “Private Pool Entry”, are automatically called.

  • Page 28: Answered

    Answered Information about the most recent 20 Answered Calls can be successively viewed including source and time of the call. In the event that there are more than one Answered Call, they can be browsed by using the navigation keys on the display. If there is Caller ID information, the “Select”...

  • Page 29: Phone Settings

    PHONE SETTINGS Submenu titles: · Key Settings Extension Line Private Pool Common Pool Feature · Follow Me Key · Call Back Key · Do Not Disturb Key · Phone Lock Key · Conference Key · Night Mode Key · Message Listen ·...

  • Page 30: Key Settings

    · Contrast · Backlight · Enblock · Line Access Code · Home Area Code · Price Meter Pulse Price Last Call · Private Pool Entry · *Language · Eprom Version System Version ST Version Key Settings Number of keys that can be programmed is 16 in total and assignments of programs are done to those.

  • Page 31: Line

    In the event that the number is correct, the message “Successful” is displayed for 1 second, OK tone is received and the Key Settings is completed. After the acceptance of the extension number, there is no message given to the user if the entered number has been programmed on another key before, the latest programmed key will be valid.

  • Page 32: Executive Key

    Executive Key Any extension who diverts his/her calls to user, can be assigned to that key. Extension who diverts his/her calls, could be thought as executive and priority can be given to the incoming calls to that executive. At that situation when user is on the phone, s/he can easily notice that there is an incoming call to executive and s/he can answer that call will a single key.

  • Page 33: Feature

    ¨ Register no: Indices that belong to the line numbers, which have been entered into the common pool of the exchange, are assigned to the programmable keys by this menu option. Even though 9 (line access code) is not appended to the beginning of the numbers that are stored in the common pool, during the calls made by using the keys, whose assignments are done in this menu, calls are made by including 9 at the beginning of the numbers.

  • Page 34: Feature Code

    Feature Code Any code of 8 digits can be assigned to the programmable keys by using this menu option. ¨ Press Key: The key, on which the programming will be done, is pressed for a short or a long period in order to select the first or the second function, respectively.

  • Page 35: Do Not Disturb

    Option 3 1.key Func1 Phone Lock 9.key Func1 Follow Me On Busy Func2 PP 1 (CP000) Func2 PP 9 (CP008) 2.key Func1 Auto-Dial 10.key Func1 Conference Func2 PP 2 (CP001) Func2 CP009 3.key Func1 Alarm 11.key Func1 Music Func2 PP 3 (CP002) Func2 CP010 4.key Func1 Do Not Disturb...

  • Page 36: Sounds & Alerts

    Sounds & Alerts Signal Beep Option: ¨ When the Enable option is selected, a special warning tone is received for an incoming call, in case the phone is busy. ¨ The warning tone is cancelled through the Disable option. Keypad Sound: ¨...

  • Page 37: Headphone

    The Bluetooth Profiles supported by ST30 are Handsfree, Headset and Handsfree- Audio Gateway. The embedded applications of the Bluetooth devices can differ from device to device, thus the ST30 compatibility problems may occur with these devices. The detailed information about the compatibility problems could be obtained from the product company or Karel International Support department.

  • Page 38: Line Access Code

    Line Access Code With this facility, if there is an incoming call that includes the Caller ID information and the “Area Code”, which has been defined before, only the Line Access Code is displayed instead of the Area Code on the screen. In order to realize it, firstly, the line access code need to be entered to the phone and saved into the memory.

  • Page 39: Price

    Any desired one out of Turkish and English language options can be selected and the telephone starts to display menu messages in the selected language. Eprom Version One can reach version information of the DS200 exchange and the ST30 telephone. ¨ System Version: Example: - Z_ADA ¨...

  • Page 40: Phone Security

    PHONE SECURITY Operations of defining / changing passwords, which are required in order to make use of features such as making calls or listening to messages through another extension within one’s own authorization limits, can be carried out through this upper menu item. Submenu titles: ·...

  • Page 41: Message

    MESSAGE It appears only when there is an installed EVM module. Submenu titles: · Absent Message Read Message · Message Listen (New Messages) All Messages Message § § Password= Absent Message ¨ Read message: By this menu, you could leave a message to be announced to people who call you when you are not at your place, provided that you confirm the message through the “Terminate”...

  • Page 42: System Settings

    Common Pool Entry ¨ In the Register no section, ST30 primarily prompts the operator for the common pool number. Then the operator enters it. That number should be of 3 digits due to the exchange storage capacity of 1000 records. The number does not need to start with line access code.

  • Page 43: Phone Book

    PHONE BOOK A phone book of 39 entries in total can be created by using this upper menu item. 16 characters are reserved for the entry of name and 20 characters are reserved for the entry of number into the Phone Book. One of the advantages of using the phone book is in the event that any information of call, conversation, missed call, hold, park or forwarding that is related to a number stored in the phone book is received, the name corresponding to that information is displayed.

  • Page 44: Add

    most similar entry starting with the same letter as the searched name is displayed. On the other hand, in the event that no entry starting with the same letter as the searched name is found, the telephone set displays the first entry that starts with the alphabetically next letter after the first letter of the searched name.

  • Page 45: Clear

    When Constant Message is selected, the entry message can be recorded or changed by using the “Constant Message” menu. Content of the entry message is KAREL by default. Clear The submenus “Find by name” and “Find by number” are located within this menu. The entry to be deleted is found by using search menus, as described above (When the searched entry is found, while the records are being displayed, the query “Clear”...

  • Page 46: Bluetooth

    Since devices with Bluetooth wireless technology communicate using radio waves, the two devices (ST30 and other device) do not need to be in direct line of sight. The two devices only need to be within 10 meters (33 feet) of each other, but the connection may be subject to interference from obstructions such as walls or from other electronic devices.

  • Page 47: Status

    Status This section is used to start or end the bluetooth connection. By using ‘Enable’ menu, bluetooth option is activated on the ST30 and the bluetooth icon is displayed on the screen. By using ‘Disable’ menu, bluetooth option is cancelled on the ST30 and the bluetooth icon is not displayed on the screen.

  • Page 48: My Devices

    ST30. If the active GSM device disables the bluetooth feature or if it is removed from the ‘My Devices’ list, the connection request that is sent by ST30 can not be responded, so there will not be a new connection request.) For paired inactive devices, “Connect”...

  • Page 49: Delete All Pairings

    NOTE: If the connection is finished by the active device, automatic connection request is not sent from the ST30 on which all pairings are deleted. Bluetooth Settings Password; For pairing with a bluetooth device, a password (1-16 characters long, numeric) must be entered.

  • Page 50: (Phone Book)

    By Make BT Call option, number can be called through the active GSM device. ¨ Save; This menu is presented when the phonebook item is not recorded in the ST30 phone book. By entering a name, number can be stored into the ST30 phone book. NOTE: The GSM phone book accessing applications can differ from model to model (and also their supported features).
  • Page 51 H/F speaker. When the headset option is in “Without Handsfree” mode, the same key ends the conversation. The last number can be dialed through the ST30 with bluetooth headset if the headset has “Redial” option.

  • Page 52: Appendix

    APPENDIX Error Messages · The system takes no action for the keys pressed during display of the messages (Error message, Line back...) that resides on the display for a specific period of time. · In the event that an incorrect operation is done while in the programming mode, the error message is displayed in two lines for one second.

  • Page 53: Accessories

    ACCESSORIES DSS25–28 DIRECT STATION SELECT MODULE DSS25–28 modules are designed as Direct Station Select modules for ST25/ST30 telephones. They facilitate extension/line/feature access by single key touch. Those keys are also used to monitor status of extensions/lines by their LED functions.
