Summary of Contents for ARMORDILLO AW99408
- Page 1 AW99408 600LBS DUMP GARDEN CART IMPORTANT: Instruction Read and follow all safety rules and operating Manual instructions before using this product.
- Page 2 11. It is recommended to inspect the cart for each usage. 12. KEEP THIS INSTRUCTION FOR FURTHER REFERENCES Tray Locking Handle Left Bracket Right Bracket Frame Bolt M8 Washer M8 Nut M8 Wheel Washer Handle Bolt M6 Washer M6 Nut M6 Axle M12 Nut Steering Assembly 10 G AW99408...
- Page 3 Repeat step for Right Bracket (D). Refer to Fig. 2. Fig 2 STEP 3: FRAME ASSEMBLY Place the Frame (E) onto the Tray (A), and insert the Axle (F) through the two Brackets (C, D) and Frame (E). Refer to Fig. 3 Fig 3 AW99408...
- Page 4 Handle to rotate cart upward into the dumping position. Returning the plastic tray to the lowered position Rotate the plastic tray back down to the lowered position. Make sure the dumping Locking Handles is locked into place when the tray is in the lowered position AW99408...
