- Page 1 User’s Manual – A S Garden Trolley REBO Garden Trolley AR-HE-GW550 Please follow all security measures in this user’s manual to ensure a secure use. Thank you for trusting in AREBOS.
- Page 2 User’s Manual – A S Garden Trolley REBO List of Content Security Instructions ........................2 Assembly............................4 Content ............................ 4 Assembly..........................5 Technical Data ..........................7 Disposal Instructions ........................8 4.1 Disposal of the packaging ......................8 4.2 Disposal of waste equipment ......................8 Imprint ..............................
- Page 3 User’s Manual – A S Garden Trolley REBO Risk of suffocation – Acute danger to life! The product includes packaging materials and small parts that can be swallowed, such as screws and nuts. If children put these in their mouths, they can choke on the individual parts! Therefore, keep your children and pets away from all small parts and packaging material.
- Page 4 User’s Manual – A S Garden Trolley REBO 2. Assembly 2.1 Content Figure 1: Delivery volume Delivery volume: 4x wheels 1x front axle with handle and drawbar 1x rear axle 1x grid floor 2x side rails 1x front grille 1x rear grille 1x screw set 1x fabric inlay 1x grid shelf...
- Page 5 User’s Manual – A S Garden Trolley REBO 2.2 Assembly 1. Place the rigid axle on the grid floor and fasten it with two washers and nuts (M10, spanner size 17mm). Mount the drawbar on the steering axle. The screws (M10x60) are passed through the steering axle from above, through the drawbar and fixed with washers and nuts (M10, spanner size 17mm).
- Page 6 User’s Manual – A S Garden Trolley REBO 3. Put the trolley on its wheels. Attach the handle to the drawbar. The handle can be mounted vertically or horizontally, as desired. Use the supplied M8x60 screw, washers and nut M8 (spanner size 13 mm) Figure 4: Mounting the handle 4.
- Page 7 User’s Manual – A S Garden Trolley REBO 5. Mount the “L-bolts” with washer and nut (M8, spanner size 13 mm) on the upper corners. Figure 6: Mounting the "L-bolt" 6. In the last step the fabric inlay and the storage compartment are inserted. Figure 7: Garden trolley with fabric inlay and compartment 3.
- Page 8 Authorised representative for the technical documentation: Korhan Canbolat Office address: Canbolat Vertriebs GmbH Gneisenaustraße 10-11 97074 Würzburg Return address can be found in the imprint: https://www.arebos.de/impressum/ VAT identification number: DE 263752326 Court of the Commercial Register is Würzburg, HRB 10082 WEEE Reg.-No. DE 61617071...
