Summary of Contents for AREBOS AR-HE-SB800
- Page 1 User’s manual – A S starting aid& battery charger REBO Starting aid & battery charger AR-HE-SB800 Please follow all security measures in this user’s manual to ensure a secure use. Thank you for trusting AREBOS.
-
Page 2: Table Of Contents
User’s manual – A S starting aid& battery charger REBO List of contents 1. Safety instructions ..........3 1.1 Explanation of the symbols ............3 1.2 General safety instructions ............4 1.3 Electrical residual hazards ............5 2. Technical data ............5 3. -
Page 3: Safety Instructions
User’s manual – A S starting aid& battery charger REBO Please read and safe these instructions. Read through this user’s manual carefully before using this product. Protect yourself and others by observing all safety information, warnings and cautions. Failure to comply with instructions could result in personal injury and/or damage to product or property. -
Page 4: General Safety Instructions
User’s manual – A S starting aid& battery charger REBO 1.2 General safety instructions • This battery charger may only be used by persons over the age of 16. An exception is made for use as a young person if it is used in the course of vocational training to achieve the skill under the supervision of an instructor. -
Page 5: Electrical Residual Hazards
Inappropriate local lighting: • Poor lighting represents a high safety risk. Always ensure adequate lighting when working with the device. 2. Technical data Model AR-HE-SB800 230 V; 50/60 Hz Charging voltage 12 V/24 V Charge current effective 50 A Start current effective... -
Page 6: Commissioning
User’s manual – A S starting aid& battery charger REBO 3. Commissioning 3.1 Before the charge Number of parts Designation 12 V Connection Ground connection 24 V connection Fuse Ammeter Step switch charge/start • ATTENTION: The mains plug must be disconnected before changing or adjusting the battery charger. -
Page 7: Charging Function
User’s manual – A S starting aid& battery charger REBO 3.2 Charging function • Connect the charger to the battery to be charged. • Always connect the black pole cable to the negative pole first, then to the positive pole. •... -
Page 8: Proper Use
User’s manual – A S starting aid& battery charger REBO the vehicle! • The vehicle should always be started with 2 persons. • The first person operates the start switch on the charger. The second person starts the ignition process immediately. •... -
Page 9: Bug Fixing
User’s manual – A S starting aid& battery charger REBO • Use a damp cloth to clean the plastic parts. Do not use cleaning agents, solvents or pointed objects. • Use a soft brush or brush to remove stuck dust from the ventilation opening and moving parts after each use. -
Page 10: Disposal Instruction
User’s manual – A S starting aid& battery charger REBO 7. Disposal instruction 7.1 Disposal of the packaging • Please make reference to the guidelines and standards for appropriate disposal of the packaging valid in your region. In part, the package may consist of plastic bags – watch this respect, with special care to ensure that this is not out of the reach of children. - Page 11 Hereby declare that the product named below, seen its design and construction as well as according to our sales, has been complied with the relevant and basic health and safety EU-requirements. Name of the product: Arebos starting aid & battery charger Art. Nr.: 426055189850 Model Nr.: AR-HE-SB800...
