Summary of Contents for UVISAN UV Cleantech VR12

  • Page 1 USER MANUAL info@uvcleantech.com www.uvcleantech.com +61 3 9028 4555 Recommended by PORTABLE ELECTRONICS, TOOLS AND ACCESSORIES CHARGING & DISINFECTION...
  • Page 2: Table Of Contents

    CONTENTS Safety Guide Features Technical Data Model Varieties Controls and Programming Setup of Device Cleaning and Maintenance Troubleshooting Warranty Appendix - Setting Charging Time Appendix - UVC Digital Timer Programming Instructions...
  • Page 3: Safety Guide

    SAFETY GUIDE Working Environment: Uvisan products are designed to work in ambient temperatures (18-30˚C). Do not operate the cabinets in the following environments: Outdoor location In direct sunlight Wet/humid environment Unstable or unevem surface Near emergency exits or firefighting equipment...
  • Page 4 SAFETY GUIDE Safety Note: The charging cart must always be used by adults or under adult’s supervision Never open the doors while the UVC lights are on Ensure casters are locked before opening cart doors Always latch doors before moving the cart. Do not use power cord to pull the cart or roll the cart over the power cord Any repairs should always be performed by a qualified electrician.
  • Page 5: Features

    FEATURES Main Structure Top IT area Storage shelf Front doors with locking Universal casters (2 lockable) Ergonomic handle UVC light IT Area Power supply unit Manual switch for USB charger Power switch for cooling fan UVC lights programmer USB charger programmer RCD and circuit breaker Smartswitch for UVC cleaning cycle...
  • Page 6: Technical Data

    TECHNICAL DATA Specification Table Model VR12 VR20 VR30 Dimensions (LxWxH) 750 x 400 x 860mm 750 x 600 x 860mm 900 x 600 x 860mm Charging Devices Portable electronics and VR headsets W: 600mm W: 600mm W: 600mm Shelf Size D: 250mm D: 250mm D: 250mm...
  • Page 7: Model Varieties

    MODEL VARIETIES VR12 VR20 VR30...
  • Page 8: Controls And Programming

    CONTROLS & PROGRAMMING UVC Disinfection Cycle Cart is pre programmed for 2 minutes disinfection cycle, which is specifically design to deliver over 99.9% reduction of common bacteria and viruses. Disinfection cycle is initiated by start button (ref.: page 4 position 11) In order to start sanitization cycle the steps below need to be followed: Open the door and place all items on cabinet selves.
  • Page 9 CONTROLS & PROGRAMMING Charging Time Settings Functions Charging time setting function is an optional feature, allowing users to setup specific charging time slots (7 days a week). Charging will only be activated during pre-set window. For detailed instructions please refer to Appendix 1 of this guide.
  • Page 10: Setup Of Device

    SETUP OF DEVICES VR12 Setup Remove the back panel from the sanitization/charging cart to allow access to the USB charging ports Starting from the top area of the cart, connect the charging cables for individual devices to the USB charging ports Pass the charging cables through holes on in the back panel and route them to the front of cart.
  • Page 11: Cleaning And Maintenance

    CLEANING & MAINTENANCE For a daily cleaning use a soft dry cloth, do not use abrasives or solvents. Check if rear access panel (VR12 only) is secured and locked Check power cord for any visual damage Check body of the cart for visual damage Avoid using the cart in dusty, dirty places Do not store the cart in low temperatures, it may produce condensation.
  • Page 12: Troubleshooting

    TROUBLESHOOTING The devices are all plugged in, but won’t charge? Make sure cart’s power cord is fully inserted into power outlet Check if the power button is ON Check if the safety switch is ON Refer the Appendix1 (Charging and Time Setting Instructions) The UVC light does not work? Make sure cart’s power cord is fully inserted into power outlet Check if the power button is ON...
  • Page 13: Warranty

    WARRANTY Two years on main body and electronic system, one year on UVC bulbs. Plugs, cords are not warranted Limitations of Warranty. We make no warranties to any third party. Disclaimer of Warranty Except as expressly provided otherwise herein and to the maximum extent permit- ted by applicable law, we disclaim all other warranties with respect to the product, whether express, implied, statutory or otherwise, including without limitation, satis- factory quality, course of dealing, trade usage or practice or the implied warranties...
  • Page 14: Appendix - Setting Charging Time

    APPENDIX Setting Charging Time Charging time programmer is a device that allows precise charging intervals setup for the USB charging points inside the cart. Charging will only be activated during pre-set window and stay inactive outside of it. This function is commonly used for power saving purposes.
  • Page 15 APPENDIX Setting Charging Time Continued CYCLE SETTING Press "RESET/RECALL" and "TIMER" together for 3 seconds, and it begin to countdown setting, Press "WEEK" to determine the week, "HOURS" to hour,"MINUTE" to minute. Press "AUTO/MANU" to start or pause the cycle (can adjust the time when pause) Example: If you want to charge the devices on 19:00, and stop charging on 08:00 next day.
  • Page 16: Appendix - Uvc Digital Timer Programming Instructions

    APPENDIX UVC Digital Timer Programming Instructions Time setting range: 0-999 hours 0-999 minutes 0-999 seconds Reset: Hold the “SET“button and power on . TIMER Program number setting Tuesday WEEK Weekday setting Wednesday HOUR Hour setting Thursday P0=0: T1 timing mode is seconds P0=1: T1 timing mode is minutes P0=2: T1 timing mode is hours P1=0: The relay is closed after delaying T1 (T1 timing)
  • Page 17 APPENDIX UVC Digital Timer Programming Instructions Continued P1=3: The relay is released after a delay of T1 (T1 timing), and after a delay of T2, the relay is closed (T2 timing), and it ends. P1=4: After the delay of T1, the relay is closed (T1 timing), and after T2, the relay is released (T2 timing), and the cycle is repeated.
  • Page 18 APPENDIX UVC Digital Timer Programming Instructions Continued Example If you need to setup lights for 6 minutes: 1. Setting the time loops: Short press SET button to enter the top timer (timer will flash) Using arrows “↑” or “↓” set timer to 6 Short press SET button to enter the bottom timer (timer will flash) Using arrows “↑”...
