Technics RS-AZ6 Service Manual

ORDER NO. AD9602020A2
Service Manual
Stereo Cassette Deck
*
DOLBY B»C NR HX PRO
Cassette Deck
RS-AZ6
Colour
(K)...Black Type
Area
Please file and use this manual together with the service manual for
Model No. RS-AZ7, Order No. AD9601017C2.
V.___
J
Note: • This service manual is provided to indicate the main differences
between the original model No. RS-AZ7 (E) and the subsequent model
No. RS-AZ6 (E, EB, EG).
Suffix for
Model No.
Area
Colour
(E)
Europe.
(K)
(EB) Great Britain.
(EG)
Germany and Italy.
* Dolby noise reduction and HX Pro headroom extension
manufactured under license from Dolby Laboratories
Licensing Corporation. HX Pro originated by Band and
Olufsen. "Dolby", the double-D symbol and "HX PRO"
are trademarks of Dolby Laboratories Licensing
Corporation.
CHANGES
■SPECIFICATIONS
RS-AZ7 (E) RS-AZ6 (E, EB, EG)
■General
mm
■General
Power consumption
26W
Power consumption 25W
Weight
4.2kg
ha
Weight
3.9kg
■ CHANGE IN REPLACEMENT PARTS LIST
(RS-AZ7 Service Manual of pages 56—60.)
Notes:
• Mentioned in this parts list is only those different from Model No. RS-AZ7 (E). All other parts are the same as for
RS-AZ7 (E).
• Important safety notice:
Components identified by A mark have special characteristics important for safety.
Furthermore, special parts which have purposes of fire-retardant (resistors), high-quality sound (capacitors), low-noise
(resistors), etc. are used.
When replacing any of components, be sure to use only manufacture's specified parts shown in the parts list.
• The parenthesized indications in the Remarks columns specify the areas. (Refer to the cover page for area.) Parts
without these indications can be used for all areas.
Change of Part No.
Part Name & Description Remarks
INTEGRATED CIRCUIT(S)
IC4 AN6558SFE2
—
BUFFER AMP Deletion ;
TRANSISTOR(S)
Q101-104 2SK369GRTPE2
—
TRANSISTOR
Deletion
Q105, 106 2SB709QRSTX
— TRANSISTOR
Deletion
Q107, 108 2SD601QRSTX
— TRANSISTOR Deletion
Q109 DTC144EKT147
—
TRANSISTOR
Deletion
