Villa ADIME904-04 User Manual

Stainless steel veterinary scale
Hide thumbs

Advertisement

Quick Links

Download this manual
STAINLESS STEEL
VETERINARY SCALE
USER GUIDE
ADIME904-04

Advertisement

loading
Need help?

Need help?

Do you have a question about the ADIME904-04 and is the answer not in the manual?

Questions and answers

Summary of Contents for Villa ADIME904-04

  • Page 1 STAINLESS STEEL VETERINARY SCALE USER GUIDE ADIME904-04...
  • Page 2 Thank you for your purchase. Viva Comfort maintains a strong practice of ongoing development of products and commercial research. We recognize that starting and maintaining a medical practice is expensive. We’ll help make the process cost- effective and elegant. Additionally, our team of specialists will ensure everything you need works as efficiently as possible, so you can effectively treat your clients.

  • Page 3: Table Of Contents

    Table of Contents Parts List Button Functions Operational Method Malfunction Specification Warranty...

  • Page 4: Parts List

    Parts List A. Base B. Indicator...

  • Page 5: Button Functions

    Button Functions Serial Port Name Function Menu Function Instruction Code Turn on/off Null ON/OFF Switch the unit Scroll down the menu UNIT or parameters Hold Function/ Scroll up the menu or HOLD/ Output Printing parameters PRINT Tare Enter the menu or TARE confirm to change parameter.

  • Page 6: Operational Method

    Operational Method: Installing the Power Adapter: A. Insert the plug of the AC Adapter into the supply hub located on the left of the display indicator. B. Insert the AC Adapter into the AC socket. Loading The Batteries: A. Open the battery cover located on the right side of the display indicator, load four AAA alkaline cells into the cell box.
  • Page 7 Calibration - Single Point: A. To calibrate, press the hold the “UNIT” button until the window displays “------.“ B. Press the “UNIT” or “HOLD” button to switch functions and make the window display “CAL.” C. Press the “TARE” button to ensure you enter calibration mode. D.
  • Page 8 Calibration - Single Point: G. If you have to change this weight, you can short-press the “UNIT” button or the “HOLD” button to enter the modified menu. a. Press the “UNIT” button to change the flashing position and then press the “HOLD” button to make the flashing position’s number plus 1.
  • Page 9 Hold Function: A. When the “HOLD” button is pressed the following occurs: a. The CPU will send weight data into the USB or RS232 socket. b. The weight will remain on the display for 120 seconds after the item has been removed from the scale so that the weight can be easily read.
  • Page 10 Counting Sample: A. When trying to count, remove unrelated objects on the platform, and then press the “TARE’ button to go back to zero. B. Press the “UNIT” button to switch the unit to “PCS”, and the window will display “ADD10”. a.
  • Page 11 Set User Parameter: A. When the machine is off, press and hold the “UNIT” button together with the “ON/OFF” button to turn the scale on. a. DO NOT release the “UNIT” button until the screen displays “-----“. B. Press the “UNIT” or “HOLD” button to switch to the menu. C.
  • Page 12 User Parameter Meaning of Selectable Meaning of Menu Menu Parameter Parameter Check the Null Check the internal code for codE internal code debugging by manufacturer. Zero tracking 0.5/1/2/3d Set automatic zero range tracking range. Printout kEy/Auto/ kEy: Printout while method Conti pressing the key, Auto: Printout Automa-...
  • Page 13 Meaning of Cue Code Display Meaning of Code Solution Code 1. The calibration weight val- 1. Load the weight value ue is not loaded according to according to the show the display when calibrating. value. 2. The quantity of objects is 2.

  • Page 14: Malfunction

    The scale is not calibrated. then begin to weigh The calibration weight is Use the precise False not precise. calibration weight. calibration Specification ADIME904-04 Model 300kg/ 660lb Capacity 0.1kg/ 0.2lb Division To capacity by subtraction Tare Range 300kg/ 660 Capacity 9d...

  • Page 15: Warranty

    Warranty Viva Comfort (the “Company” or “Tiger Companies”) warrants to the purchaser that the product will be free from defects in workmanship and materials for a period of 1 year from the date of purchase. The warranty period is not extended if we repair, replace, exchange, or provide a refund for the product (as determined in our sole discretion).
  • Page 16 ADIME904-04 © 2023 Viva Comfort vivacomfort.com...
