Installation, OPERATION AND MAINTENANCE INSTRUCTIONS
Vandal Resistant Refrigerated Universal Bi-Level AquaAccess
Alternate Configuration
TECHNICAL ASSISTANCE TOLL FREE TELEPHONE NUMBER:
Notes TO INSTALLER:
1. Please leave this documentation with the owner of the fixture when finished.
2. Please read this entire booklet before beginning the installation.
3. Check your installation for compliance with plumbing, electrical and other applicable
codes.
LIMITED WARRANTY - UNITED STATES & CANADA
Acorn Aqua warrants that its products are free from defects in material or workmanship under normal use and
service for a period of one year from date of original shipment or for 18 months after the date of shipment from the
factory, whichever comes first. The compressor, condenser and refrigeration tubing is warranted for five years.
Acorn's liability under this warranty shall be discharged solely by replacement or repair of defective material,
provided Acorn is notified in writing within one year from date of shipment, F.O.B. Industry, California.
This warranty does not cover installation or labor charges and does not apply to materials, which have been
damaged by other causes such as mishandling or improper care or abnormal use. The repair or replacement of the
defective materials shall constitute the sole remedy of the Buyer and the sole remedy of Acorn under this warranty.
Acorn shall not be liable under any circumstances for incidental, consequential or direct charges caused by defects
in the materials, or any delay in the repair or replacement thereof. This warranty is in lieu of all other warranties
expressed or implied. Product maintenance instructions are issued with each unit and disregard or non-compliance
with these instructions will constitute an abnormal use condition and void the warranty. Stainless steel must be
protected on jobsite during construction and must be properly maintained after the water has been introduced
into the water cooler or drinking fountain, or Acorn's limited warranty is void.

LIMITED EXPORT WARRANTY -

L1001134
Barrier Free, Wall Mounted Water Cooler
A112408B/S-VR-UBL
1.800.591.9360
Technical Assistance Fax: 1.626.855.4894
One year on parts only.
ACORN AQUA
P.O. Box 3527
City of Industry, CA 91744-0527
United States of America
www.acornaqua.com
Page 1 of 8
OR
Standard Configuration
Revised: 09/07/11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A112408B/S-VR-UBL and is the answer not in the manual?

Questions and answers

Related Manuals for ACORN AQUA A112408B/S-VR-UBL

Summary of Contents for ACORN AQUA A112408B/S-VR-UBL

  • Page 1 LIMITED WARRANTY - UNITED STATES & CANADA Acorn Aqua warrants that its products are free from defects in material or workmanship under normal use and service for a period of one year from date of original shipment or for 18 months after the date of shipment from the factory, whichever comes first.
  • Page 2 IMPORTANT This fixture is intended to dispense water that has been lowered in temperature, but otherwise remains unchanged by the materials in the water cooler. It is common for electrical equipment to be grounded to water lines either within a structure or away from it. Every attempt should be made to prevent this kind of grounding from generating electrical feedback into the water cooler creating electrolysis.
  • Page 3 Acorn Aqua. 10. Fixture operates within water pressure range of 20 to 105 psig. Acorn Aqua will not warranty fixtures damaged when connected to supply lines with flow pressure lower than 20 psig or higher than 105 psig.
  • Page 4 ITEM 30 ITEM 30 FILLER PLATE FILLER PLATE STANDARD WASTE CONFIGURATION ALTERNATE WASTE CONFIGURATION INSTALLATION: Choose configuration; Remove and reinstall filler plate, item 30 , reverse drain assembly if required for alternate mounting configuration. 1. Mount hanger bracket to wall horizontally level as shown in Roughing-In and Dimensional Drawing. Note: Adjust height of bracket if bubbler outlet height is required to vary from that shown.
  • Page 5 TROUBLE SHOOTING: IMPORTANT: BEFORE MAKING ANY OF THE REPAIRS LISTED, MAKE SURE THE WATER COOLER IS DISCONNECTED FROM THE ELECTRICAL SUPPLY AND THE WATER SUPPLY VALVE IS SHUT OFF. 1. Adjustments a. Cartridge – The water flow can be adjusted through the pushbutton using a straight blade screwdriver and turning clockwise to increase flow and counterclockwise to decrease flow.
  • Page 6 Valve Cartridge Assembly 7000-060-000 Valve Cartridge 7000-053-199 Jam Nut Repairs must be made with Acorn Aqua parts only. Please order through your local representative or distributor. The phone number to locate your local representative is 1.800.591.9360. Page 6 of 8...
  • Page 7 COOLER PARTS BREAKDOWN DRAWING 28 29 3" 28 29 8" 15" 3" 20" 24" 29 28 20" 29 28 20" 29 28 20" Standard A112408S/B-VR-UBL Refrigerated AquaAccess shown. All 1/4" O.D. Plastic tubing 28 must be insulated with 29 foam insulation. NOTE: See next page for table of part numbers corresponding to drawing above.
  • Page 8 0124-050-000 #8 x 3/8" LG PHILLIPS PAN HEAD SCREW Repairs must be made with Acorn Aqua parts only. Please order through your local representative or distributor. The phone number to locate your local representative is 1.800.591.9360. Page 8 of 8...
