MP5103 SMART DASHCAM (4K ULTRA HD)
USER GUIDE
Please read this operating manual fully and abide by all safety instructions
when using this device.
Keep these instructions for future reference. When passing the device on to
others be sure to include all documentation. The instruction leaflet is also
available on our website:
www.maypoleltd.com
Advertisement
Table of Contents
Related Manuals for MayPole EVC-100R
Summary of Contents for MayPole EVC-100R
- Page 1 MP5103 SMART DASHCAM (4K ULTRA HD) USER GUIDE Please read this operating manual fully and abide by all safety instructions when using this device. Keep these instructions for future reference. When passing the device on to others be sure to include all documentation. The instruction leaflet is also available on our website: www.maypoleltd.com...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS • If you are not confident working with 12V/24V DC wiring, removing or installing interior panels, carpeting, dashboards or other components of your vehicle, consider having the dashcam professionally installed. • The device is immune from interference from other wireless devices, bluetooth, mobile telephones, Wi- Fi routers, power lines and other electrical equipment. -
Page 3: Product Layout
PRODUCT LAYOUT 1. Mounting bracket/ GPS module 8. Up 2. Mount release button 9. Lens 3. AV input port 10. TF card slot 4. Mini USB socket 11. Reset 5. Menu 12. Power 6. Down 13. Display screen 7. Mode PREPARATION &... -
Page 4: Video Setup Menu
• Using the adhesive pad, mount the dashcam on the front windscreen ensuring the camera’s field of vison and GPS module is not obstructed. • NOTE – choose the installation location in advance as the adhesive pad is single use only. •... - Page 5 Menu Options/ description Resolution 4K (30fps), 2K (30fps), 1080P (60fps), 1080P (30fps) Loop Recording 1 or 3 minutes WDR (Wide Dynamic On/Off Range) G Sensor Off/ low/ medium/ high sensitivity Exposure -2.0 to +2.0 Record Audio On/Off Date Stamp On/Off A further press of the menu key (5) will show the below menu settings: Menu Options/ description...
-
Page 6: Video Mode - Operation
VIDEO MODE - SCREEN DISPLAY 1. Video mode 2. Emergency lock 3. WIFI 4. Recording (yellow = locked/ red = normal) 5. Recording time 6. Video resolution 7. Audio 8. Time 9. Date 10. GPS Signal (yellow = GPS connected) VIDEO MODE - OPERATION •... -
Page 7: Camera Setup Menu
CAMERA SETUP MENU • Before using the device, it is recommended you set each menu option. • Short press the mode button (7) to stop recording then long press the same mode button (7) to enter camera mode. Pressing the menu button (5) will show the camera menu options. -
Page 8: Playback Mode
1. Camera mode 2. Capacity of images on SD card 3. Resolution 4. Time 5. Date 6. Anti Shaking CAMERA MODE – OPERATION • In video mode; long press the mode button (7) to activate camera mode. • Pressing the mode button (7) will take still images. PLAYBACK MODE •... -
Page 9: Gps Operation
• Download and install the app. • Make sure WIFI is enabled on your smartphone. • Select ‘NVT_CARDV688fc9380039’ to add the dashcam. The default password is ‘12345678’. • Once the device is successfully connected you can view, control footage and download files onto your smartphone. - Page 10 NOTE – it is essential your smart phone has a strong network signal for the GPS journey to playback successfully as a google map on your smart phone. Scan the below QR code to access a how to guide to help with this process: •...
- Page 11 REAR CAMERA (MP5104) This dashcam can be used with the Maypole rear camera (MP5104) which is sold separately. This allows footage to be recorded at the rear or inside the vehicle. NOTE – only ever connect the Maypole rear camera (MP5104) to this dashcam and refer to the instructions included with the rear camera before installation.
-
Page 12: Environmental Protection
DECLARATION OF CONFORMITY We declare that this product conforms to the following standards: EMC Directive 2014/53/EU ROHS 2011/65/EU Annex II and its amendment Technical Manager, Maypole Ltd, Dec 2023 Email: sales@maypoleltd.co.uk Web: www.maypoleltd.com...
