Summary of Contents for NEMIQ NTCS Series
- Page 1 OPERATION MANUAL Edition No.: 2020 Rev 1 (CE, ISO9001) NTCS Series Full-automatic Computer Wire Stripping Machine Operation Manual (FOR NTCS 16)
- Page 2 1 . S t r a i g h t e n i n g f r a m e : w i r e s t r a i g h t e n i n g e f f e c t 2 .
- Page 3 OPERATION MANUAL 5. Inlet hole seat: fixed catheter, move up and down to adjust the center position of the catheter and blade. 6. Feeder wheel lift function: rotate the feeder wheel counterclockwise, and rotate the feeder wheel clockwise. 7. Wire feed wheel: The motor drives the wire feed wheel to rotate so that the wire material moves forward and backward, and cooperates with the function of the wire feed and stripping head of the knife holder.
- Page 4 OPERATION MANUAL wheel increases when it is rotated upward, and decreases when it is rotated downward. 15. Outlet wheel pressure adjustment knob: adjust the pressure between the two wheels of the outlet wheel, pull out the knob to rotate counterclockwise to increase the pressure, turn clockwise to decrease the pressure, adjust the appropriate pressure and push it inward to fix it.
- Page 5 OPERATION MANUAL Part 2: Operation of the computer Picture 1 1.1. Program: store parameters from 0-99 program serial numbers. 1.2 UPH: to wait. 1.3. FORWARD: Thread the thread into the cable entry hole until the cable entry roller. Press the [Thread entry] roller to automatically feed the thread forward.
- Page 6 OPERATION MANUAL make the machine work. 1.7. Stop: Press [Stop] to stop the machine. 1.8. Reset: Make each part of the machine return to the origin. 1.9 Emergency stop: When the machine is in working state, press [Emergency Stop], the machine will stop working urgently. 1.10.
- Page 7 OPERATION MANUAL 1.16. Cutter Back: Refers to the blade cutting into a certain depth and retreating to a certain size to avoid the core wire being scratched. The size of the retreat is determined according to the thickness of the wire rubber. The thicker the rubber is, the larger the retreat is.
- Page 8 2 . 1 . C u t t e r : P r e s s t h e f o r w a r d b u t t o n t o c l o s e t h e u p p e r a n d l o w e r b l a d e s...
-
Page 9: Parameter Settings
OPERATION MANUAL Parameter settings: Picture 3 3.1 Roller speed: refers to the motor feed roller speed of 00-99, 00 is the slowest and 99 is the fastest. 3.2. Cutter speed: refers to the cutting speed of the knife holder driven by the motor, the speed is 00-99, 00 is the slowest and 99 is the fastest. - Page 11 OPERATION MANUAL MIDDLE STRIP Picture 5 MIDCUT: on / off 5.1. DIA MODIFY: when the middle stripping wire and the copper wire are too tight to be stripped, the cutting depth of the middle stripping can be slightly increased. For example, 0.1 means 0.1+ 【Picture 1】 wire diameter. 5.2.
- Page 12 OPERATION MANUAL...
