- Page 1 5500 Dual Equalizer OPERATOR’S MANUAL Revised 2024-01-17 W ri t t en f o r A ut o mat ed Pro cesses, I n co r po rat ed by Dan i el Pf ei f er...
- Page 2 No part of this publication may be reproduced in any form or by any means, whether mechanical or electronic, without the written permission of Automated Processes, Inc. As research and development is a continual process, API reserves the right to change the features and specifications described herein without notice or obligation. API cannot be held responsible for any loss or damage arising directly or indirectly from any error or omission in this manual.
- Page 3 55-year tradition of API excellence, we appreciate your purchase. API takes great pride - and great care - in the hand assembly of all our professional audio products. Above all, we appreciate our loyal users, who have made the Company what it is today.
-
Page 4: Table Of Contents
A3 5500 Recall Sheet ................. 13 A4 5500 Housekeeping ............... 13 A5 API Limited Warranty and Service Information ......14 5 5 0 0 D u a l E q u a l i z e r A P I... -
Page 5: About This Manual
Experienced engineers may get up and running quickly, but if you are new to API equalizers, it’s recommended that you read the entire manual at least once and keep it handy while recording, editing, and mixing. -
Page 6: Important Safety Instructions
Important Safety Instructions 1. Please read these instructions 2. Keep this information in a safe place 3. Do not use this device near water 4. Clean only with a dry cloth 5. Do not block any ventilation openings 6. Do not install near any heat sources such as radiators, heat registers, stoves, or other devices that produce heat 7. -
Page 7: Overview
1.0 Overview 1.1 History of the API Equalizer The lineage of the 5500 circuit can be traced back to the original 550 equalizer designed by Saul Walker, the founder of Automated Processes, Inc. That three band EQ was originally used in the earliest API consoles built in the 1960s. Engineers were immediately captivated by its fully reciprocal boost/cut characteristic and its proportional Q design, one of API’s... -
Page 8: Range Control
1.6 Power Mute and Bypass The 5500 features a true hard-wire bypass. In this mode, the output connector is wired directly to the input. Shortly after power is first applied, or immediately after it is lost, a special circuit forces this mode, so signal is never lost and power thumps are never heard. -
Page 9: Front Panel Controls
Illuminates in red when engaged 2.2 Channel Controls The 5500 is a two-channel unit that can be used as two separate mono EQs or in stereo. Each channel has an identical set of controls, all of which will be outlined in the following sections. -
Page 10: Boost And Cut
“tilt” to the tonal balance towards treble or bass. The API 5500 accomplishes both of these tasks without sounding resonant. - Page 11 Mastering engineers also prefer an equalizer that has exactly repeatable switch settings and the capability of truly reciprocal operation, features that are common to all API equalizers. 5 5 0 0 D u a l E q u a l i z e r...
-
Page 12: Rear Panel Connections
3.0 Rear Panel Connections 3.1 Balanced INPUT and OUTPUT Connections Each channel is equipped with a set of balanced, line level audio input and output connectors. The audio INPUT is a female, 3-pin, XLR connector that feeds an active balanced circuit. There is a switching 1/4”... -
Page 13: Appendix
+24dBu, but another API device could distort any input transformer since it is capable of an undistorted +30dBu output. Since API equipment is capable of signal voltages that are typically twice as large as most professional equipment, it is possible that the input transformer will experience some distortion in the low frequencies when fed signals beyond +24dBu. -
Page 14: A3 5500 Recall Sheet
A3 5500 Recall Sheet A4 5500 Housekeeping Here is a great place to write down the serial number of your 5500 and your purchase date, just in case you need that information someday in the future. API 5500 serial number ________________... -
Page 15: A5 Api Limited Warranty And Service Information
API. Therefore, service or modification of any API unit except by an authorized API representative may VOID this warranty. c) API reserves the right to inspect any products that may be the subject of any warranty claims before repair or replacement is carried out. Final determination of warranty coverage lies solely with API. - Page 16 8301 Patuxent Range Road! Jessup, MD 20794 USA 301-776-7879 http://www.apiaudio.com...
