LED PAR 54x3in1 RGB
LD611-54031
User Manual
This product manual contains important information about the safe installation
and use of this product.Please read and follow these instruction carefully and
keep this manual in a safe place for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LD611-54031 and is the answer not in the manual?

Questions and answers

Summary of Contents for SUPER-CAN LD611-54031

  • Page 1 LED PAR 54x3in1 RGB LD611-54031 User Manual This product manual contains important information about the safe installation and use of this product.Please read and follow these instruction carefully and keep this manual in a safe place for future reference.

  • Page 2: Security Warning

    Understanding of Product Security Warning  When unpacking and before disposing of the carton, check if there is any transportation damage before using the product. Should there be any damage caused by transportation, consult your dealer and do not use the apparatus. ...

  • Page 3: Main Technical Parameters

    Main Technical Parameters Power supply  Rated Voltage: AC90~240V  Rated Frequency: 50~60Hz ± 10%  Rated Power: 200W  LED Type: 54pcs × 3in1 RGB Chips  Drive Current: 2700mA x 3  Colors: 256 (0~100% Dimming)  Life: About 50,000 hours Control ...

  • Page 4: Product Features

    Product Features Using latest LED control technique, newest intelligent LED Par light can realize intelligent operation and control through its special menu at the backside. It’s more convenient and easy to operate.This product is designed for building large area spread light,large concerts, outdoor landscape lighting, wedding scene, small performances, slow club KTV and various performance occasion.

  • Page 5: Operation Method

    DMX Connection Method 2.2--1 When you set the DMX512 address code,, as below:  The DMX interface of lamp needs be connected to the controller  DMX address from 001 to 512. Note: 1. As this fixture's DMX signal cable connection is Parallel connection, please don’t more than 15 units.

  • Page 6: Menu Overview

    Menu Overview Static Color Setting (STATIC)  Find【STATIC】menu and press【ENTER】 to enter color static setting.  Press【ENTER】button to select【RED】,【GREEN】,【BLUE】, or【STROBE】.  Press【UP/DOWN】button to adjust parameters.  Press【MENU】button to return to the menu, the selected parameters will be automatically saved.  After setting lighting fixture's static color, restart the lighting fixture's power supply.
  • Page 7 Automatic Programming Setting (AUTO)  Find【AUTO】menu and press【ENTER】to enter automatic programming setting.  Press【UP/DOWN】button to select【AT.01~05】5 kinds of auto-program.【PT.01~10】10 kinds of programmable. Press【ENTER】to confirm your setting.  After setting lighting fixture's automatic operation,restart the lighting fixture's power supply.The setting was preserved.Exit menu,automatic operation setting will be removed. Note: When entered this submenu, the light fixture will automatically set to the data status sent by the master, other light fixtures should be set as the slave.
  • Page 8 DMX Channel Mode setting (PERS)  Find【PERS】menu and press【ENTER】to enter DMX channel mode setting.  Press【UP/DOWN】button to select【8CH, ARC.1……】5 kinds DMX channel modes.  Press【ENTER】to confirm or【MENU】to exit.The setting will be automatically saved. Function Settings (SET)  Find【SET】menu and press【ENTER】to enter function setting. ...

  • Page 9: Control Channel

    Temperature control protection State When the temperature of the LED bead plate more than 65℃, the driver current begin slow down,to protect the LED Chips bead is not damaged by high temperature heat aging. Control Channel 4.1----3CH 3CH Mode: Channel DMX Data Control function Detail description...
  • Page 10 4.3----ARC.3+D 5CH Mode: Channel DMX Data Control function Detail description Over dimmer Brightness 0~100% Red dimmer Brightness 0~100% Green dimmer Brightness 0~100% Blue dimmer Brightness 0~100% NO FUNCTION Linear dimming speed (DIM=OFF) Fading speed Non-linear dimming speed1 (DIM=1) Fading speed Non-linear dimming speed2 (DIM=2) Fading speed Non-linear dimming speed3 (DIM=3)
  • Page 11 4.5----STAG 9CH mode: DMX data Functions Descriptions Overall Dimmer Brightness 0~100% Red Dimmer Brightness 0~100% Green Dimmer Brightness 0~100% Blue Dimmer Brightness 0~100% NO FUNCTION RED 100％/GREEN UP/BLUE 0％ RED DOWN/GREEN 100％/BLUE 0％ RED 0％/GREEN 100％/BLUE UP RED 0％/GREEN DOWN/BLUE 100％ COLOR MACRO RED UP/GREEN 0％/BLUE 100％...

  • Page 12: Product Maintenance

    Remark: This product warranty for one year. We provide pay-needed maintenance service after the warranty. But because of natural and man-made disasters or improper operation caused damage not under warranty range! SUPER-CAN INDUSTRY GROWING GROUP CO.,LTD. MADE IN CHINA - 11 -...
