StressVest StressX PRO Quick Setup Manual

OVERVIEW

The StressX™ PRO Belt is the brains of the entire StressVest®
system. It allows the Instructor to set the system to deliver a
vibration or shock. The shock adjustment allows the instructor to
adjust the pain penalty based on the students' level of performance
from 1(Lowest) to 5 (Highest). Twelve Advanced Training Instruction
Modes have been programmed into the StressX™ PRO Belt to
optimize the level of training for the students. Finally, it registers
the number of hits to the StressVest®. The StressX™ PRO Belt has
a USB port that is used for charging and also for remote upgrading
of the software if required.
STRESSX PRO BELT PARTS
™
1 2 3 4 5

BASIC OPERATION

Turning On the StressX
™
Press the Power On/Off Button (1) once. The Power On/Off Button (1) should illuminate red.
Turning Off StressX PRO Belt
™
Press and hold the Power On/Off Button (1) for two seconds. The Power On/Off Button (1)
should turn off.
SETTING TRAINING MODES & SHOCK LEVEL
There are 12 Advanced Training Modes and 5 Shock Levels (1-Low to 5-High) that the StressX™ PRO can be set to.
1. Press the Select Button (4) on the StressX™ PRO until the
Mode LED Indicator is illuminated. Press the Up & Down
Arrows (9) to move to the desired Mode. The mode number
is displayed in the LED Display (8).
2. Press the Select Button (4) on the StressX™ PRO until the
Level LED Indicator is illuminated. Press the Up & Down
Arrows (9) to move to the desired Shock Level. The Shock
Level is displayed in the LED Display (8).
STRESSVEST INC.
1080 Kingsbury Avenue • Winnipeg, Manitoba, Canada R2P 1W5
Toll Free: 1-866-353-5055 • Ph: (204) 336-0011 • Fax: (204) 586-2049 • info@stressvest.com
6 7 8 9 10
PRO Belt
Operating Instruction:
QUICK SETUP GUIDE
11
1. Power On/Off Button
2. Sync Button
3. Shock Button
4. Select Button
5. Hits LED Indicator
6. Mode LED Indicator
ROLE PLAYER MODES
(Ensure Controller Switch is Set to Vibrate)
1 - Vibrates every hit.
2 - Vibrates after two hits
3 - Vibrates after three hits
MOVE TO COVER MODES
(Pain Penalty Increases with Each
Subsequent Hit)
6 - Vibrates 1st hit, 2nd begins shock
7 - Shocks 1st at Low then increases
8 - Shocks 1st at Med then increases
StressX
™
StressX™ PRO Belt
7. Shock Level Indicator
8. LED Display
9. Up & Down Arrows
10. Sync Window
11. Belt Strap Holders
STRESS EXPOSURE MODES
(Set Appropriate Shock Level for Student)
4 - Shocks every hit.
5 - Vibrates 1st hit, then shocks
INJURED OFFICER MODES
(Shock Continues to Fire Randomly for Set
Time Period After First Hit)
9 - Shocks randomly - 10 seconds
10 - Shocks randomly - 20 seconds
11 - Shocks randomly - 30 seconds
12 - Vibrates randomly - 30 seconds
PRO - Advanced Training Modes
